Source Audio Soundblox Pro User Manual page 7

CONNECTIONS
GUITAR IN
Connect your bass guitar or other instrument here using a standard
¼" cable.
MONO
GUITAR OUT
Connect this to your amp, pedal, or other audio device.
EXPRESSION IN (optional)
Connect a passive expression pedal that uses a
expression pedal is assignable to a variety of parameters.
SENSOR IN (optional)
Connect an optional Hot Hand sensor here, either wired or wireless.
SENSOR OUT (optional)
Use a Source Audio daisy-chain cable to connect this jack to the sensor
input of another pedal.
MIDI IN (optional)
program and continuous control input. Connect to a
MIDI
with a standard
MIDI
clock.
9V DC
Connect the included 9 Volt
Audio power supply may cause damage and void the warranty.
SENSOR
IN
cable. Can also be used to sync the
power supply here. Use of a non-Source
DC
GUITAR IN EXP IN
TRS
MIDI IN
SENSOR
GUITAR OUT
plug here. The
output
MIDI
with a
LFO MIDI
OUT
9V DC
Connections | 7
