the diagram above to attach the external devices to the connector
block. Attach the connector block to the terminal connector on the
camera.
2 Basic Connection (Without PoE)
2.1 Connect the camera to a switch using a standard Ethernet cable.
2.2 Connect the power adapter from the camera to a power outlet.
Note: DC12V 1A power adapter is required.
3 Power over Ethernet (PoE) Connection
3.1 The CB-101A is PoE compliant, so there are two options for
connecting the camera to a power and Ethernet source. The
camera can either be connected to a PoE-enabled switch or a
non-PoE switch.
A. If using a PoE-enabled switch:
1. Use a single Ethernet cable to connect the camera to the
PoE-enabled switch.
