WARNING:
If the information in these instructions are not followed exactly,
a fire or explosion may result causing property damage,
personal injury or loss of life.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
Tested by:
908-727
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
U41 Gas Insert
MODELS: U41-NG3 Natural Gas U41-LP3 Propane
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
www.regency-fire.com
Owners &
Installation Manual
FOR YOUR SAFETY
What to do if you smell gas:
! ! ! ! ! Do not try to light any appliance
! ! ! ! ! Do not touch any electrical switch:
do not use any phone in your
building.
! ! ! ! ! Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
! ! ! ! ! If you
cannot reach your gas
supplier, call the fire department.
10/08/03
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Regency U41
Summary of Contents for Regency U41
- Page 1 Owners & U41 Gas Insert Installation Manual MODELS: U41-NG3 Natural Gas U41-LP3 Propane WARNING: FOR YOUR SAFETY If the information in these instructions are not followed exactly, What to do if you smell gas: ! ! ! ! ! Do not try to light any appliance...
- Page 2 The models U41-NG3 and U41-LP3 of this series have been approved by Warnock Hersey for both safety and efficiency. As it also bears our own mark, it promises to provide you with economy, comfort, and security for many trouble free years to follow.
-
Page 3: Table Of Contents
Faceplate & Trim Installation ......10 Log Installation ..........11 Door Installation & Door Latches ..... 11 Optional Remote Control Installation ....12 Optional Wall Thermostat Installation ....12 Final Check ..........12 Wiring Diagram ..........13 Regency U41-3 ULTIMATE Gas Fireplace Insert... -
Page 4: Safety Label
Commonwealth of Massachusetts. For the State of Massachusetts, flexible connectors shall not exceed 36 inches in length. For the State of Massachusetts, the appli- ances individual manual shut-off must be a t-handle type valve. Regency U41-3 ULTIMATE Gas Fireplace Insert... -
Page 5: Installation Requirements
6) This unit is not approved for installation into a mobile home. plate from the factory built fireplace if The Regency Gas Fireplace must be installed removable without cutting or torching, 7) Always connect this fireplace to a chimney in accordance with these instructions. Care-... -
Page 6: Installation Checklist
Side* 1" / 25 mm 1" / 25 mm CHECKLIST The Regency Gas Insert is installed as listed below. 1) Unit Location - check Clearances to Com- bustibles on pages 6 and 7. 2) Make the gas connections and electrical connection for fan and vent spill switch. -
Page 7: Clearances To Combustible Mantels
4500 ft. follow current CAN/CGA-B149.1. Manifold Pressure Natural Gas 3.8" +/- 0.2" w.c. In U.S.A., for installations above 2000 ft. refer to current ANSI Z223.1 Sc8- Propane 11" +/- 0.2" w.c. 8.1.2a appendix F, for resizing orifice. Regency U41-3 ULTIMATE Gas Fireplace Insert... -
Page 8: Gas Connection
2 feet above any point within 10 feet Draft Hood when pushing the measured horizontally. B-Vent chimneys re- unit into position. Spill T ube quire a 1" clearance to combustibles. Rear screw holes guides Spill T ube Front Regency U41-3 ULTIMATE Gas Fireplace Insert... -
Page 9: Gas Pressure Test
1) Start all exhaust fans in the home and then AERATION SYSTEM close all doors and windows in the room. The Regency Insert incorporates its own inter- nal draft hood, so no additional external draft The burner aeration is factory set but may need 2) Light the unit and set controls to maximum. -
Page 10: Faceplate & Trim Installation
DO NOT BYPASS OR DIS- CONNECT THIS SWITCH. 5) Push the Regency logo plate into the two 9) ON/OFF wires: Hook up the ON/OFF wires holes in the bottom left corner of the face- to the switch on the left side trim. -
Page 11: Log Installation
Note: The door latch Diagram 3 require adjustment as Diagram 2 the door gasket material com- presses after a few fires and after glass replacement. Turn the latch to tighten or loosen the latch. Regency U41-3 ULTIMATE Gas Fireplace Insert... -
Page 12: Optional Remote Control Installation
THERMOSTAT Before leaving this unit with the customer, the installer must ensure that the appliance is firing Use the Regency Remote Control Kit approved A wall thermostat may be installed if desired. correctly. This includes: for this unit. Use of other systems may void Connect the wires as per the wiring diagrams. -
Page 13: Wiring Diagram
This appliance is equipped with a three pronged (grounding) plug for your protection against shock hazard and should be plugged directly into a properly grounded three-prong receptacle. Do not cut or remove the grounding prong from this plug. Regency U41-3 ULTIMATE Gas Fireplace Insert... -
Page 14: Operating Instructions
3) If the control knob is in the "OFF" position proceed to Step 5. 4) Disconnect all electric power to the appli- ance if service is to be performed. 4) Push in gas control knob slightly and turn clockwise to "OFF". Regency U41-3 ULTIMATE Gas Fireplace Insert... -
Page 15: Copy Of The Lighting Plate Instructions
Keep burner and DO NOT REMOVE THIS control compartment clean. See installation and operating INSTRUCTION PLATE instructions accompanying appliance. 908-432 Made in Canada Regency U41-3 ULTIMATE Gas Fireplace Insert... -
Page 16: Normal Operating Sounds Of Gas Appliances
Blower: 2) Clean glass (never when unit is hot), appli- condensation and fog the glass. This con- Regency gas appliances use high tech blow- ance, door and louvers with a damp cloth. densation and fog is normal and will disap- ers to push heated air farther into the room. -
Page 17: Log Replacement
REPLACEMENT 4) Install side retainers. 5) Install door catch plate. Your Regency stove is supplied with high temperature, 5 mm Neoceram ceramic glass that will withstand the highest heat that your 6) Install the 24 nuts loosely, do not tighten yet. -
Page 18: Fan Maintenance
7) Lift fan off of the 2 pins, tip forward and pull cut or remove the grounding through firebox opening. prong from this plug. CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Regency U41-3 ULTIMATE Gas Fireplace Insert... -
Page 19: Parts List
Side Panel Hinge Bracket - Left 613-522 Side Panel Assy - Right 650-528 Side Panel Hinge Bracket - Right 710-028 Faceplate Mounting Bracket 948-241 Door Latch 910-325 Spill Switch 610-576 False Top Assembly 836-220 False Top Insulation Regency U41-3 ULTIMATE Gas Fireplace Insert... - Page 20 Pilot Hood Assy- 3 Flame NG 910-035 Pilot Hood Assy- 3 Flame LP 653-930 Log Set 653-531 Burner Assy 260-565 Air Shutter Gear Assembly (Female) 904-565 Hex Key 3/16" A/F *Not available as a replacement part. Regency U41-3 ULTIMATE Gas Fireplace Insert...
- Page 21 Burner On/Off Switch 910-810 Wire Harness (Faceplate end) 613-919 Faceplate & Trim - Complete - Extra Oversize 101) * Faceplate - Extra Oversize - Side Right 102) * Faceplate - Extra Oversize - Top Assy Regency U41-3 ULTIMATE Gas Fireplace Insert...
- Page 22 _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ ____________________________________________________________ __________________________________________________________ ____________________________________________________________ _______________________________________________________ _____________________________________________________ __________________________________________________________ _________________________________________________________ _________________________________________________________ ______________________________________________________ ______________________________________________________ _______________________________________________________________ ___________________________________________________________ __________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ _____________________________________________________________ __________________________________________________________ __________________________________________________________ _____________________________________________________ ________________________________________________________ _________________________________________________________ _________________________________________________________ Regency U41-3 ULTIMATE Gas Fireplace Insert...
-
Page 23: Warranty
Regency Fireplace Products, are designed with reliability and simplicity in mind. In addition, our internal Quality Assurance Team carefully inspects each unit thoroughly before it leaves our door. Regency Industries Ltd. is pleased to extend this limited lifetime warranty to the original purchaser of a Regency Product. - Page 24 Installer: Please complete the following information Dealer Name & Address: ______________________________________________ __________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: _________________________________________________________ Regency and energy are trademarks of FPI Fireplace Products International Ltd. Printed in Canada © FPI Fireplace Products International Ltd. 2003...
