Contents
locations for the siren,..........................................................3
for the status LED, locations for the
Hawkguard shock sensor..................................................... 4
sensors, locations for the immobiliser
relay, obtaining constant 12 volts........................................ 5
crank position...................................................................... 6
your wiring connections.......................................................7
Prrimary harness wire connection guide
C1-12 pin connector............................................................ 8
6 pin connector - C2, immobiliser relay
connection guide..................................................................9
Wiring diagram................................................................... 1 0
Siren connection guide, jumpers setup...............................12
Central locking technical diagrams..................................... 1 3
supervision relays, boot release configurations..................17
