Secondary harness wire connection guide

6 pin connector – C2
BLACK WIRE:
Ground Input (-). The black wire must connect to a solid chassis ground. Clean away any paint or dirt
to ensure the best possible ground.
BLUE WIRE:
Second Ignition Output (+). The blue wire provides +12v for second ignition wire.
YELLOW WIRE:
Ignition Output (+). Connect to the main ignition wire that provides +12v when the ignition is on and
while cranking the starter. Also, when ignition is off, this wire should not show any voltage (0v).
GREEN WIRE:
Starter Output (+). Connect to the vehicle's starter wire.
RED WIRE:
Main Power Input (+). Connect to the battery or constant power wire at the ignition switch with a
minimum 25 amp supply.
WHITE WIRE:
Accessory Output (+). Connect to the accessory wire coming from the ignition switch that supplies
power to the heater/air conditioner.

Immobiliser relay connection guide

YELLOW WIRE:
Connect to yellow wire of alarm system C1 connector (pin 11).
WHITE WIRE:
Connect to first accessory of ignition switch (+12v).
2 x GREEN WIRES:
Normally closed, can be connected to starter motor, positive side of coil, for diesel car fuel pump.
See wiring diagram for guidance.
