  • Page 1 C H A R N W O O D I S L A N D O p e r a t i n g a n d I n s t a l l a t i o n I n s t r u c t i o n s f o r t h e a n d I s l a n d I I I...

  • Page 3: Door Operation

    For the same reason Your Charnwood Island is fitted with a multifuel grate to enable both hard woods (such as Ash, Beech and Oak) are better than soft woods solid fuels and wood to be burned equally effectively.

  • Page 4: Controlling The Fire

    This To make ash removal easier there is a special Charnwood ash carrier is normal and will cease after a short time, but meanwhile the room available.

  • Page 5: Overnight Burning

    Charnwood. S P E C I A L P O I N T S W H E N B U R N I N G C O A L C l e a n i n g t h e G l a s s...

  • Page 6: Troubleshooting

    T R O U B L E S H O O T I N G F i r e W i l l N o t B u r n . Check that: a) the air inlet at the rear of the stove is not obstructed in any way, b) chimneys and flueways are clear, c) that a suitable fuel is being used, Lift throat plate at rear,...
  • Page 7 I f Yo u N e e d F u r t h e r H e l p If you need further help with your Charnwood Island then your Installer will be able to provide the answers to most questions. Your Local Charnwood Premier Dealer has a great deal of experience and will also be able to provide helpful advice.

  • Page 8: H E A R T H A N D F I R E S U R R O U N D

    P E R F O R M A N C E The stove must stand on a fireproof hearth and must be situated at The output of the Charnwood ISLAND is 6.0 kW (20,500 Btu/h), least 300mm (12 inches) from any combustible material. The the Charnwood ISLAND output is 8.0kW (27,300 Btu/h) the...

  • Page 9: C O N N E C T I O N S T O F L U E S

    distance will need to be greater in some cases to meet Building Soot Door In Side or Rear Regulation requirements. Of Chimney Register Plate C O N N E C T I O N S T O F L U E S There are several ways of connecting the stove to the flue.
  • Page 10 2. The plates round the sides and back of the grate must be in COMMISSIONING position and sitting correctly. On completion of the installation and after allowing a suitable period of time for the fire cement and mortar to dry out, the stove should 3.
  • Page 11 C H A R N W O O D I I I I S L A N D Flue Outlet To Suit 175mm (7”) Flue Pipe Page 11 Island 8.03...
  • Page 12 Issue B Charnwood Island I Parts List Item Part No. Description Item Part No. Description 008/KV35S Door Seal Set Inc. Adhesive 004/AY24-02 Flap Mounting Rod (inc. fixings) 008/FW29 Door Seal Adhesive 004/BY23-07 Air Control Rod 002/CG20 Bottom Grate Bar 004/AY23...
  • Page 13 Issue B Charnwood Island II Parts List 33 17 Item Part No. Description Item Part No. Description 008/KV35S Door Seal Set Inc. Adhesive 004/AY24-02 Flap Mounting Rod (inc. fixings) 008/FW29 Door Seal Adhesive 004/BY23-07 Air Control Rod 002/CG20 Bottom Grate Bar...
  • Page 14 Issue C Charnwood Island III Parts List 21 22 37 29 Item Part No. Description Item Part No. Description 008/CY40S Door Seal Set Inc. Adhesive 004/CY24 Flap Mounting Rod (inc. fixings) 008/FW29 Door Seal Adhesive 004/CY32 Air Control Rod 002/CG20...
  • Page 16 Your Local Charnwood Premier Dealer: C H A R N W O O D B i s h o p s W a y , N e w p o r t , I s l e o f W i g h t P O 3 0 5 W S , U n i t e d K i n g d o m...
