Daewoo DWC-104C Service Manual page 18

 Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
NO CODE
3108005020 MOTOR FAN
25
3108005220 MOTOR FAN
26 7S432X5121 SCREW HEX
27 3101802700 FAN PROPELLER
28 3102201100 WINDOW KIT FRAME(L)
29 3102201000 WINDOW KIT FRAME(R)
30 3100604200 PLATE WINDOW TOP
31 3100061000 CABINET ASS'Y
32 3100604300 BRACKET WINDOW LOWER
33 3100604500 BRACKET SILL
34 3106600610 SCROLL LOWER
35 3103700101 LEVER VENT
36 3103700100 WASHER VENT
37 3104600100 RING VENT
38 3106700400 CAM
39 3118501300 ROCKER SWITCH
40 3107000100 CLIP THERMO
41 3118500600 THERMOSTAT
42 3118501100 SWITCH ROTARY
43 3111362B30 POWER CORD
3109507000 CAPACITOR
44
3109505300 CAPACITOR
45 3101201600 CLAMP CAPACITOR
46 3108009700 MOTOR SWING
47 3100508500 BOX CONTROL
48 3106600500 SCROLL UPPER
49 3103002800 HOLDER SCROLL
50 3104404400 PIPE RUBBER BUTYL
51 3102707500 HARNESS COMP ASSY
52 3110099A10 AS CAP DRAIN
53 3101404200 COVER ORIFICE
COMPONENTS Q'TY
1
1
4
1
1
1
1
1
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
SPECIFICATION
AM12DWD12, 208~230V, 60HZ
AM12DWD11, 208~230V, 60HZ
TT3 HEX M5*12 MFZN
ABS-5220 BLACK
HIPS(HI-425TV)
HIPS(HI-425TV)
SGCC T1.2*602*86.5
PP(H-540)
SGCC T0.8*80.5*27
SGCC T1.6*288*75
EPS FR20-Y(GRAY)
PP(H-540)
PP(H-540)
P6
PCM
SSM-1110
ABS(HF-380)
WK14S-408-120
HZ20-6
SJT 3*18 AWG,250V
370VAC 5/30µF
370VAC 4/25µF
SGCC T0.8
ST-16E, 220V, 3.15A
SGCC T0.8*410*331 ZERO/SP
EPS FR20-Y
SGCC 1.0T
T5X55X40
UL1015 3*16AWG
PP(H-540)
17
REMARK
DWA-125C/CS
DWA-145C/CS
DWA-125CS,145CS
DWA-125C/CS
DWA-145C/CS
DWA-125CS,145CS
