Glow-worm Swift flow 80 Instructions For Use Installation And Servicing

Fanned flue combination boiler g.c. no. 47 313 10 honeywell g.c. no. 47 313 09 s.i.t
Hide thumbs Also See for Swift flow 80:
Table of Contents

Advertisement

Quick Links

See also: Instruction and Installation Manual
Installation and Servicing
80
Fanned Flue Combination Boiler
The instructions consist of three parts, User, Installation and Servicing Instructions which includes the
Guarantee Registration Card. The instructions are an integral part of the appliance and must, to comply with the current issue of
the Gas Safety (Installation and Use) Regulations, be handed to the user on completion of the installation.
Glow-worm appliances' are manufactured to the very highest standard so we are pleased
In the center pages are to be found your Guarantee Registration Card, which we recommend you complete and
If this card is missing you can obtain a copy or record your registration by telephoning the Heatcall Customer
Our Guarantee gives you peace of mind plus valuable protection against breakdown by covering the cost of:
All replacement parts
All labour charges
All call-out charges
One Contact Local Service
Instructions for Use
T o b e l e f t w i t h t h e u s e r
G.C. No. 47 313 10 Honeywell
G.C. No. 47 313 09 S.I.T
This is a Cat I
Appliance
2H
Guarantee Registration
Thank you for installing a new Glow-worm appliance in your home.
to offer our customers' a Comprehensive First Year Guarantee.
return as soon as possible.
Service number 01773 828100.
REGISTER YOUR GLOW-WORM APPLIANCE
FOR 1ST YEAR GUARANTEE PROTECTION
CALL 0181 380 2555
Customer Services:
Tel: (01773) 828100
Fax: (01773) 828070
Hepworth Heating Ltd.,
Nottingham Road, Belper, Derbyshire. DE56 1JT
General/Sales enquiries:
Tel: (01773) 824141 Fax: (01773) 820569
221469B.03.99
