Installation
This is an example of a typical setup.
Serial-to-Ethernet Power Connections
The Adapters are powered in one of two ways:
Powered by External Power Supply
Adapter Ethernet Connector
Adapter RS-232 & External Power Connectors
Multi-Tech Systems, Inc. MultiConnect Serial-to-Ethernet Adapter User Guide (S000344D)
MTS2EA
Chapter 2 – Installation
Powered through RS-232 Cable (Pin 6)
MTS2EA-R
Adapter Ethernet Connector
Adapter RS-232 Power Pin Connector
10
