- Page 1 21.5” (54.6cm) FHD LED LCD TV with Built-in DVD Player AK22FLEDCG Instruction Manual AFTER SALES SUPPORT NZ: 0800 883 301 N13275...
-
Page 2: Table Of Contents
Contents Important Safety Instructions Usage conditions and restrictions Electrical safety, power cord and plug Position Cleaning and maintenance Assembly Mounting Instructions Connections and Functions Remote Control Installing the Batteries Remote Control Operation First Time Installation Selecting an Input Source Menu Operation in DTV Mode Channel Menu Picture Mode Sound Mode... - Page 3 Contents Specifications Care and Maintenance Responsible Disposal FAQs...
-
Page 4: Important Safety Instructions
Important Safety Instructions Read this manual thoroughly before first use and keep it in a safe place for future reference, along with the warranty card, purchase receipt and carton. The safety precautions enclosed herein reduce the risk of fire, electric shock and injury when correctly adhered to. Usage conditions and restrictions To prevent any injuries, the following safety precautions should be observed in the installation, use, servicing and maintenance of equipment. -
Page 5: Electrical Safety, Power Cord And Plug
Important Safety Instructions (Cont.) Electrical safety, power cord and plug • Before installing this TV set, make sure your outlet voltage corresponds to the voltage stated on the appliance rating label. • To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. •... - Page 6 Important Safety Instructions (Cont.) • Do not apply excessive force to the screen when cleaning. • Do not clean the screen with water or chemical cleaners as this may damage the LED screen surface. • Do not dismantle this product by yourself, as this may cause damage. There are no user- serviceable parts contained in the TV set.
-
Page 7: Assembly
Assembly Assembly Contents of carton: Contents of carton: 1 x TV Set 1 x Instruction Manual 1 x Stand Base 1 x TV Set 1 x Instruction manual 1 x Stand base 1 x Remote Control 2 x AAA Batteries 2 x Screws (for stand) 1 x Remote control 2 x AAA batteries... -
Page 8: Mounting Instructions
Mounting Instructions Notes: Assembly (Cont.) • Contact a professional for assistance when wall mounting your TV. We are not responsible for any damage to the product or injury to yourself, if you mount the TV on your own. • Do not wall mount the TV while TV is turned on. It may cause personal injury due to electric Wall mounting shock. -
Page 9: Connections And Functions
Connections and Functions Controls and Connections Controls and Connections Front View Side View Front View Side View LED display screen LED display screen Power indicator- In standby mode the Power indicator- In standby mode the Back View Back View indicator shows red; when switching on indicator shows red;... -
Page 10: Back View
Connections and Function (Cont.) Controls and Connections (Cont.) Back View 1. Power input: Connect the included power adaptor. 2. HDMI 1: Connect the HDMI output jack of DVD 3. PC AUDIO: Connect the Audio output jack of PC. Power Input: Connect the included power adaptor. 4. -
Page 11: Basic Installation
Connections and Functions (Cont.) Basic Installation Basic Installation Power Cord Connection Power Connection - Connect the power cord correctly as shown. Power Connection ● Connect the power adaptor to power outlet correctly as shown below. - Press the POWER switch of your TV to switch the unit on. The power indicator on the front ●... - Page 12 Basic Installation (Cont.) Connections and Functions (Cont.) AV (CVBS) Connection Basic Installation (Cont.) AV (CVBS) Connection Connect the VIDEO and AUDIO output jack of the DVD or VCR to the AV IN jacks in the set using an Connect the VIDEO and AUDIO output jack of the DVD or VCR to the AV IN jacks on the set using the AV cable (Yellow [video], White and Red [left and right audio]).
-
Page 13: Hdmi Connection
Connections and Functions (Cont.) Basic Installation (Cont.) VGA (PC) Connection VGA (PC) Connection Connect the RGB output of the PC to the VGA jack on the set. Connect the AUDIO output of Connect the VGA output of the PC to the VGA jack on the set. Connect the AUDIO output of the the PC to the PC AUDIO jack on the set. -
Page 14: Earphone Connection
Connections and Functions (Cont.) Earphone cable Earphone cable Coax Connection (Not included) (Not included) Connect the Coaxial output of the TV to the Coaxial (SPDIF) input on the amplifier. Your amplifier must have the corresponding decoding functions to decode the signal coming from the TV. -
Page 15: Remote Control
: To move fast backward. (DTV) : Start recording when watching available digital programs. D.SETUP (DVD): Call out the setup menu. : To stop playing. AK22FLEDCG : To play next chapter. INDEX (DTV): Display the record list. : To play previous chapter. - Page 16 New Zealand channel providers. However, one teletext option, “closed captions”, is still working on most New Zealand television channels. This service allows you to activate subtitles while watching normal television programs that provide AK22FLEDCG...
-
Page 17: Installing The Batteries
Installing the Batteries Installing the Batteries Battery Installation Open the cover at the back of the remote control unit completely. Open the cover at the back of the remote control unit completely. Insert two 1.5V AAA batteries, ensuring the polarities (+/-) of the batteries are correctly Insert two 1.5V AAA batteries, ensuring the polarities (+ / -) of the batteries are aligned and the batteries are properly pushed into place so they can power the remote correctly aligned and the batteries are properly pushed into place so they can power... -
Page 18: First Time Installation
First Time Installation First Time Installation First Time Installation When you switch on the TV for the first time, the First Time Installation menu will be displayed on If you are using the TV for the first time, below menu will appear on the screen after turning on this TV: the screen. -
Page 19: Selecting An Input Source
Selecting and Input Source Selecting an Input Source Selecting and Input Source You can select an input signal source by pressing the SOURCE button on the remote control or You can select an input signal source by pressing the SOURCE button on the remote control or control panel of your TV. -
Page 20: Menu Operation In Dtv Mode
Menu Operations in DTV Mode Menu Operation in DTV Mode Basic Menu Operations Basic Menu Operations 1. Press the MENU button on the remote control, the on-screen menu will appear on the screen. Press the MENU button on the remote control, the on-screen menu will appear on the 2. - Page 21 Menu Operations in DTV Mode (Cont.) Menu Operations in DTV Mode (Cont.) Menu Operations in DTV Mode (Cont.) Menu Operation in DTV Mode (Cont.) ● Press ◄/► button to select desired tune type: DTV, ATV, ATV+DTV. ● ● Press ▼ button and use ▲/▼/◄/► button to select your country. Press ◄/►...
- Page 22 Menu Operation in DTV Mode (Cont.) Menu Operations in DTV Mode (Cont.) Program Edit Programme Edit Press button to select this item and press OK button Menu Operations in DTV Mode (Cont.) Press ▲/▼ button to select this item and press OK button to to enter it.
- Page 23 Menu Operation in DTV Mode (Cont.) Menu Operations in DTV Mode (Cont.) Channel Channel Press button to highlight it and press button to select desired channel. Press ▲/▼ button to highlight it and press ◄/► button to select desired channel. Type Press button to highlight it and press...
-
Page 24: Picture Mode
Menu Operation in DTV Mode (Cont.) Picture Mode Menu Operations in DTV Mode (Cont.) Press MENU button to display the main menu. Press button to select PICTURE, then press OK button to enter sub-menu. Picture menu Press button to select available options: Dynamic, Standard, Mild, User. Tips: Picture Mode •... -
Page 25: Sound Mode
Menu Operation in DTV Mode (Cont.) Noise Reduction Press button to select Noise Reduction, then press OK button to enter it. Press button to select available options: Off, Low, Medium, High, Default. Sound Mode Press MENU button to display the main menu. Press button to select SOUND in the main menu, it will highlight the first option. -
Page 26: Time Settings
Menu Operation in DTV Mode (Cont.) Menu Operations in DTV Mode (Cont.) Time Settings Press MENU button to display the main menu. Time menu Press button to select TIME, then press Ok button to enter submenu. GMT +12 Clock Clock Press button to select Clock and press OK button to enter it. -
Page 27: Lock Menu
Menu Operation in DTV Mode (Cont.) Menu Operations in DTV Mode (Cont.) Lock Menu Press MENU button to display the main menu. Lock menu Press button to select LOCK in the main menu, it will highlight the first option. Lock System Lock System This allows you to turn the system lock on or off. -
Page 28: Hotel Mode
Menu Operation in DTV Mode (Cont.) Menu Operations in DTV Mode (Cont.) Hotel Mode Press MENU button to display the main menu. Press button to select HOTEL in the main menu, it will highlight the first option. Hotel Mode Press button to select On or Off. -
Page 29: Setup
Menu Operation in DTV Mode (Cont.) Menu Operations in DTV Mode (Cont.) Setup Press MENU button to display the main menu. Setup menu Press button to select SETUP in the main menu, it will highlight the first option. West OSD Language OSD Language Press ▲/▼... - Page 30 Menu Operations in PC Mode Menu Operations in PC Mode Connect your computer to the TV using the VGA cable. Power on the TV and your computer. Press SOURCE button on the TV control panel or on your remote control, and 1.
-
Page 31: Menu Operation In Other Mode
Menu Operation in Other Modes Press SOURCE button on the unit or remote control to select other modes. • PICTURE menu and description are the same as DTV mode. • SOUND menu and description are the same as DTV mode. •... -
Page 32: Pvr And Time Shift Operation
Menu Operations in DTV Mode (Cont.) PVR File System PVR and Time Shift Operation ● Insert your USB memory device into USB port before entering PVR f ● Press ▲/▼ button to select this item and press OK button to enter i USB Device Setup Before use the Recording and Time shift functions, you should insert a USB device and format it in the USB Host... - Page 33 PVR and Time Shift Operation (Cont.) Recording (PVR Function) Your TV features a Personal Video Recording function which lets you: Recording (PVR Function) • Instantly record a digital TV program (via the one-touch recording button on Your television features a PVR recording function which lets you: the remote control).
-
Page 34: Important Notes
PVR and Time Shift Operation (Cont.) Time shift recording and playback (DTV mode only) IMPORTANT! Recording (PVR Function, Cont.) Before recording (including time shift recording), you must insert a FAT32 formatted USB storage device into the USB port. Time-shift recording and playback (DTV mode only) Setup Time Shift Recording IMPORTANT! If you don’t want to miss any programs when temporally leaving, while the TV is... - Page 35 PVR and Time Shift Operation (Cont.) Important Notes When using the Media function, remember the following important points: • We strongly recommend you back up all data in the USB storage device to another storage device so you do not risk losing any data in case of an unexpected device failure or accident. We do not assume liability for any loss of data due to misuse or malfunction.
-
Page 36: Media (Multimedia) Playback
Media (Multimedia) Playback Media (Multimedia) Playback Insert a USB memory device (with FAT32 format). Press SOURCE button on remote control to switch TV into Media mode. Or you can press 1. Plug in a USB device (with FAT32 format), then press SOURCE button to switch this unit to MEDIA button on the remote control to enter Media mode directly. -
Page 37: Photo Menu
Media (Multimedia) Playback (Cont.) PHOTO Menu Press button to select PHOTO menu. Press OK button to enter PHOTO menu and press button to select desired disk. Press OK button to enter selected disk, and press buttons to select desired folder. 1. -
Page 38: Music Menu
Media (Multimedia) Playback (Cont.) ● Press button to pause/start playing. ● Press button to play previous/next file. MUSIC Menu ● Press button to stop playing. Press 2. Music playback button to select MUSIC menu. Press OK button to enter MUSIC menu and press button to select desired disk. -
Page 39: Movie Menu
When playing Music files: ● Press ◄/► button to select desired option in the tool bar, and press OK button to confirm it. ● Press button to pause/start playing. Media (Multimedia) Playback (Cont.) ● Press button to play fast backward / fast forward. ●... -
Page 40: Text Menu
Media (Multimedia) Playback (Cont.) When playing Movie files: ● Press DISPLAY button on remote control to display/hide the tool bar. Media (Multimedia) Playback (Cont.) TEXT Menu Press button to select TEXT menu. ● Press ◄/► button to select desired option in the tool bar, and press OK button to confirm it. Press OK button to enter TEXT menu and press button to select desired disk. - Page 41 Media (Multimedia) Playback (Cont.) USB Multimedia Playback Format Media File Codec Remark Exit Video Audio .mpg MPEG-1,MPEG-2 MP3, WMA, AAC, Max Solution: 1920×1080 Max Data Rate: 40 Mbps AC3, PCM .avi Divx, Xvid, MJPEG Max Solution: 1920×1080 Max Data Rate: 20 Mbps MEPG-4 SP/ASP MPEG-2 .mov/...
-
Page 42: Epg (Electronic Program Guide)
EPG (Electronic Program Guide) EPG (Electronic Program Guide) EPG stands for Digital Electronic Program Guide. It is supplied by the program providers and offers EPG stands for Digital Electronic Program Guide. It is supplied by the program providers and offers information about the programs to be broadcast. -
Page 43: Built-In Dvd Player Operation
Built-in DVD Player Operations (If Fitted) Built-in DVD Player Operations (If Fitted) 40 Built-in DVD Player Operations (If Fitted) Some points about discs Built-in DVD Player Operation Built-in DVD Player Operations (If Fitted) Some points about discs Built-in DVD Player Operations (If Fitted) Some points about discs The following types of disc can be played on this unit: Some points about discs... - Page 44 Built-in DVD Player Operation (Cont.) CAUTION: • Only the types of disc listed below can be played on this unit: DVD/CD/CDR/CDRW/DVD-R/DVD+R/DVD-RW/DVD+RW/VCD/SCVD. • A DVD-RW (video mode) can generally be played back, but not necessarily all DVDs of this type: playback capability depends on the recording conditions. •...
-
Page 45: General Setup
Press to highlight and move between different sub-menus, then press ◄/► ▼ enter the sub-menu. Press to move the highlight to the item you wish to select, then press to ▲/▼ ► enter. Press for adjustments and press [OK] to confirm settings. ▲/▼/◄/►... - Page 46 the disc slot, the TV will switch to DVD mode and start playback automatically. 3. To temporarily stop playback of a CD, press to stop playback, press it again to resume playback. To temporarily stop playback of a DVD, press ■ once to stop playback, press it twice Built-in DVD Player Operation (Cont.) to stop playback completely.
- Page 47 Built-in DVD Player Operation (Cont.) A-B repeat (designated range repeat playback) A-B Repeat (designated range repeat playback) Press A-B button on the remote control during playback at the beginning of the section 1. Press [A-B] during playback at the beginning of the section you want to repeat (Point A”...
- Page 48 Built-in DVD Player Operation (Cont.) Audio Sound Track Language (Multi-language DVD) This function works only with discs that have multiple audio sound track languages recorded. Press LANG button on the remote control repeatedly during playback to select desired audio sound track language.
-
Page 49: Specifications
Specifications MODEL AK22FLEDCG Panel System 21.5” (54cm) FHD LED panel Display Resolution 1920 x 1080 Aspect Radio 16:9 Contrast Radio 1000:1 Brightness 250cd/m2 Viewing Angle 170 (H) x 160 (V) Lift Time 30,000 Hrs Inputs/Outputs HDMI input USB input CVBS... -
Page 50: Care And Maintenance
Care and Maintenance Maintaining your TV If you clean your TV carefully and regularly, it helps your TV to last longer. Make sure you turn the power off and unplug the power cord on your TV before you begin to clean it. Cleaning the screen Here’s a great way to keep the dust off your screen. -
Page 51: Faqs
FAQs Problem Action No picture, no sound Check that you have connected the TV power cord properly and switched the wall socket on. Check that you have turned on the POWER button on your TV. Check the picture contrast and brightness setting. - Page 52 FAQs Problem Action No Colour, poor quality colour, Change the colour setting on the PICTURE MENU. poor quality image Keep a distance between your TV and any VCR you may be using Try watching another channel. The problem may be with the channel you’re watching. Are the video cables installed properly? Change the setting of picture brightness on PICTURE MENU.
