Installation Instructions

Fanned Flue Combination Boiler
One Contact Total Service
To b e l e f t w i t h t h e u s e r
This is a Cat I
Customer Services:
Tel: (01773) 828100
Fax: (01773) 828070
75
G.C. No. 47 313 14 Honeywell
G.C. No. 47 313 15 SIT
Appliance
2H
Hepworth Heating Ltd.,
Nottingham Road, Belper, Derbyshire. DE56 1JT
General/Sales enquiries:
Tel: (01773) 824141 Fax: (01773) 820569
221129A.05.97
