Installation - Glow-worm Swift flow 100 Installation Instructions Manual

1.1 Installation

Materials and equipment should be fit for their purpose
and of suitable quality and workmanship.
1.2 Important Notice
This boiler is for use only on natural gas.
This boiler will supply central heating, only when an
external time clock provides a mains live and neutral
supply to pins 1 and 2 on the mains connection plug, see
diagram 9.2.
1.3 Sheet metal Parts
WARNING. When installing the appliance, care should
be taken to avoid any possibility of personal injury when
handling sheet metal parts.
1.4 Requirements
The installation of this boiler must be carried out by a
competent person in accordance the rules in force in the
countries of destination.
This appliance must be installed so as to comply with
the requirements of the Australian Gas Association
Installation Code A.G. 601, Australian standard A.S.
3500.4, the manufacturers instructions and any local
authority regulations.
TABLE 2
Lift Weight
Total Weight
Gas connection
Heating and return
Domestic hot water
Safety valve C.H.
Safety valve D.H.W.
Safety valve discharge
Water content
Expansion vessel capacity 8 litres
Heating cold fill
pressure minimum
Ball valves are fitted in water and gas connections, plus a drain point on all water connections.
Boiler starts at an inlet pressure of 0.05MPa but requires 0.08MPa for maximum output.
For larger systems use an additional expansion vessel, see Section 4.
1 G e n e r a l
37.0kg
50.4kg
Rc 1 / ( 1 / in BSPT)
2 2
22mm compression
15mm compression
Preset 0.3MPa (43.5lbf/in
Preset 1.4MPa (203lbf/in 2
15mm copper
1.74 litres
0.07 MPa
1.5 Data Label
The data label is on the inner case cover.
1.6 Data
See Tables 1 and 2
TABLE 1
NOMINAL
HEAT
INPUT MJ/h
NOMINAL
HEAT
OUTPUT kW
BURNER k Pa
PRESSURE
APPROX. m 3 /h
GAS RATE
D.H.W
working pressure
Maximum Heating
system water
content using
fitted expansion
vessel.
2 )
)
Electrical supply
Electrical rating
Internal Fuse rating
3
C.H. Max D.H.W Max MIN
81 125 46
17.6 27.8 9.2
0.34 0.82 0.11
2.0 3.2 1.1
0.5 to 1.0 MPa
119 litres
with a cold
fill pressure
of 0.07 MPa
240V~50Hz
150W fused 3A
1) Type T1.6A
2) Type T630mA
221017B
