Summary of Contents for Sirius Range Hoods SUT950
- Page 1 INSTALLATION INSTRUCTIONS CARE AND USE MANUAL FOR: Ceiling Hood Models covered by this instructions: SUT950 - SUT951 *** BEFORE INSTALLATION *** ENSURE THERE IS NO VISIBLE OR HIDDEN DAMAGE SUSTAINED DURING SHIPPING *** SHIPPING DAMAGE *** MUST BE REPORTED WITHIN 5 DAYS OF RECEIPT...
-
Page 2: Installing The Appliance
W A R NI N G Thank you for purchasing a Sirius Range Hood. Please read all the instructions in this manual before installing the appliance. Save these instructions for future reference. Only use this appliance as an exhaust ventilation system for the removal of cooking vapors. -
Page 3: Table Of Contents
TABLE OF CONTENTS BEFORE YOU BEGIN DUCTING ELECTRICAL Electrical Supply INSTALLATION Before the installation Panels opening Installation OPERATING PROCEDURES General Advice Technical data Standard configuration Generating a new transmission code Learning the new transmission code MAINTENANCE Cleaning the Filter Cleaning the Hood WARRANTY... -
Page 4: Before You Begin
B E FOR E Y OU BEG I N The manufacturer declines all responsi- BEFORE YOU BEGIN: It is advisable to test bility in the event of failure to observe the run the range hood before installation. instructions given here for installation, maintenance and suitable operation of BEFORE STARTING –... -
Page 5: Electrical
E LE CT RIC AL WARNING: All electrical work must be Electrical Supply. performed by a qualified electrician. This appliance requires 120V/60Hz, 3amp electrical supply – ensure an ap- Please ensure that the appropriate electri- propriately qualified person completes cal codes or prevailing local building co- the electrical hook-up. -
Page 6: Installation
Fit a false ceiling with an opening that has the following dimensions: SUT950: 1465x965 mm with a minimum distance of 330 mm between the ceiling and the false ceiling; SUT951: 1065x665 mm with a minimum... - Page 7 in case of a larger gap between the hood and the ceiling, you need to use longer threaded bars. Connect the power supply into the metal box placed inside the hood as shown in fig. 7. Open the stainless steel panels and re- move the grease filters in order to avoid damaging them in any way and too al- low installation;...
-
Page 8: Operating Procedures
and connect the air outlet pipe. Do not fix the ducting to the outlet with screws - use DUCT TAPE; place the ceiling-mounted hood into the niche, the outer edge of the hood needs to be perfectly flush with the false ceiling. Insert the plates and nuts provided on the threaded bars, making sure to tighten them securely, as shown in Fig. -
Page 9: Technical Data
SUT950 - SUT951 TECHNICAL DATA: Alkaline battery powered: 12v mod. 23A Remote control Operating frequency: 433.92 Mhz Combinations: 4096 A: At every selected function, the led li Max. consumption: 25Ma ghts on accordingly. B: To increase the speed. Operating temperature: -20°... -
Page 10: Maintenance
Warning The battery should be repla- Filter requires washing indicator: after ced every year to guarantee the optimal 30 hours of use, all the buttons will li- range of the transmitter. To replace the ght up to remind you that the grease filter exhausted battery, take the plastic lid should be cleaned. - Page 11 FOR SUT950 - SUT951 Turn blower and lights off. Make sure the lights are cool. If new lights do not operate, check fuses and be sure globes and breakers are in- serted correctly. Do not remove the entire fixture (socket) as this is very difficult to reinstall.
-
Page 12: Warranty
Three Year Limited Warranty YOU MUST REGISTER THE PURCHASE OF YOUR PRODUCT ON LINE AT www.siriuscappe. com/usa/warranty.htm TO CONVALIDATE YOUR WARRANTY. YOU CAN FIND THE DATA OF YOUR HOODS ON A LABEL INSIDE THE HOOD. JUST REMOVE THE GREASE FILTER TO READ IT. WARRANTY SERVICE To qualify for warranty service, you must notify Sirius After sale service at the email ad- dress stated below or call toll free USA 1-877-474-8770 and provide the model number,...
