Charnwood Island I Operating & Installation Instructions Manual
Hide thumbs
Also See for Island I:
- Operating and installation instructions (17 pages) ,
- Operating and installation instructions (17 pages) ,
- Operating and installation instructions (16 pages)
Subscribe to Our Youtube Channel
Related Manuals for Charnwood Island I
Summary of Contents for Charnwood Island I
- Page 1 ® charnwood I S L A N D Operating & Installation Instructions Version AZ, BZ, CZ...
-
Page 3: Table Of Contents
Health & Safety Precautions Specification CO Alarms Chimney Hearth & Fire Surround Connection to Flues Soot Doors Pre Lighting Check Commissioning Island I Dimensions Island II Dimensions Island III Dimensions Parts Lists 14 - 16 Certification Ref. Island I.II.III z 06.14 Rev. 1... -
Page 4: Operating Instructions
Take care not to touch the doors as they will be hot when the fire is burning. Turn the door handle clockwise to open, and anti-clockwise This stove is not designed to burn household waste. For advice on to close. The stove is normally run with the doors shut. other fuels please contact Charnwood. -
Page 5: Multi Grate
® Fig. 3 Air control MULTI GRATE Your Charnwood Island is fitted with a multi grate to enable wood to Air control handle be burned and ash to be cleared. The grate has two positions: 1) In the open position the grate bars are vertical with gaps in... -
Page 6: Lighting
OPERATING INSTRUCTIONS I S L A N D ® Fig. 6 Adding larger logs LIGHTING On initial lighting, the stove may smoke and give off an odour as the silicon paint with which the firebox is painted reacts to the heat. This is normal and will cease after a short time, but meanwhile the room should be kept well ventilated. -
Page 7: Refuelling
Charnwood. parts that are beginning to show signs of wear. Check that the doors seals are in good condition and that the doors seal correctly. -
Page 8: Chimney Sweeping
OPERATING INSTRUCTIONS I S L A N D ® CHIMNEY SWEEPING glass to blacken. The chimney should be swept at least once a year. Where a top d) There is a bypass slide that can be adjusted to suit the particular outlet is used it will generally be possible to sweep the chimney installation. -
Page 9: If You Need Further Help
Expert advice should be sought if necessary. IF YOU NEED FURTHER HELP If you need further help with your Charnwood Island then your Installer will be able to provide the answers to most questions. Your Local Charnwood Premier Dealer has a great deal of experience and will also be able to provide helpful advice. -
Page 10: Installation Instructions
SPECIFICATION can be used either internally or externally. These chimneys must be fitted in accordance with the manufacturers instructions and Building Specification Island I Island II Island III Regulations. Anki pumice liners or chimney blocks will give a highly insulated Output kW 12.0... -
Page 11: Hearth & Fire Surround
INSTALLATION INSTRUCTIONS I S L A N D ® HEARTH AND FIRE SURROUND Fig. 9 Vertical Register Plate With Bricked Up Fireplace Soot Door The stove arrives bolted and shrink-wrapped to its pallet which is In Side or Rear intended to be cut up and used for kindling fuel. -
Page 12: Soot Doors
INSTALLATION INSTRUCTIONS I S L A N D ® Fig. 12 Horizontal Register Plate With Optional Vertical Rear Flue Connector Alternative Soot Door Positions Register Plate With Soot Door 158mm Island 1 & 2 197mm Island 3 SOOT DOORS... -
Page 13: Island I Dimensions
ISLAND I DIMENSIONS (mm) I S L A N D ® charnwood I S L A N D Flue outlet to suit 150mm (6") flue pipe Optional Vertical Rear Flue Adapter TOP VIEW Optional External Air Manifold Max dim. with door open = 601... -
Page 14: Island Ii Dimensions
ISLAND II DIMENSIONS (mm) I S L A N D ® ® charnwood I S L A N D Flue outlet to suit 150mm (6") flue pipe TOP VIEW Optional Vertical Rear Flue Adapter Optional External Air Manifold Max dim. with door open = 639... -
Page 15: Island Iii Dimensions
ISLAND III DIMENSIONS (mm) I S L A N D ® charnwood charnwood I I I I S L A N D I S L A N D Flue outlet to suit 175mm (7") flue pipe TOP VIEW Optional Vertical Rear Flue Adapter... -
Page 16: Parts Lists
Description. In case of difficulty contact the manufacturer at the address shown. This drawing is for identification purposes only. charnwood BISHOPS WAY, NEWPORT, ISLE OF WIGHT PO30 5WS, UNITED KINGDOM T:+4 4 (0)1983 537799 • F:+4 4 (0)1983 537788 • SPARES@CHARNWOOD.COM • WWW.CHARNWOOD.COM ®... - Page 17 Description. In case of difficulty contact the manufacturer at the address shown. This drawing is for identification purposes only. charnwood BISHOPS WAY, NEWPORT, ISLE OF WIGHT PO30 5WS, UNITED KINGDOM T:+4 4 (0)1983 537799 • F:+4 4 (0)1983 537788 • SPARES@CHARNWOOD.COM • WWW.CHARNWOOD.COM ®...
-
Page 18: Parts Lists
Description. In case of difficulty contact the manufacturer at the address shown. This drawing is for identification purposes only. charnwood BISHOPS WAY, NEWPORT, ISLE OF WIGHT PO30 5WS, UNITED KINGDOM T:+4 4 (0)1983 537799 • F:+4 4 (0)1983 537788 • SPARES@CHARNWOOD.COM • WWW.CHARNWOOD.COM ®... -
Page 19: Certification
Bishops Way, Newport, Isle of Wight PO30 5WS, United Kingdom A Division of A.J.Wells & Sons Limited Registered in England No. 03809371 EN13240:2001 I S L A N D ROOMHEATERS FIRED BY SOLID FUEL Island I Island II Island III EC CERTIFICATE OF AZ50-CPD-2014... - Page 20 BISHOPS WAY, NEWPORT, ISLE OF WIGHT PO30 5WS, UNITED KINGDOM T : + 4 4 ( 0 ) 1 9 8 3 5 3 7 7 7 7 • F : + 4 4 ( 0 ) 1 9 8 3 5 3 7 7 8 8 • C O N T A C T U S A T W W W . C H A R N W O O D . C O M ®...
