Daewoo DWC-104C Service Manual page 16

 Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
NO CODE
21 3101802600 FAN BLOWER
22 3101404100 COVER MOTOR
23 3104202000 PANEL HOUSING
24 3102000500 FIXTURE RUBBER
24-1 3100700600 BUSHING GUIDE
25 3108004920 MOTOR FAN
26 7S432X5121 SCREW HEX
27 3101802700 FAN PROPELLER
28 3102201100 WINDOW KIT FRAME(L)
29 3102201000 WINDOW KIT FRAME(R)
30 3100604200 PLATE WINDOWE TOP
31 3100061000 CABINET ASS'Y
32 3100604300 BRACKET WINDOW LOWER
33 3100604500 BRACKET SILL
34 3106600610 SCROLL LOWER
35 3103700100 LEVER VENT
36 3103700100 WASHER VENT
37 3104600100 RING VENT
38 3106700400 CAM
39 3118501300 ROCKER SWITCH
40 3107000100 CLIP THERMO
41 3118500600 THERMOSTAT
42 3118501100 SWITCH ROTARY
43 3111372B20 POWER CORD
44 3109507400 CAPACITOR
3116907100 CAPACITOR
45 3101201600 CLAMP CAPACITOR
46 3108004800 MOTOR SWING
47 3100508500 BOX CONTROL
48 3106600500 SCROLL UPPER
49 3103002800 HOLDER SCROLL
50 3104404400 PIPE RUBBER BUTYL
51 3102707500 HARNESS COMP ASSY
52 3110099A10 AS CAP DRAIN
53 3101404200 COVER ORIFICE
COMPONENTS Q'TY
1
1
1
1
1
1
4
1
1
1
1
1
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
SPECIFICATION
ABS-730
EPS(NATURAL)
SGCC T1.0*780*415 ZERO/SP
NBR(11.6g)
NBR
AM12DWD10, 115V, 60HZ
TT3 HEX M5*12 MFZN
ABS-5220 BLACK
HIPS(HI-425TV)
HIPS(HI-425TV)
SGCC T1.2*602*86.5
DWC-121C
SGCC T0.8*80.5*27
SGCC T1.6*288*75
EPS FR20-Y(GRAY)
PP(H-540)
PP(H-540)
P6
PCM
SSM-1110
ABS(HF-380)
WK14S-408-120
HZ20-6
SJT 3*16 AWG, 125V, 13A
370VAC 12/50•ÏF
370VAC 12/45•ÏF
SGCC T0.8
ST-16 120VAC 60HZ
SGCC T0.8*410*331 ZERO/SP
EPS FR20-Y
SGCC 1.0T
T5X55X40
UL1015 3*16AWG
PP(H-540)
15
REMARK
DWC-104CS,125CS
DWC-125C/CS
DWC-104C/CS
DWC-104CS,125CS
