Parts List

1. Blades
2. Blunt plate
3. Protective guard
4. Silencer cover
5. Spark plug cover
6. Spark plug (not shown)
7. Front handle
8. Recoil starter
18
17
1
AFTER SALES SUPPORT
9. Air filter cover
10. On/Off switch
11. Throttle trigger
12. Fuel tank
13. Fuel cap
14. Safety lever
15. Rear handle
16. Throttle start button
21
19
20
2
10
1800 909 909 www.powertoolsupport.com
A U S
17. Primer bulb
18.Choke lever (red)
19. Rotating handle
lock lever
20. Rotating handle
21. Grease nipple
22. Blade cover
5
4 8
7
3
22
email: help@powertoolsupport.com 11/2015
3
10 11 14 15
16
12
9 13
