DMX Protocol
The LED Par 64 can be operated with a controller in control mode or without the controller in stand-alone
mode.

DMX Channels

Channel 1 – Red
0-255
Channel 2 – Green
0-255
Channel 3 – Blue
0-255
Channel 4 – Dimmer intensity
0-255
Channel 5 Strobe (Dimmer must be open
0-5
6-10
11-255
DMX Channels
Channel 1 – Built/in Programs / Sound-controlled
0
1-35
36-71
72-107
108-143
144-179
180-215
216-255
Note CH1:
When CH1 is set to 0-215, CH2 controls the speed of the programs from slow to fast.
When CH1 is set to 216-255, CH2 controls the audio sensitivity.
Channel 2 – Speed (when CH1 is set between 0-215
0-255
Channel 2 – Audio Sensitivity (when CH1 is set between 216-255
0-255
Channel 3 Strobe
0
1-255
(
5CH)
Gradual adjustment Red from 0 – 100%
Gradual adjustment Green from 0 – 100%
Gradual adjustment Blue from 0 – 100%
Gradual adjustment Blue from 0 – 100%
No Function
Full on
Strobe effect, from slow to fast (0-20 flashes/sec.)
(
3CH)
No Function
Program 1: 7-color fading
Program 2: 7-color jump
Program 3: color dreaming
Program 4: red fading
Program 5: green fading
Program 6: blue fading
Sound active
Speed from slow to fast
Audio sensitivity from less sensitive to highly sensitive
No Function
Strobe effect, from slow to fast (0-20 flashes/sec.)
)
)
