Summary of Contents for Qvis APOLLO PRO DC LX
- Page 1 APOLLO PRO DC LX 8 - 16 Channel User’s Manual ®...
- Page 2 ENHANCE YOUR DVR WITH OUR WIDE RANGE OF CAMERAS OUR PRODUCTS ARE FULLY TESTED TO WORK TOGETHER P400 CAMERAS VANDAL DOMES EYEBALL DOMES PTZ CAMERAS INTERNAL DOMES MINI CAMERAS DONT SETTLE FOR LESS, ALL OUR PRODUCTS CARRY LOGOS...
-
Page 3: Table Of Contents
Directory 1 Welcome ..................5 2 Open-package check and cable connections ........6 Initial check ............6 Hard disk installation ............6 Rack mount .................7 Front panel .................7 Rear panel ................8 Audio and video input and output connections ......9 2.6.1 Video input connections ..........9 2.6.2 Video output connections and options .......9 2.6.3 Audio signal input ............9... - Page 4 System ................33 4.4.1 General ................33 4.4.2 Encode .................34 4.4.3 Network ..............35 4.4.4 NetSevice ..............35 4.4.5 GUI Display ..............41 4.4.6 PTZ ................42 4.4.7 RS232 set up ..............42 4.4.8 Tour setup ..............43 Advanced ................43 4.5.1 HDD Manage ...............43 4.5.2 Account ...............44 4.5.3 Online user ..............46 4.5.4 TV adjustment ..............46 4.5.5 Auto maintain ..............46 4.5.6 Restore...
-
Page 5: Welcome
1. Welcome Thank you for purchasing our DVR! This manual is designed to be a reference tool for the installation and operation of your Qvis DVR series DVR system. You will find information about this Qvis DVRseries DVR's features and functions, as well as a detailed menu tree. Before you begin installation and operation please read the following safeguards... -
Page 6: Open-Package Check And Cable Connections
2 Initial check and cable connections 2.1 Initial check When you first receive your DVR, please check the following: 1. Please check whether there is any visible damage to the package appearance. The protective materials used for the package of the DVR can protect the DVR against most accidental damage during transportation. 2. Please open the box and get rid off the plastic protective materials. Check whether there is any visible damage to the DVR itself. -
Page 7: Rack Mount
5). Connect SATA data wire 6). Connect the power wire 7). Put the top back on 8). Screw on the cover 2.3 Rack mount installation This series of DVR is in a standard 2U case, so it can be rack mounted. Step: 1. Make sure the room temperature is lower than 35°C (95°f) 2. Keep at least 15cm space around the DVR to allow air to flow 3. Installation is from bottom to top 2.4 Front panel (may vary on some models) (1) Direction/OK (2) Play Pause/1... -
Page 8: Rear Panel
Front panel function table Serial NO Mark Function Direction In the Menu,press up or down to move Cursor Change configuration in the Drop-down menu Press up or down to select record file in the playback status In the Preview screen,press up or down to go into 1/4/8/9/16 multiple channels screen In the Menu,press left or right to move Cursor In the playback status,press left or right to move cursor of function button Enter Enter Enter into MainMenu Play/Pause Play or Pause when playback II Playback Reverse the playback Pause/4 Press shift to No. -
Page 9: Audio And Video Input And Output Connections
2.6.2 Video output connections and options The video output is divided into PAL/NTSC BNC(1.0VP-P ,75Ω) and VGA output (selective configuration). If you replace your Qvis monitor with a computer display, there are some issues to take note of. 1). Do not leave the display turned on for a long time. 2). To ensure normal working demagnetize regularly. 3). Keep the display away from electro magnetic Interference. -
Page 10: Audio Signal Output
2.6.4 Audio signal output Commonly the output parameter of a DVR audio signal is greater than 200mv 1KΩ(BNC) which can connect a low impedance earphone and active sound box or other audio output equipments through a power amplifier. If the sound box and the tone arm can not be isolated, a howling phenomena is often experienced. Here are some methods to deal with this phenomena. 1). -
Page 11: Alarm Input Port Specifications
(1,6,8) alarm input (2,7) grounding (3) Alarm (5) RS485 (4) RS232 Parameter Meaning grounding (earth) C1, NO1 Alarm output interface(constant open type) T, R RS232 port A, B 485 communication interface which is connected with the recording control equipments such as the decoder 2.7.1 Alarm input port specification 1 channels alarm input. Alarm input type unlimited. The earth and the com port of the alarm sensor are parallel (The alarm sensor has an external power supply) . -
Page 12: Alarm Output Port Relay Perameters
2.7.3 Alarm output port relay parameters Type: JRC-27F Interface material Silver Rating Rating switch capacity 30VDC 2A, 125VAC 1A (resistance load) Maximal switch power 125VA 160W Maximal switch voltage 250VAC, 220VDC Maximal switch current Isolation Homo-polarity interface 1000VAC 1minute Inhomo-polarity interface 1000VAC 1 minute Interface and winding 1000VAC 1 minute Surge voltage Homo-polarity 1500VAC (10×160us) Turn-on time 3ms max... -
Page 13: Basic Operation
3 Basic operation Note: The button in gray display indicates nonsupport. 3.1 Turn on Plug in and turn on the power supply switch. If the Power supply indicator light lights up then the video recorder has turned on. After startup you will hear a beep. The default setting of the video output is a multiple-window output mode. If the startup time is within a set video recording time, the timing video recording function will start up automatically. -
Page 14: Preview
Picture 3.1 System Login Password protection: If the password is entered continuously wrong for three times, the alarm will start. If the password is continuously wrong five times, the account will be locked. (Through a reboot or after half an hour, the account can be unlocked automatically). -
Page 15: Main Menu
Picture 3.2 Shortcut Menu 3.5.1 Main menu When you login, the system main menu is shown as below. Picture 3.3 Main Menu... -
Page 16: Playback
3.5.2 Playback There are two methods for you to play the video files in the hard disk. 1). In the desktop shortcut menu. 2). Main menu>Record->Playback Note: The hard disk that saves the video files must be set as read-write or read- only state. (4.5.1) Picture 3.4 video playback 1). Listed files 2). File information 3). File searching 4). - Page 17 Detect: Detect the storage connected with the DVR such as hard disk or universal disk. Erasure: Choose the file to delete and click erasure to delete the file. Stop: Stop the backup. Backup: Click backup button and the dialog box is popped up. You can choose the backup file according to the type, channel and time. Picture 3.6 recording backup Remove: Clear the file information. Add: Show the file information satisfying the set file attributes. Start/Pause: Click the play button to start the backup and click the pause button to stop the backup. Cancel: During backup you can exit the page layout to carry out other functions. (File searching) Search the file according to the searching parameter. Picture 3.7 file searching File type: Set the searching file type. Channel: Set the searching channel. Start Time: Set the searching time scan.
-
Page 18: Record Mode
Button Function Button Function Play/pause Backward Stop Slow play Fast play Previous frame Next frame Previous file Next file Circulation Full screen Table 3.2 Playback control key Note: Frame by frame playback is only performed in the pause playback state. (Operation hint) Display the function of the cursor place. Special functions: Accurate playback: Input time (h/m/s) in the time column and then click the play... -
Page 19: Alarm Output
3.5.4 Alarm output • Please check current channel status: “o” means it is not in alarming status, “ ” means it is in alarming status. You can use desktop shortcut menu or click [main menu]> [alarm function]> [alarm output] to enter the alarm output interface. Picture 3.9 alarm output (Configuration) Alarm is on according to the configuration. (Manual) Click the all button and the according channel is alarming no matter the channel in any state. - Page 20 Speed: Set the PTZ rotation range. Default range: 1 ~ 8. Zoom: Click / button to adjust the zoom multiple of the camera. Focus: Click / button to adjust the focus of the camera . Iris: Click / button to adjust the iris of the camera. Direction control: Control the PTZ rotation. 8 directions control is supportive. (4 directions in Front panel is supported ) High speed PTZ: Full-screen shows channel image. Left mouse click to control the PTZ rotation and orientation. Left click mouse and then rotate the mouse to adjust the zoom multiple of the camera. Set: Enters the function operation menu. Page switch: Switchs between different pages. Special functions: 1).
- Page 21 Value input blank Picture 3.12 PTZ Control 2: Cruise between Points A PTZ camera can be set to cruise between a series of preset points. This is called a cruise. To set the PTZ up to do this is as follows: 1). Cruise Between Points Settings A cruise line is a set up of multiple preset connected points, the setup procedure is as follows: Step 1: In Picture 3.10, use the Direction key to turn the PTZ to a designated location, click the settings button to enter Picture 3.13, Step 2: Click the Tour button, enter the tour number into the Patrol Number box if it isn't already showing and then click Add preset. The number of presets in the tour will show in the Preset box.
- Page 22 3: Scan The PTZ can also work on the preset scan line repeatedly. 1). Scan setup Step 1: In Picture 3.10, click the Setup button, which takes you to Picture 3.14; Step 2: Click the Pattern button and input a patrol value in the pattern value blank; Step 3: Click the begin button and enter Picture 3.10, here you can set the following items: Zoom, Focus, Aperture, Direction and so on. Click Set button to go back Picture 3.14; Step 4: Click the End button to complete the setup, Click the right button of the mouse to exit. Scan value blank Scan button Picture 3.14 Scan Setup 2).
-
Page 23: Color Setting
2). Boundary Scan Calls In Picture 3.10, click the Page Shift button to enter the PTZ control menu as shown in Picture 3.12. Please input the number of the scan in the value blank, then click the AutoScan button, the PTZ will begin to work on the scan line . Click the stop button to stop. 5: Rotating the Horizontal Click the Horizontally Rotating button and the PTZ will begin to rotate horizontally (relative to the original position of the camera). Click the Stop button to stop. 6: Rotate Click on the horizontal rotating button and the PTZ will turn around. -
Page 24: Output Adjust
3.5.7 Output Adjust Adjust TV output area parameters. You can use the desktop shortcut menu or enter [main menu]> [management tools]> [Output adjust]. Picture 3.19 Output Adjust 3.5.8 Logout To logout, shut down the system or reboot the system. You can use the desktop shortcut menu or enter [main menu]. Picture 3.20 Logout/ Shutdown/ Reboot the system (Logout) Quit the menu. Re-enter the password to log back in. -
Page 25: Main Menu
4 Main menu 4.1 Main menu navigation Main menu Sub menu Function Record Config Set the recording configuration, recording type, recording time section Playback Set recording look-up, recording play, video file storage Backup Detect or format backup equipment, back the selective files Snapshot Storage Set Pre snapshot,record and record time Alarm Motion detection Set motion detect alarm channel, sensitivity, area, linkage parameters: defending time section, alarm output, screen hint, recording, PTZ, patrol Video blind Set camera mask alarm channel, sensitivity, linkage parameters: defending time section, alarm output, screen hint, recording, PTZ, patrol Video loss Set video loss alarm channel, linkage parameters: defending time section, alarm output, screen hint, recording, PTZ, patrol Alarm input Set alarm input channel, equipment type, linkage parameters: defending time section, alarm output, screen hint, recording, PTZ, patrol... -
Page 26: Record
Main menu Sub menu Function Management Hard disk Set appointed hard disk as read-write disc, read-only disc tools management or redundant disc, clear data, resume date and so on User management Modify user, team or password. Add user or team. Delete user or team. Online user Break the connection with the already login user. Lock the account after break until booting up again. TV adjust Adjust TV upside, downside, nearside, starboard distance Automatic maintenance Set automatic reboot system and automatic deleting files. -
Page 27: Playback
(PreRecord) Record 1-30 seconds before the action. (time length is decided by the code stream) (Record mode) Set the video state: schedule, manual or stop. Schedule: Record according to the set video type (common, detection and alarm) and time section. Manual: Click the button and the relevant channel will start recording no matter what else the channel has been set to do. Stop: Click the stop button and the relevant channel stops recording no matter what else the channel has been set to do. (Period) Set the time section for common recording, The recording will start only within the set range. (Record type) Set recording type: regular, detection or alarm. Regular: Perform regular recording in the set time section. The video file type is “R”. Detect: Trigger the “motion detect”, “camera mask” or “video loss” signal. When the above alarm is set as the opening recording, the “detection recording” state is on. The video file type is “M”. -
Page 28: Backup
Manual: No matter what the present channel is doing, once you choose the "manual" button, it will only take a snapshot when you tell it to. Stop: No matter what the present channel is in a state, once you choose the "stop" button, it will stop the snapshot function. (Period) Set normal record period, (Sets the frequency that a Snapshot is taken). (Type) Three types: regular, detect and alarm (sets the trigger for a shapshot). (Record type) Three types: regular, detect and alarm Regular: snapshot at set period Detect: snapshot at set period when motion detect, video blind and video loss are set as the trigger to activate a snapshot. Alarm: snapshot at set period when alarm in which is preset for snapshot enable. -
Page 29: Alarm
Remove: Clear the file information. Add: Show the file information to satisfy the set file attributes. Start/pause: Click the play button to start the backup and click the pause button to stop the backup. Cancel: During backup you can exit the page layout to carry out other functions. 4.3 Alarm Function Alarm functions include: motion detect, video blind, video loss, alarm input and alarm output. 4.3.1 Motion Detect When the system detects a motion signal that reaches the set level of sensitivity, the motion detect alarm is switched on and the linkage function is turned on. Picture 4.4 Motion Detect (Channel) Choose the set motion detect channel. (Enable) ... - Page 30 (Period) Trigger the motion detect signal in the set time section. You can set according to week or set uniformly. Each day is divided into four time sections. means the setup is valid. Picture 4.6 set the time section (Interval) Only one alarm signal is turned on even if there are several motion detection signals in the set interval.
-
Page 31: Video Blind
(Send EMAIL) means sending an email to the user when the alarm is turned on. Note: Set in the [NetService] and send email. (Buzzer) Buzzering when alarm is actived (FTP upload) Upload record file to FTP server when alarm is actived Note: Set in the [NetService] and send FTP . 4.3.2 Video Blind When the video image is influenced by environmental factors such as excessive brightness or reaching the set sensitivy parameter, the camera mask function and the linkage function are turned on. Picture 4.9 Video Blind Set method: refer to chapter 4.3.1. Motion detect Note: "Advanced" button is the same as right-click. -
Page 32: Alarm Input
4.3.4 Alarm input When the system gets an external alarm signal, the alarm function is turned on. Picture 4.11 Alarm input Set method: refer to chapter 4.3.1. Motion detect Note:"Advanced" button is the same as right-click. 4.3.5 Alarm output Refer to chapter 3.5.4. 4.3.6 Abnormal Analysing and inspecting current software and hardware of the device: When some abnormal events happen, the device will make a relative explanation such as show a message and sound a buzzer. Picture 4.12 Abnormal (Event Type) Selecting the abnormity you want to inspect (Enable) Select it to make sure the abnormal function works... -
Page 33: System
4.4 System setup Set the system parameters such as General, Encode, NetWork, NetService, GUI Display, PTZ Config, RS232 and Tour Setup. 4.4.1 General Picture 4.13 General setup (System time) Set the system data and time. (Date format) Choose the data format: YMD, MDY, DMY. (Date Separator) Choose list separator of the data format. (Time Format) Choose time format: 24-hour or 12-hour. (Language) Arabic, Czech, English, Finnish, Greek, Indonesian, Italian, Japanese, Portuguese, Russian, Thai, T-Chinese, S-Chinese, Turkish, Brazilian, Bulgarian, Farsi, French, German, Hebrew, Hungarian, Polish, Romanian, Spanish, Swedish, Vietnamese (HDD full) Choose stop record: Stop recording when the hard disk is full Choose overwrite: Cover the earliest recording files and continue recording when the hard disk is full. (DVR No.) Only when the address button in the remote controller and the corresponding DVR number is matched, the remote operation is valid. -
Page 34: Encode
4.4.2 Encode setup Set the video/audio code parameters: video file, remote monitoring and so on. Set every independent channel’s coding parameter in the left part, and set the combine encode parameter in the right part. Note: Combine encode introduces video compression technique which combines and compresses multi-channel’s video to a special channel. Applying for multi- channel playback simultaneously, Dial-up multi-channel real-time monitor, mobile monitor and so on. Picture 4.16 Encode setup (Channel) Choose the channel number. -
Page 35: Network
4.4.3 Network setup Picture 4.17 Network (Net Card) You can choose cable network card or wireless network card. (DHCP Enable) Obtain IP address automatically (not suggested) Note: DHCP server is preinstalled. (IP address) Set the IP address. Default: 192.168.1.10. (Subnet mask) Set the subnet mask code. Default: 255.255.255.0. (Gateway) Set the default gateway. Default: 192.168.1.1. (DNS setup) Domain Name Server. It translates the domain name into IP address. The IP address is offered by network provider. - Page 36 (PPPoE setup) Picture 4.19 PPPOE Input the user name and password that the ISP (Internet service provider) provides. After saving it reboot your system. Then the DVR will build a network connection based on PPPoE. The IP address will change into a dynamic IP address after the above operation is done.
- Page 37 (EMAIL setup) If the alarm is turned on or the alarm linkage photos are taken, the system can send an email of the alarm information and the photos to an appointed address. Picture 4.21 EMAIL SMTP server: Email server address. This could be an IP address or a domain name. A domain name can only be used if it has the correct DNS configuration. Port: Email server port number. SSL: Decide whether to use Secure Socket Layer protocol to login. User Name: Apply the email server user name. Password: Input the user password. Sender: Set the senders email address. Receiver: Send the email to the appointed receiver(s) when the alarm is turned on. You can set up to three receivers. Title: You can set this as you wish. (IP Filter setup) When choosing from the white list, only those IP addresses listed can connect to the DVR.
- Page 38 (DDNS) (dynamic domain name server). Local domain name: Insert the domain name registered by the DDNS. User name: Insert the user name. Password: Insert the password. When the DDNS is successfully configured and started, you can connect the domain name in the IE address column to visit. Note: The DNS setup must be configured correctly in the network setup. Picture 4.23 DDNS setup (FTP setup) FTP is available only when an alarm happens, or an alarm activates a record and takes a snapshot, it will then upload the related records and snapshot pictures to the FTP server.
- Page 39 (ARSP) Startup DDNS server to add devices and manage it in the DDNS server Type: choose "DNS" Enable: means it is chosen Sever IP: IP address of DDNS server Port: (Wireless Config) ADSL through 3G net card, use CMS to visit and config the device Picture 4.25 Wireless Config (Enable) Choose Enable to make all settings available (Type) Dial type,default AUTO (Wireless AP) 3G access point (Dial Number) 3G Dial Number (User Name) User name of 3G (Password) Password of dial user (IP Address) IP address,got from dial.
- Page 40 (Enable) Select this to make sure the abnormal function is working (Port) This is the port to enable mobile monitoring. You will need to make a router map of it if you want to view everything by mobile (UPNP) UPNP protocol can set auto port forwarding on the router, make sure UPNP is running on the router before useing it. Picture 4.27 (Enable) Choose Enable to make sure all UPNP settings available (HTTP) Route will automatically distribute HTTP port for the device,when IE...
-
Page 41: Gui Display
4.4.5 GUI Display Configure the video output parameters including the front output mode and code output mode. Front output: In the local preview mode and includes: channel title, time display, record status, alarm status, bitrate info, transparency and region cover. Code output:In the network surveillance and video file mode include: channel title, time display, record status, alarm status, bitrate info, transparency and region cover. Picture 4.28 GUI Display (Channel Title) Click the channel name modify button and enter the channel name menu. -
Page 42: Ptz
4.4.6 PTZ setup Picture 4.29 PTZ setup (Channel) Choose the dome camera input channel. (Protocol) Choose the corresponding dome protocol. (PELCOD as an example) (Address) Set as the corresponding dome address. Default: 1. (Note: The address must be consistent with the dome address.) (Baud rate) Choose the corresponding dome baud rate length. You can control the PTZ and monitor. Default: 115200. (Data bits) Include 5-8 options. Default: 8. -
Page 43: Tour Setup
4.4.8 Tour setup Set the patrol display. means that the tour mode is turned on. You can choose the single window, four windows, nine windows, sixteen windows patrol display or single display. Picture 4.31 tour setup (Interval) Set the patrol switch interval. The set range is 5-120 seconds. Note: / means turn off/on the patrol. 4.5 Advanced 4.5.1 HDD Manage Configure and manage the hard disk. The menu displays current hard disk information: hard disk number, input port, type, status and overall capability. The operation include: setup the write-read disk, read-only disk, redundant disk, hard disk format, resume default. Choose the hard disk and click the right function... -
Page 44: Account
4.5.2 Account Manage the user purview. Note: 1. T he maximum character length is 8 bytes for the following user and user team name. A blank ahead of or behind a character string is invalid. A middle blank in the character string is valid. Legal characters include: letters, numbers, underline, subtraction sign, dot. 2. There is no limit to the number of users or user groups. You can add or delete a user group according to the user definition. - Page 45 (Add user) To add a user to the team and set the user authority. Enter the menu interface and input the user name and password. Choose the team and choose whether cover using is to be activated. Cover using means that the account can be used by multiple users at the same time.
-
Page 46: Online User
4.5.3 Online User Look up the network user information in the local DVR. You can choose the network user and cut the connection. Then the user is locked until next boot- strap. Picture 4.38 Online User 4.5.4 TV adjust Refer to chapter 3.5.7. 4.5.5 Auto Maintain The user can set the auto reboot time and auto file deleting time limit. -
Page 47: Upgrade
4.5.7 Upgrade Picture 4.41 Upgrade (Upgrade) choose USB interface. (Upgrade file) choose the file which needs upgraded. 4.5.8 Device Info Provide device interface info like audio in,alarm in/out to be conveniently used for user. Picture 4.42 Device Info. 4.6 Info 4.6.1 HDD info Display the hard disk state: hard disk type, overall capability, residual capability, the recording time and so on. Picture 4.43 HDD Info... -
Page 48: Bps
Clue: means that the hard disk is normal. X means that the hard disk is not working. means that there is no hard disk. If the user needs to change the damaged hard disk then you must shut down the DVR and remove all the damaged hard disks before installing a new one. -
Page 49: Version
4.6.4 Version Display the basic information such as hardware information, software edition, issue data and so on. Picture 4.46 Version 4.7 Shut down system Refer to chapter 3.5.8. -
Page 50: Faq And Maintenance
5 FAQ and maintenance 5.1 FAQ If your problems is not listed, please contact your local installer for service. The DVR does not boot up normally. Possible reasons are as followed: The power supply is not correct. Switch power supply line is not in good connection. Switch power supply is damaged. The program updating is wrong. The hard disk is damaged or the hard disk lines are broken. - Page 51 Real-time image problems such as the image color or the brightness distortion. Possible reasons are as followed: 1 When using the BNC output, the option between the N mode or PAL mode is wrong and the image becomes black and white. The DVR is not matched the monitor impedance. The video transmission distance is too far or the loss of the video trans mission line is too large.
- Page 52 11). The DVR can not control the PTZ. Possible reasons are as followed: There is something wrong with the frontal PTZ. 2 The setting, connection or the installation of the PTZ decoder is not correct. The connections are not correct. The PTZ setting of the DVR is not correct. The protocols of the PTZ decoder and the DVR are not matched. The address of the PTZ decoder and the DVR are not matched.
- Page 53 15). Network connection is unstable. Possible reasons are as followed: Network is not stable. 2 IP address is conflicted. 3 MAC address is conflicted. The net card of the DVR is bad. 16). There is something wrong with the USB backup or writing a CD. Possible reasons are as followed: The rewritable machine and the hard disk are shared the same data lines.
-
Page 54: Maintenance
21). The storage time is not enough. Possible reasons are as followed: Front monitor quality is bad. The lens is too dirty. The monitor is in back lighting installation. The hard disk capability is not enough. The hard disk is damaged. 22). -
Page 55: Appendix 1.Remote Controller Operation
Appendix 1.Remote controller operation (6)(1) (5) (8)(7) Serial Number Name Function Multi-window button Same function as Multi-window button in the front panel Numeric button Code input/number input/channel switch (Esc) Same function as (Esc) button in the front panel Direction button Same function as direction button in the front panel Record control Control the record Record mode... -
Page 56: Appendix 3.Technique Parameters
Appendix 3.Technique parameters Type 16ch System Main processor High performance embedded microprocessor Operation system Embedded LINUX operation system System resource synchronous multi-channel recording, synchronous multi- channel sub-code stream, synchronous multi-channel playback, synchronous network operation Interface Operation interface 16 bit true color graphical menu interface, mouse operation supportive display GUI on screen menu tips Video Video standard PAL 625line,50 f/s;NTSC 525 line,60 f/s Surveillance image PAL, D1(704x576);NTSC, D1(704x480) quality Playback image... - Page 57 Type 16ch Other Power supply 12V/6A external power supply Power consumption <15W (without hard disk) Working 0ºC~55ºC temperature Working humidity 10%–90% Air pressure 86kpa–106kpa Size 442x430.1x91mm Weight 7.5kg (without hard disk) Installation Desktop GENERAL FEATURES • 8/16 Channel video inputs & 8/16 Simultaneous playback • 8/16 Channel Full D1 Realtime Recordings • H.264 dual-stream video compression • Up to 8/16 cameras with realtime display • Pentaplex function giving live recording, playback,backup & remote access • Supports Dual stream giving mobile monitoring and network transmission • Smart video detection: motion detection, camera blank, video loss...
