IP Telephony Clients

IP Phone 2007 Firmware Release Notes

Product Release:
Document Version:
Document Release Date:
0621C23
1.0
July 19, 2005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2007 and is the answer not in the manual?

Questions and answers

Related Manuals for Nortel 2007

Summary of Contents for Nortel 2007

  • Page 1: Ip Phone 2007 Firmware Release Notes

    IP Telephony Clients IP Phone 2007 Firmware Release Notes Product Release: Document Version: Document Release Date: 0621C23 July 19, 2005...

  • Page 2: Table Of Contents

    Version 1.00 Table of Contents Table of Contents ... 1 IP Phone 2007 Firmware Release Notes ... 4 Release Date... 4 History... 4 Applicable Hardware ... 4 Purpose of this Firmware ... 4 Identification ... 4 Image Size... 5 Firmware Upgrade ... 5 Method 1: Automatic UFTP Download Initiated by Server...
  • Page 3 Changes in C11 (from C10):... 24 Changes in C10 (from C09):... 24 IP Phone 2007 Feature Description... 26 The following is a list of the major features implemented in the IP Phone 2007 (some are hardware features)... 26 Call Processing... 26 Touch Panel ...
  • Page 4 Dial Digit in Text Based XAS ... 29 Video... 29 XAS Text-based Net6 ... 29 Features Not Implemented in this Release ... 29 CR’s Opened... 29 Bug Reporting ... 29 C23 Firmware for Verification IP Phone 2007 Firmware Release Notes Page 3 July 19, 2005...

  • Page 5: Ip Phone 2007 Firmware Release Notes

    Based on the previous release: 0621C22. Applicable Hardware This firmware is intended to run on the IP Phone 2007 NTDU96, Sample C, D or newer hardware. This firmware cannot run on any other existing hardware. This firmware no longer supports sample B hardware.

  • Page 6: Image Size

    2) Re-programming using the JTAG port Important Note: The TFTP download and upgrading of the IP Phone 2007 Flash memory takes a while. Please be patient. Do not unplug or reboot the phone during the process! The TFTP file transfer takes about 20 seconds, followed by another 2.5 minutes to burn the file into the Flash memory;...
  • Page 7 The configuration file can be created with a default filename like “i2007.img”, so that the i2007.cfg file does not have to be changed each time a new IP Phone 2007 firmware is released. However, if the default filename is used, when copying the new firmware file to the TFTP directory, users must rename the released firmware file –...

  • Page 8: Method 3: Manual Bootc Tftp Firmware Upgrade Procedure

    1. Put the file i2007.img on a TFTP server. The file name must be fixed in this method. 2. Hold down the [Up] and [2] keys, and while doing so, re-power the IP Phone 2007. When the IP Phone 2007 re-starts, it loads and runs BootC instead of the Application. A simple, non- graphic text menu on white background should be displayed.

  • Page 9: Powering

    XAS Configuration The IP Phone 2007 allows either a text XAS or a graphical XAS session, not both. This is a limitation of the Citrix AG. The extra GXAS IP address was removed from the configuration in version C17 in response to this limitation.

  • Page 10: Password Protection Of The Tools Menu

    Graphical XAS check box and select "Apply and Reset". This restores the text XAS. If the XAS IP address is set to 0.0.0.0, the IP Phone 2007 will not attempt to register to the AG. When the Citrix graphical XAS server software is released and installed on the AG, each user will need to go to the Tools >...
  • Page 11 Note: the S4 set of data items is actually the third group of server data items in the Full DHCP string. S3 is used in internal messaging between the TPS and the IP Phone 2007 and thus is not in the DHCP string.

  • Page 12: Eap Configuration And Statistics

    IP phone “sees”. This feature only works if the IP Phone 2007 is configured on a voice VLAN. If the filter is turned on but the IP Phone 2007 is not configured for VLAN, then the IP Phone 2007 can not register to the TPS.

  • Page 13: New Features And Changes By Build (Summary)

    The RFB code falsely reported itself to the GXAS server as a little endian architecture, when in fact it was big endian. These false reports caused the IP Phone 2007 to manually swap all the pixel color bytes delivered by the server. With the architecture now specified as big endian, the byte swapping occurs on the server instead, where the processing power resides.

  • Page 14: Citrix Related Fixes

    The IP Phone 2007 now handles hookswitch synchronization with the TPS, according to document. • If the GXAS server does not specify a transducer, then the IP Phone 2007 remembers and selects the last transducer used. • The IP Phone 2007 handles headset connection/disconnection for GXAS audio.

  • Page 15: Cr Fixes Inherited From The Ip Phone 200X Platform

    Version 1.00 CR Fixes Inherited from the IP Phone 200x Platform: The IP Phone 2007’s C22 is equivalent to D98 firmware, minus the following feature content and CR fixes: • IP Call recording (in conflict with GXAS audio) and related CR Q01105003, Q01149451, and Q01141470 •...

  • Page 16: Citrix Related Fixes

    Q01136879 Beta: The IP Phone 2007 does not complete the boot-up sequence when VLAN is defined as AUTO (solved by inclusion of Q00989473-01). CR Fixes Inherited from the IP Phone 200x Platform: The IP Phone 2007’s C20 is equivalent to D97 firmware, minus the following feature content and CR fixes: •...

  • Page 17: Changes In C19 (From C18)

    The "VoiceVLAN:" prompt field is widened so that the colon (:) is not longer truncated. Citrix Related Fixes • The IP Phone 2007 now properly handles the hold button, so that any active call remains on hold when outside the phone application. •...

  • Page 18: Ip Phone 2007 Crs Fixed

    Q01094346: The Phase 2 D88 incorrectly reported Latency, which caused too many false QoS messages. CR Fixes Inherited from the IP Phone 200x Platform: The IP Phone 2007’s C19 is equivalent to the D97 firmware, minus the following feature content and CR fixes: •...

  • Page 19: Changes In C18 (From C17)

    Q01085763: Users can initiate a page with the IP Phone 2007 on hold. • Case 050223 - 65764: The IP Phone 2007 switches back to TPS when done. • Case 050225 - 68536: The message waiting key turns off during an XAS session.

  • Page 20: Changes In C17 (From C16)

    • Q01083591: The Ping IP entry problem is resolved. • Q01092391: The integrated WindRiver patch resolves the problem of the IP Phone 2007 getting stuck at the DHCP stage of bootup. • Q01091187: The Network Configuration menu now disables the fields that the DHCP server fills in when DHCP is set to Full or Partial.

  • Page 21: Cr Fixes Inherited From The Ip Phone 200X Platform

    TPS can now query and receive the last reset reason code. • Q01018457: A QoS issue, IP Phones 2007 in a congested, low priority network did not reconnect to the S1/S2. The fix sets the default DSCP value to 0x28 when sending the “connect to server”...

  • Page 22: Changes In C15 (From C14)

    Q01101861 - CIVO:MCS4.0:PC Client Set Phase 2 IP Phone 2004 Beeps After # Is Entered When Dialing). • A UART function call caused problems for CICM. The IP Phone 2007 does not support KEM, and so the KEM is not init in code. •...

  • Page 23: Cr Fixes Inherited From The Ip Phone 200X Platform

    Q01068743, Q01040558: Swapping active calls resulted in lost indication of ongoing calls. A check of the LED state before toggling solves the problem. • Q01084377: The IP Phone 2007 display flashed and showed too dark. The minimum brightness level is raised to prevent both flickering and darkness. •...

  • Page 24: Cr Fixes Inherited From The Ip Phone 200X Platform

    – still do not accept the star (*) in IP address entries. • The new Nortel splash logo – This is the way, this is Nortel - is now displayed according to the contrast and brightness settings contrast of the EEPRM map.

  • Page 25: Changes In C11 (From C10)

    • A problem with the flash file system caused the IP Phone 2007 – with C10 firmware – to crash on startup. This problem occurred when the user changed the button customization tool to use custom text labels, then power cycled the IP Phone 2007; the phone then crashed, and remained in that state until upgraded to C11 or above.
  • Page 26 A problem occurred in the touch panel calibration screen when attempting to jump to the IP Phone 2007 application. • The Flash File system semaphore loading problem (related to speed of access) is fixed. C23 Firmware for Verification IP Phone 2007 Firmware Release Notes Page 25 July 19, 2005...

  • Page 27: Ip Phone 2007 Feature Description

    IP Call recording, which conflicts with GXAS audio. Touch Panel The IP Phone 2007 supports point and click with stylus. It does not support dragging. Touch Panel Calibration This feature keeps the analog system from causing errors in coordinates. Access the calibration tool through the Tools menu.

  • Page 28: Bluetooth

    Phone 2004. Users access the new graphical Network Diagnostic Tool from the Tools menu. Network Configuration Since the IP Phone 2007 has no physical softkeys, it uses a different procedure to access the Network configuration menu during bootup. On the IP Phone 2007, press [0], [0], [7], [*] at the Nortel Networks prompt.

  • Page 29: G-Xas Graphical Citrix (Net 6)

    Prime key, keeping the key from remaining blank. Figure 1: BCM Display below shows an example of the Prime key; with Nortel as the prime external application, the Globe logo shows on the Prime key.

  • Page 30: Mouse Or Touchpanel Click

    G-XAS. It is up to the G-XAS to respond Text Entry Use the offered dialogs to enter text into the pop-up or the USB keyboard. The IP Phone 2007 sends the entered text to the G-XAS.
