C1-12 Pin Connector; Primary Harness Wire Connection Guide - Hawk ha-280 pro Installer Manual

Primary harness wire connection guide

C1–12 pin connector
This guide describes in detail the connection of each wire. Also included are possible applications of
each wire. This system was designed with the ultimate in flexibility and security in mind. Please read
the instructions carefully to ensure a thorough understanding and how it operates; also see wiring
diagram of HA-280 PRO.
BLUE WIRE:
Negative Door Input (-). Connect to the Driver door pin switch circuit wire that shows
when the door is open.
Note: Nearly all cars have negative door input. Consult owner manual for polarity.
GREEN WIRE:
Positive Door Input (+). Connect to the driver door pin switch circuit wire that shows +12v when
the door is open.
Note: Consult owner manual for polarity.
GREY WIRE:
Negative Hand Brake Input (-). Connect to the hand brake. If the hand brake is not in pull position,
remote engine start will not function.
BROWN WIRE:
Positive Hazard Light Output (+). Connect the brown wire to the circuit that shows +12v or only when
the hazard lights are on. Right hazard light.
BROWN WIRE:
Positive Hazard Light Output (+). Connect the brown wire to the circuit that shows +12v or only when
the hazard lights are on. Left hazard light.
WHITE WIRE:
Positive Siren Output (+). Connect the white wire to the siren of white wire.
WHITE/BLACK WIRE:
Positive Input (+). Connect the white/black wire to ignition positive when engine on. This signal is
used as to confirm whether engine started, can connect to the tachometer line, or oil light or charging
battery line.
BLUE/WHITE WIRE:
Positive Input (+). Connect the blue/white wire that shows +12v when pressing the foot brake.
RED/BLACK WIRE:
Negative Output (-). 250mA Interior Light. Connect to the wire that activates the vehicle's interior light.
NOTE: MUST USE RELAY (not supplied).
PINK WIRE:
Negative Output (-). 250mA Boot Release. Connect to the boot release motor.
NOTE: MUST USE RELAY (not supplied).
YELLOW WIRE:
Negative Output (-) 250mA Immobiliser. Connect to yellow wire to yellow wire to immobiliser relay.
RED WIRE:
Negative Output (-). 250mA Window Closer. 30 second negative output.
NOTE: MUST USE window closer module HA-64U (optional extra).
8
ground (-)
