- Page 1 IP Phone 2007 User Guide BCM50 2.0 Business Communications Manager Document Status: Beta Document Version: 01.01 Part Code: NN40050-109 Date: June 2006...
- Page 2 Nortel Networks. Trademarks Nortel, the Nortel logo, and the Globemark are trademarks of Nortel Networks. Microsoft, MS, MS-DOS, Windows, and Windows NT are registered trademarks of Microsoft Corporation. All other trademarks and registered trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
Program soft keys ..........20 IP Phone 2007 User Guide... - Page 4 Contents For more information ..........20 NN40050-109 NN40050-109...
-
Page 5: Getting Started With The Business Communications Manager 50
Getting started with the Business Communications Manager 50 The Nortel Business Communications Manager 50 brings voice and data capabilities to the desktop by connecting directly to a local area network (LAN) through an Ethernet connection. The Business Communications Manager 50 supports call processing features and can work with an External Application Server to display Web-based and interactive applications on the large, color LCD touch panel. -
Page 6: Business Communications Manager 50 Buttons, Display, And Lights
Chapter 1 Getting started with the Business Communications Manager 50 Business Communications Manager 50 Figure 1 Business Communications Manager 50 buttons, display, and lights Figure 2 shows the Business Communications Manager 50 buttons, display, and lights. Table 1 gives a description of the buttons, display, and lights identified in Figure NN40050-109... - Page 7 Allows you to scroll through lines of text and menu items, such as those listed in Services or the Call Log. Soft key buttons (either side of Navigation key) Labels on the bottom of the LCD give the meaning associated with these keys. IP Phone 2007 User Guide...
-
Page 8: Business Communications Manager 50 Lcd
Chapter 1 Getting started with the Business Communications Manager 50 Message Waiting Indicator Flashes when a call rings at the telephone. Lights up when Message for you appears on the display. Color LCD The color LCD contains the soft keys and information areas. Tap a soft key with the stylus to activate the feature displayed. -
Page 9: Programmable Line (Dn)/ Feature Soft Key Area
Soft key area The soft key area shows the Feature soft key and three additional display soft keys. These labels vary depending on the feature in use. You cannot reprogram these soft keys. IP Phone 2007 User Guide... -
Page 10: Feature Keys Area
Tap this icon to access the Telephone screen. Use this soft key to access the first registered external application. The icon displayed on the key is that of the application. The Nortel globemark is an example of an icon. NN40050-109... -
Page 11: About Your Programmable Soft Keys
Stylus You can operate the touch panel using a stylus or your finger. However, it is recommended that you use only a stylus to avoid damage to the touch panel and to ensure accuracy. IP Phone 2007 User Guide... -
Page 12: To Clean The Touch Panel
Chapter 1 Getting started with the Business Communications Manager 50 To clean the touch panel Press and hold down the Goodbye button While you hold down the Goodbye button, gently clean the touch panel with a soft, dry cloth. Note: While you hold down the Goodbye button, pressing on the touch panel does not activate features. -
Page 13: Enter Text Using The Telephone Dialpad
This section describes the Business Communications Manager 50 display features: • Display contrast • Language choice • Ring type Note: For more information about the features available to your telephone and how to use them, refer to the BCM50 Telephone Feature Card. IP Phone 2007 User Guide... -
Page 14: Display Contrast Level
Chapter 1 Getting started with the Business Communications Manager 50 Display contrast level Adjust the contrast for the telephone display. Feature Enter *7 using the telephone dialpad. to view the levels. DOWN to select a level. Language choice Select the Primary Language for the telephone display. Feature Enter *501 using the telephone dialpad. -
Page 15: Ring Type
Select a different ring type for your telephone. Feature Enter *6 using the telephone dialpad. Press 1, 2, 3, 4 (on the telephone dialpad), or to hear the different ring types. NEXT to store the ring type. IP Phone 2007 User Guide... - Page 16 Chapter 1 Getting started with the Business Communications Manager 50 NN40050-109...
-
Page 17: Features And Soft Keys
Lift the handset. Tap a line soft key. Dial the external telephone number. To make external calls using intercom soft keys Lift the handset. Tap an intercom soft key. Enter a line pool access code. IP Phone 2007 User Guide... -
Page 18: Answer Calls
Chapter 2 Features and soft keys When you hear an external dial tone, dial the external telephone number. Note: Contact your system administrator for a list of line pool codes. When entering a line pool access code on PRI lines, you do not hear dial tone. -
Page 19: Mute
Programmable line (DN)/feature soft keys store internal and external numbers or features to give you one-touch dialing or feature activation. Refer to “Business Communications Manager 50 buttons, display, and lights” on page IP Phone 2007 User Guide... -
Page 20: Program Soft Keys
Chapter 2 Features and soft keys Program soft keys You can program a programmable line (DN)/feature soft key with a new number or feature. To program external autodial Tap Feature. Enter *1 using the telephone dialpad. Tap a memory soft key. Dial the external number.
