Specifications
Category
Memory
Flash Memory
Protocols Supported
WAN Interface
Serial Interface
Data Formats
Data Rates
Flow Control
Management
Security
System Software
LEDs
Ethernet
Power Requirements
Operating Temperature
Storage Temperature
Physical Dimensions
Certifications
Multi-Tech Systems, Inc. MultiConnect Serial-to-Ethernet Adapter User Guide (S000344D)
Description
8 MEG
2 MEG
ARP, DHCP, Telnet, UDP, TFTP, PPP, HTTP, SMTP, POP3, FTP, SNTP, RAW
UDP/TCP, ICMP, IP, TCP, SNMP
10/100BaseT Ethernet
Standard DCE Serial
Serial, binary, asynchronous
300; 1200; 2400; 4800; 9600; 19200; 38400; 57600; 115200; 230400 bps
RTS/CTS (hardware)
Serial; Telnet; Web
Username and password authentication using local database
Flash ROM standard: downloadable from a TCP/IP host (TFTP) or Xmodem via
Serial
Link, Activity, Speed, Status, Power
IEEE 802.3
With External Power (MTS2EA) Power Consumption
@ 9V DC:
Typical 250mA
With RS-232 Power (MTS2EA-R) Power Consumption
@ 5V DC:
Typical 190mA
@ 10V DC:
Typical 100mA
@ 15V DC:
Typical 69mA
@ 20V DC:
Typical 54mA
@ 25V DC:
Typical 45mA
32° to +104°F (0° to 40°C); humidity range 25-85% (non-condensing)
-40°C to +85°C
3.5" w x 2.1" h x 0.98" d; 3.4 oz.
8.8 cm x 5.3 cm x 6 cm; 96 g
Safety Certifications:
UL60950
cUL60950
EN60950
ACA TS001 / AS 3260
EMC Safety Approvals:
FCC Part 15 Class A
EN55022
EN55024
CE Marked
Chapter 1 – Product Description & Specifications
Maximum 305mA
Maximum 245mA
Maximum 120mA
Maximum 83mA
Maximum 65mA
Maximum 55mA
6
