Installation Instructions
Digital Clock/Timer
Kit Style 2
This is a Cat I
These instructions are for the installation and setting of
the digital clock/timer Style 2.
Instructions on how to use and service are supplied with
the boiler.
Note. The boiler Installation Instructions will be
required should the clock/timer be fitted to an already
fitted boiler.
If the literature is not to hand, copies can be obtained
from:-
Hepworth Heating Ltd
Nottingham Road
Belper
Derbyshire
DE56 1JT
Telephone 01773 824141.
It is important to quote the model, size and serial
number.
One Contact Total Service
T o b e l e f t w i t h t h e u s e r
Appliance
2H
Customer Services:
Tel: (01773) 828100
Fax: (01773) 828070
100e 80e 75e
100
80 75
Hepworth Heating Ltd.,
Nottingham Road, Belper, Derbyshire. DE56 1JT
General/Sales enquiries :
Tel: (01773) 824141 Fax: (01773) 820569
221062A.02.97
