TORK MODEL EWZ101/103/120
7 DAY DIGITAL TIME SWITCH
READ INSTRUCTIONS CAREFULLY BEFORE ATTEMPT-
ING TO INSTALL TIME SWITCH. SEE WARNING ON
FRONT PANEL – Failure to comply with instructions
could result in personal injury and/or property damage.

INSTALLATION:

UNIT IS TO BE INSTALLED BY A LICENSED ELECTRICIAN
1. To remove unit from enclosure: Push the tab on right
to swing unit the left and remove.
2. Mount the enclosure at eye level using screws or
other suitable fastening device. Bring supply and load
wires in through or side knockouts. DO NOT USE
TOP.
3. Reinstall unit by reversing step #1 above and con-
necting wires to units as per suggested wiring dia-
grams. See illustration and warning on back page.

CAPABILITIES

- 7 Day scheduling.
- ON and OFF set points:
Total # - 20 per week
- Minimum setting – 1 minute
- Capable of different schedules each day of the week
- Astronomic Option. For automatic ON at sunset, OFF
at sunrise for outdoor lighting.

FEATURES

Daylight Saving
Leap Year
Display
Manual Override
Power Outage
10:18 PM Page 3
Automatic (can be adjusted).
Automatic compensation.
LCD
Until the next schedule ON or OFF.
Automatic operation then resumes.
Permanent schedule retention
Super capacitor maintains real
time up to 4 days.
1
