Bluetooth Antenna Requirements
Frequency Range
Impedance
VSWR
Gain
Radiation
Polarization
Wave
Connector
An antenna that meets the requirements for use with the SocketWireless product can be ordered, for example,
from Nearson.
www.nearson.com
Part number: S131AH – 2450S
Multi-Tech Systems, Inc. MultiModem Wireless EDGE, GPRS, & CDMA Modem with Bluetooth (S000390B)
2.4-2.5 Ghz
50 ohm nominal
<2.0:1
2 dBi
Omni
Vertical
Half Wave Dipole
Reverse Polarity SMA Plug
Chapter 5 – Wireless Antennas
17
