TORK DGM100
DIGITAL TIME SWITCH
READ INSTRUCTIONS CAREFULLY BEFORE SETTING UNIT

FEATURES

Single channel controller
7 day scheduling
Special day scheduling
32 set points
2 second momentary output for use with low voltage
latching relays, mechanically held contactors, electri-
cally (magnetically) held contactors.
Battery back-up uses standard 9 volt non-recharge-
able (not supplied). Lithium averages 450 hours of
power outage; Alkaline averages 175 hours
Manual override to the next scheduled event
Automatic daylight saving - user selectable
Automatic leap year compensation
AM/PM or 24 hour format - user selectable

INSTALLATION

UNIT IS TO BE INSTALLED BY A LICENSED ELECTRICIAN
Unit contains 2 SPDT relays. Left relay will close
for 2 seconds between C & NO when an ON pulse
is scheduled. Right relay will close for 2 seconds
between C & NO when an OFF pulse is scheduled.
NOTE: C & NC of right relay is used to OPEN elec-
trically held contactors.
1. To remove unit from enclosure: Push tab on right
to swing unit to the left and remove.
2. Mount the enclosure at eye level using screws or
other suitable fastening device. Bring supply and
load wires in through bottom or side knockouts.
DO NOT USE TOP.
Input wires to controller must be dedicated i.e. no
other loads connected to the same circuit.
SEVEN DAY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DGM100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tork DGM100

  • Page 1 ____________________________________________ http://waterheatertimer.org/Tork-Digital-timers-and-manuals.html TORK DGM100 DIGITAL TIME SWITCH SEVEN DAY READ INSTRUCTIONS CAREFULLY BEFORE SETTING UNIT FEATURES Single channel controller 7 day scheduling Special day scheduling 32 set points 2 second momentary output for use with low voltage latching relays, mechanically held contactors, electri- cally (magnetically) held contactors.
  • Page 2 3. Install a standard 9 volt lithium or alkaline battery (not supplied) by gently squeezing the right side of the battery cover on the front of the unit and pull to open. Pull out the battery connector and con- nect the battery. Reinstall battery cover. Lithium should be replaced every 3-5 years, Alkaline every year.
  • Page 3 ON/OFF: Pressing each time will select ON or OFF pulse. Multiple OFF pulses may be scheduled to can- cel override ON pulses. ENTER: Press to store the displayed information into memory. Information will not be stored until ENTER is pressed. NOTE: During settings, each press of the key will advance one number.
  • Page 4 TO SET CLOCK Press MODE key; display shows CLK. Press DAY/MONTH key to select today’s day. Press HOUR key to set present hour (check AM/PM). Press MIN key to set present minutes. Press ENTER key. Unit now stores present time. Seconds are set to zero. DAYLIGHT SAVING The user may select either standard U.S.
  • Page 5 Press MONTH key to set present month. Press DATE key to set today’s date. Press YEAR key to set present year. Press ENTER key. Unit now stores present date. Note: If unit has correct entry for the calendar, then the unit will go into the SET mode. If the calendar has an incorrect entry, then the unit will stay in the DATE mode, with MM--YY displayed, signifying that the date does not correspond with the month, and/or...
  • Page 6 Display will now show —:—02. This tells you that the first event has been entered, and that the unit is ready to accept the second entry. Repeat above steps 1 to 4 to set more schedule events Note: When the unit is returned to the run mode, check the load status of the current setting.
  • Page 7 RUN mode. The load status will flash indicating that this is a change from a scheduled event. In order to cancel the override, press override key again. ® TORK MLI-98(A) 1 GROVE STREET, MT. VERNON, NY 10550 TEL: 914-664-3542 FAX: 914-664-5052...
