WARNING:
If the information in these instructions are not followed ex-
actly, a fi re or explosion may result causing property damage,
personal injury or loss of life.
FOR YOUR SAFETY
Do not store or use gasoline or other fl ammable vapors and
liquids in the vicinity of this or any other appliance.
Installation and service must be performed by a qualifi ed
installer, service agency or the gas supplier.
Tested by:
908-727c
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
U41 Gas Insert
MODELS: U41-NG3 Natural Gas U41-LP3 Propane
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
www.regency-fi re.com
Installation Manual
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appliance
Do not touch any electrical switch:
do not use any phone in your build-
ing.
Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas sup-
plier, call the fi re department.
Owners &
07/17/06
Advertisement
Table of Contents
Related Manuals for Regency U41-LP3
Summary of Contents for Regency U41-LP3
- Page 1 908-727c FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4 www.regency-fi re.com MODELS: U41-NG3 Natural Gas U41-LP3 Propane Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference.
- Page 2 fi replace, at the fl ick of a switch. The models U41-NG3 and U41-LP3 of this series have been approved by Warnock Hersey for both safety and effi ciency. As it also bears our own mark, it promises to provide you with economy, comfort, and security for many trouble free years to follow.
-
Page 3: Table Of Contents
REGENCY ULTIMATE GAS FIREPLACE INSERT SAFETY LABEL Safety Labels ... 4 REQUIREMENTS MA Code - CO Detector ... 5 (for state of Massachusetts only) INSTALLATION REQUIREMENTS For your safety ... 6 Gas Pipe Testing ... 6 Specifi cations ... 6 Installation into a Factory Built Fireplace ... -
Page 4: Safety Labels
2000-4500 ft/pi (610-1370m) Maximum Input 34,000 Btu/h (9.96Kwh) Minimum Input 18,000 Btu/h (5.28kwh) PROPANE GAS Model U41-LP3: 0-2000 ft (0-610 m) ONLY Min. Supply Pressure 12" WC/C.E. (3.00kPa) Manifold Pressure High 11" WC/C.E. (2.74kPa) Manifold Pressure Low 2.9" WC/C.E. (0.72kPa) -
Page 5: Requirements
REQUIREMENTS MA Code - CO Detector (for the State of Massachusetts only) 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:... -
Page 6: Installation Requirements
INSTALLATION IMPORTANT: SAVE THESE INSTRUCTIONS The Regency Gas Fireplace must be installed in accordance with these instructions. Carefully read all the instructions in this manual fi rst. Consult the building authority having jurisdic- tion to determine the need for a permit prior to starting the installation. -
Page 7: Materials Required
MATERIALS REQUIRED No electrical power supply is required for the gas control to operate. A 120 Volt AC power cord is hooked up to the fan switch and blower. Plug 3 wire cord into a suitable receptacle. Do not cut the ground terminal off under any circumstances. -
Page 8: Clearances To Combustible Mantels
INSTALLATION Depth (Mx) Clearance (My) System Data For 0 to 2000 feet altitude Burner Inlet Orifi ce Sizes: Natural Gas Burner *Above 2000 ft. see National Code Orifi ce Chart. Max. Input - Natural Gas/Propane 38,000 btu/h Min. Input - Natural Gas/Propane btu/h Min. -
Page 9: Gas Connection
GAS CONNECTION For minimum and maximum supply pressure see the System Data table on page 7. Note: Prior to any pressure testing of the gas supply piping system that ex- ceeds test pressures of 1/2 psig, this appliance and its individual shut-off valve must be disconnected from the piping system. -
Page 10: Gas Pressure Test
INSTALLATION The Regency Insert incorporates its own inter- nal draft hood, so no additional external draft hood is required. Periodically check that the vent is unrestricted and an adequate draft is present when the unit is in operation. (See page 9 for spillage test.) Before installing vent system ensure that the damper plate is locked into the open position... -
Page 11: Faceplate & Trim Installation
shut off the supply of gas within 5 - 10 minutes. Tampering with the switch can result in carbon monoxide (CO) poisoning and possible death. If the heater turns off because of lack of draft during the spillage test, check for the cause and if necessary, seek expert advice. -
Page 12: Log Installation
INSTALLATION LOG INSTALLATION WARNING: Dangerous operating condi- tions may occur if these logs are not po- sitioned in their approved locations. Read the instructions below carefully and refer to the diagrams. If logs are broken do not use the unit until they are replaced. Broken logs can interfere with the pilot and burner operation. -
Page 13: Optional Remote Control Installation
OPTIONAL WALL THERMOSTAT A wall thermostat may be installed if desired. Connect the wires as per the wiring diagrams on page 13. Use table on this page to determine the maximum wire length: Note: Preferable if the thermostat is installed on an interior wall. -
Page 14: Wiring Diagram
INSTALLATION This heater does not require a 120V A.C. sup- ply for operation. In case of a power failure, the burner switch and the optional remote control/ thermostat will continue to operate. However, a 120V A.C. power supply is needed for the fan/blower operation. -
Page 15: Operating Instructions
OPERATING INSTRUCTIONS Before operating this appliance, proceed through the following check list. 1) Read and understand these Instructions before operating this appliance. 2) Check to see that all wiring is correct and enclosed to prevent possible shock. 3) Check to ensure there are no gas leaks. 4) Make sure the three door glass pieces are in place. -
Page 16: Copy Of The Lighting Plate Instructions
OPERATING INSTRUCTIONS COPY OF THE LIGHTING PLATE INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING This appliance must be installed in accordance with local codes, if any; if not, follow the current CAN1-B149/ANSI Z 223.1 (Australia: AG601 / New Zealand: NZS 5261) WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage,... -
Page 17: Normal Operating Sounds Of Gas Appliances
NORMAL OPERATING SOUNDS OF GAS APPLIANCES It is possible that you will hear some sounds from your gas appliance. This is perfectly normal due to the fact that there are various gauges and types of steel used within your appliance. Listed below are some examples. -
Page 18: Log Replacement
MAINTENANCE LOG REPLACEMENT The unit should never be used with broken logs. Turn off the gas valve and allow the unit to cool before opening door to carefully remove the logs. The pilot light generates enough heat to burn someone. If for any reason a log should need replacement, you must use the proper replacement log. -
Page 19: Fan Maintenance
If your fan requires maintenance or replace- ment, access to the fan is through the access panel on the rear wall of the fi rebox. NOTE: the unit MUST NOT be operated without the fan access panel securely in place and correctly sealed. -
Page 20: Parts List
PARTS LIST Part # Description 611-525 Bottom Louver Assy 653-535/02 Top Louver Assy 590-105 Fan Cover 936-196 Fan Cover Gasket 610-517/P Fan Assembly (120 V) 910-157/P Fan Motor 910-794 Power Cord (120 V) 910-770 Wire Harness (stove connection end) 613-520 Side Panel Assy - Left 650-527 Side Panel Hinge Bracket - Left... - Page 21 Part # Description 910-190 Piezo Ignitor and nut 910-426 Knob - Flame Hi/Low Extension 613-524/P Valve Assembly -NG 613-526/P Valve Assembly - LP 910-028 Valve - RS - NG 910-029 Valve - RS - LP 904-688 Orifi ce - #32 NG 904-641 Orifi...
