Specifications

Monitor
Specifications
Picture Tube
Viewable Image Size:
Input Signal
Display Colors Analog input: Unlimited number of Colors
Synchronization
Range
Resolutions Supported
Resolution based on horizontal and vertical
frequencies only
Active Display Area
(Factory setting)
Active Display Area
(Full scan)
Power Supply
Current Rating
Dimensions
Weight
Enviromental Considerations
Operating Temperature:
Storrage Temperature:
NOTE: Technical specifications are subject to change without notice.
MultiSync A500+
Monitor
Diagonal: 38 cm (15 inch)
35 cm (13.8 inch)
Radius: 1080 mm
Video: ANALOG 0.7 Vp-p/75
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Positive/Negative) (TTL Level)
Horizontal: 31 kHz to 70 kHz
Vertical: 55 Hz to 120 Hz
640 x 480 @ 60 to 120 Hz
800 x 600 @ 55 to 110 Hz
832 x 624 @ 55 to 106 Hz
1024 x 768 @ 55 to 87 Hz . . . . . . . . . . . . . . . . . . .
1152 x 870 @ 55 to 77 Hz
1280 x 1024 @ 55 to 66 Hz
Horizontal: 270 mm
Vertical: 202 mm
280 mm
210 mm
AC 100-120 V / 220-240 V, 50/60 Hz
1.5 A @ 100-120 V / 0.8 A @ 220-240 V
372 (W) x 402 (H) x 402 (D) mm
12.8 kg
0° C to +35° C
Humidity: 30% to 80%
Altitude: 0 to 3000 m
-20° C to +60° C
Humidity: 10% to 90%
Altitude: 0 to 13500 m
Notes
90° deflection, 0.28 mm trio dot pitch,
medium-short persistence phosphor, multi-layered,
anti-static screen coating, semi-tint screen, Invar
Shadow Mask and OptiClear screen surface.
Depends on the display card
Automatically
Automatically
Some systems may not support all modes listed
NEC cites recommended resolution at 85 Hz for
optimal display performance.
Active display area is dependent upon the signal
timing
Active display area is dependent upon the signal
timing
E - 9
