MICON
10µs
0.5V
20
WAVEFORMS
50ns
1.0V
21
0.5ms
1.0V
22
50µs
1.0V
23
5ms
1.0V
24
20µs
1.0V
25
The following waveforms were measured at the point of the corresponding
NOTE:
balloon number in the schematic diagram.
H-2
50µs
1.0V
26
10µs
1.0V
27
10µs
1.0V
28
10µs
1.0V
29
SOUND AMP
2ms
50mV
30
