Wizard Setup
IP Configuration
IP Address
Mask
DNS
PPP Configuration
PPP
Dial-on-
Demand
Idle Time Out
Dial Number
Init String
PPP Authentication
Authentication Type
User Name
Password
A Note About the Access Point Name
The APN (Access Point Name) is assigned by your GPRS or EDGE wireless service provider, but
you may have to ask for it. An access point is an IP network to which a wireless modem connects.
The Web Management software asks for the APN on the Wizard Setup screen and the PPP screen.
5. Click the Submit button.
6. Click the Save & Restart button.
IMPORTANT NOTE ABOUT SUBMIT AND SAVE & RESTART
Click the Submit button located at the bottom of most screens in order to save any changes you make.
Then you must click the Save & Restart button, located on the Menu bar, in order for your settings to take
effect. Save & Restart does not have to be executed after each screen; you can change and Submit
several screens, and then click Save & Restart.

Step 8. Set Time and Date

The date and time must be set using the Web Management software.
The time and date set in IP Setup will not be correct unless SNTP client is enabled and you have a live
Internet connection. See SNTP client.

Shutdown Caution

Never unplug the power until you have first performed the Save & Reset process. If the
setup changes are not properly saved before unplugging the power, data could be lost.
Multi-Tech Systems, Inc. MultiModem Wireless Modem with Ethernet Interface (S000375B)
The default is 192.168.2.1. To change it, simply enter your own IP
address.
The default is 255.255.255.0
Enter the primary DNS IP address for the system. The default is 0.0.0.0
Click Enable to activate PPP. You will want to enable the PPP
functionality for the PPP dialer to operate.
Click Enable to activate dial-on-demand feature.
If you Disable dial-on-demand, the modem always stays connected.
Sets the amount of time the PPP link stays active before disconnecting.
Setting the value to zero causes the link to stay active continuously.
Enter the dial number. This number connects you to the Internet.
For GPRS and EDGE, the number is *99***1#.
For CDMA, the number is #777
You can set up to 5 modem initialization strings.
For GPRS and EDGE: Include the Access Point Name by typing:
AT+CGDCONT=1,"IP","<APN>"
Note: The APN (Access Point Name) is assigned by your wireless service
provider.
Click the button corresponding to the authentication protocol you want to
use to negotiate with the remote peer. PAP, CHAP, or PAP-CHAP.
Default = PAP-CHAP
Enter the PPP User Name. This name authenticates the remote peer. The
default is ipmodule.
Enter the PPP Password. This password authenticates the remote peer.
The default is ipmodule.
Chapter 2 – Getting Started
19
