Hawk HA-FM10 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

HA - FM10
ALARM MANUAL
HA - FM1
Manufacturer:
COMMERCIAL ELECTRONICS
264 HAYDONS ROAD, WIMBLEDON, LONDON SW19 8TT. UK
TEL: +44 020 8404 7105 FAX: +44 020 8404 7104
http://www.hawkcaralarm.com e-mail: info@hawkcaralarm.com
ALARM MANU
Manufactured by Commercial Electronics. Great Britain. © Commercial Electronics 2013.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HA-FM10 and is the answer not in the manual?

Questions and answers

Related Manuals for Hawk HA-FM10

Summary of Contents for Hawk HA-FM10

  • Page 1 HA - FM10 ALARM MANUAL HA - FM1 Manufacturer: COMMERCIAL ELECTRONICS 264 HAYDONS ROAD, WIMBLEDON, LONDON SW19 8TT. UK TEL: +44 020 8404 7105 FAX: +44 020 8404 7104 http://www.hawkcaralarm.com e-mail: info@hawkcaralarm.com ALARM MANU Manufactured by Commercial Electronics. Great Britain. © Commercial Electronics 2013.
  • Page 2 PROPERTY DAMAGE OR PERSONAL INJURY. YOU MUST IMMEDIATELY CEASE THE USE OF THE UNIT AND SEEK THE ASSISTANCE OF AN AUTHORIZED DEALER TO REPAIR OR DISCONNECT THE INSTALLED REMOTE START MODULE. HAWK CAR ALARM WILL NOT BE HELD RESPONSIBLE OR PAY FOR INSTALLATION OR REINSTALLATION COSTS. Note: Range of LCD Alarm system is based on line of sight, unobstructed testing in ideal conditions.

  • Page 3: Table Of Contents

    CONTENTS FUNCTION ICONS ............1 BUTTON FUNCTION .

  • Page 4: Function Icons

    FUNCTION ICONS...

  • Page 5: Button Function

    BUTTON FUNCTION BUTTON FUNCTION System status Button Function BUTTON FUNCTION Ignition OFF ) 0.5 sec Arm / Car finder System status Button Function Ignition OFF II ( ) 0.5 sec Disarm Ignition OFF ) 0.5 sec Arm / Car finder Ignition OFF II ( ) 2 sec...

  • Page 6: Function

    FUNCTION 1. Programming setting System can program functions, please follow steps below: 1. Disarm the system, then switch ON ignition; FUNCTION 2. Press and hold II+III 2 sec, LED will flash once – pause – flash once , and siren will sound 1 sec .
  • Page 7 Description of programming functions: 1st: Alarm delay time for dome-light delay: 5 sec / 30 sec / OFF 2nd: Pulse length for central lock Version 1: 0.5 sec to close, 0.5 sec to open Version 2: 3.5 sec to close, 3.5 sec to open Version 3: 0.5 sec to close, two 0.5 sec pulses to open Version 4: two 0.5 sec pulses to close, two 0.5 sec pulses to open Version 5: 25 sec to close, 0.5 sec to open...

  • Page 8: Arm

    2. Arm To arm your system within proper operation range, press but- ton I shortly (while system in disarmed and Acc off position). Siren will sound once (siren will not sound in mute mode), lights flash once, doors lock, disable engine starter, and LED will flash slowly.

  • Page 9: Car Finder

    2. Check car battery voltage System can check car battery voltage, if voltage is 12.8V, remote controller LCD screen shows the right picture like here. 5. Car finder In arm status, press button I shortly, siren sound 4 times (siren will not sound in mute mode), turning light flash at the same time for car finder.

  • Page 10: Door Alarm Delay

    10. Door alarm delay System default setting door alarm delay is OFF, in this mode: 1. Press button I to set arm, if door (or trunk) do not be closed properly, siren will sound 3 times and lights will flash 3 times (in mute status, only lights flash 3 times), which can warn car owner to close door and set arm again.

  • Page 11: Channel 2 Output Choosing

    14. Channel 2 output choosing Channel 2 output can program to 0.8 sec pulse for opening trunk, 25 sec pulse for closing window, or 30 sec potential pulse. Factory default setting is 0.8 sec. 1. Remote open boot Press and hold button III 2 sec, the main unit channel 2 output -250mA pulse 0.8 sec to open the boot.

  • Page 12: European Mute Mode On/Off

    At this time, press button II shortly, remote controller sound OFF ”, shock sensor alarm “Bi-Bi-”, LCD screen show “ function is OFF, system can not receive shock sensor alarm signal. Hint: If you do not need shock sensor, it is possible to temporarily disconnect the sensor when leaving children or pets in the car.

  • Page 13: Auto Arm Function On/Off

    19. Auto arm function ON/OFF Press and hold button IV ( F ) 2 sec, then press button IV ( F ) shortly many times, till remote controller LCD screen icon “ AUTO ” flashes. At this time, press button I shortly, remote controller sounds “Bi-”, LCD screen shows “...

  • Page 14: Srp (Safe Roadside Parking) Function On/Off

    22. SRP (Safe roadside parking) function ON/OFF System default setting SRP function is OFF, you can set it to ON. If you park the car roadside and open the door, lights will flash 15 times to warn. 23. Power disconnecting memory When re-powered, system will keep the original status before power off.

  • Page 15: Starter On Delay Before Engine Start (Diesel Mode)

    If press button II shortly, open the door and close it again, the system is still under reservation mode and can be auto started (including remote engine start and timely engine start) again. Before using auto start, please check the car style. For manual gearshift car must be set reservation mode first.

  • Page 16: Outer Device Trigger Start Function

    4. Open the door and get off within this 3 min and close the door, engine is still running. During this time user can open and close doors many times. If you set arm, engine will stop automatically, reservation mode is set successfully. Situation of failure to set reservation mode: 1.

  • Page 17: Timely Auto Start Function

    32. Timely auto start function You can set two timely auto start time. Press and hold button IV ( F ) 2 sec, then press button IV ( F ) shortly many times, till the remote screen icon “ TIMER 1 ” or “...

  • Page 18: Low Car Storage Battery Level Auto Start Function

    When the engine temperature below –10°c, 10 sec later engine will auto start. At this time, engine will work 10 min continuously (user can set it to 20 min or 30 min). At this time, if temperature below –10°c, engine will auto start again. If the temperature below 20°c after engine start twice continuously, system will can- cel low temperature auto start function in this anti-theft cycle.

  • Page 19: Remote Controller Learning

    11. Please repeat 7. ~ 10. procedure, enter into new PIN code again, if siren sounds twice, new PIN code will be correct and saved; if siren sounds 3 times, system will exit revising PIN code status, new PIN code is invalid. Note: 1.
  • Page 20 Installation points to remember This product represents many years of research and development. It is very sophisticated and Installation points to remember should be installed by experienced security installers only. Please do not attempt installation of this product without reading this guide. The system has been designed to provide the This product represents many years of research and development.
  • Page 21 Locations for the control box Locations for the control box Locations for the control box Some things to remember about where to mount the control module: Some things to remember about where to mount the control module: • Never put the control module in the engine compartment! • Never put the control module in the engine compartment! Some things to remember about where to mount the control module: •...
  • Page 22 Locations for the Hawkguard Locations for the Hawkguard Locations for the Hawkguard Locations for the Hawkguard ultra sonic sensors ultra sonic sensors Ultra soniuc sensor ultra sonic sensors Ultrasonic cells should be placed on the left and right side as high as possible so to obtain the Ultrasonic cells should be placed on the left and right side as high as possible so to obtain the Ultrasonic cells should be placed on the left and right side as high as possible so to obtain Ultrasonic cells should be placed on the left and right side as high as possible so to obtain the...
  • Page 23 Finding the 12v switched Finding The 12v switched ignition wire Ignition wire The ignition wire is powered when the key is in the run or start position. This is because the The ignition wire is powered when the key is in the run or start position. This is because ignition wire powers the ignition system (spark plugs, coil) as well as the fuel delivery the ignition wire powers the ignition system (spark plugs, coil) as well as the fuel delivery (fuel pump, fuel injection computer).
  • Page 24 Finding the door pin switch circuit Finding the door pin switch circuit The best places to find the door switch wire are: The best places to find the door switch wire are: • At the pin switch: when testing the pin switch, check wire to ensure that it ‘sees’ all the doors.

  • Page 25: Attention For Installation

    40. Attention for installation H1: 6 PIN Remote start-up power socket PIN1: Black and yellow wire – Starter switch-on wire (+12V). It is connected to ignition lock wire where +12V appears in the “Starter” key posi- tion. This signal means engine start-up. PIN2: Blue wire –...

  • Page 26: System Parameters

    H4: 8 PIN main socket 2 PIN1: Brown/white wire – Negative hand-brake trigger input PIN2: Brown/black wire – Positive foot-brake trigger input PIN3: Gray wire – Negative trunk trigger input PIN4: White wire – Negative door trigger input PIN5: White/Red wire – Positive door trigger input PIN6: Blue/black wire –...

  • Page 27: Installation Diagram 1

    INSTALLATION DIAGRAM 1...
  • Page 28 INSTALLATION DIAGRAM 2...

  • Page 29: Central Lock Installation Diagram

    CENTRAL LOCK TECHNICAL DIAGRAM Central locking technical diagrams Central locking technical diagrams Central locking technical diagrams Diagram C Diagram C Diagram A Diagram A Single point locking Single point locking Negative locking Negative locking PRIOR TO MAKING THE CONNECTION ENSURE PRIOR TO MAKING THE CONNECTION ENSURE PRIOR TO MAKING THE CONNECTION ENSURE PRIOR TO MAKING THE CONNECTION ENSURE...
  • Page 30 CENTRAL LOCK TECHNICAL DIAGRAM Central locking technical diagrams Diagram G Diagram E Positive locking with comfort closing Actuator interrupt (negative at rest) VW Golf vehicles only PRIOR TO MAKING THE CONNECTION ENSURE THE ALARM IS PROGRAMMED FOR THE PRIOR TO MAKING THE CONNECTION ENSURE APPROPRIATE LOCKING PULSE THE ALARM IS PROGRAMMED FOR THE APPROPRIATE LOCKING AND COMFORT...
  • Page 31 CENTRAL LOCK TECHNICAL DIAGRAM Central locking technical diagrams Diagram I Diagram M Single wire - negative to lock, interrupted to unlock Central locking control resistive positive (type CHRYSLER STRATUS) INTERNAL PRIOR TO MAKING THE CONNECTION ENSURE CENTRAL THE ALARM IS PROGRAMMED FOR THE LOCKING APPROPRIATE LOCKING PULSE SWITCH...
  • Page 32 CENTRAL LOCK TECHNICAL DIAGRAM Central locking technical diagrams Diagram Q Diagram O Central locking control actuator switch interrupt Central locking control resistive (negative at rest) (type Honda) negative unlock only INTERNAL CENTRAL LOCKING VEHICLE SWITCH PRIOR TO MAKING THE CONNECTION ENSURE PRIOR TO MAKING THE CONNECTION ENSURE CENTRAL THE ALARM IS PROGRAMMED FOR THE...

  • Page 33: Other Diagrams

    Bonnet and door protection Bonnet and door protection BONNET AND DOOR PROTECTION Bonnet and door protection Bonnet and door protection Bonnet and door protection Optional diode and BLUE WIRE (–) INPUT FROM ALARM Optional diode and BLUE WIRE (–) INPUT FROM ALARM Optional diode and BLUE WIRE (–) INPUT FROM ALARM bonnet pin switch...
  • Page 34 NOTES...
  • Page 35 HAWK dealer; and the unit is returned to HAWK, shipping prepaid with a legible copy of the bill of sale or other dated proof of purchase bearing the following information: consumer’s name, telephone number and address;...
