M3 WR

Inserting the computer into the bracket

The VDO twist-click system securely connects the computer
to the handlebar bracket.
LOck
How to insert the computer:
STEP 1
UNLOck
Place the computer into the bracket in a 10 o'clock position.
STEP 2
Rotate the computer to the right into the 12 o'clock position
and click it into the bracket system. A noticeable resistance
must be overcome to move it into place. 1. LOck 2. cLick
STEP 3
To remove the computer, rotate it to the left
(without pushing or pulling).
Memory aid: Rigid to the Right, Loose to the Left
2. UNLOck

Function testing

Once the transmitter has been attached, check that it
functions correctly.
How to test the transmitter:
– Insert the computer into the bracket.
– Lift and spin the front wheel.
– A speed should now be displayed on the computer.
If no speed is displayed, there can be several reasons for this.
The possible reasons are described in the "Trouble-
shooting" section.
14
