  • Page 1 Instructions Instructions Instructions Power Hoe Power Hoe Power Hoe Power Hoe Power Hoe 1600 Farmstar premium 1600 Farmstar premium 1600 Farmstar premium 1600 Farmstar premium 1600 Farmstar premium Petrol Engine Diesel Engine 5823, 5822 Before commissioning the machine, read operating instructions and observe warnings and safety instructions.

  • Page 2: Amount Of Delivery

    Visual check Please state these data when ordering spare parts to avoid wrong Clutch deliveries. Only use original agria spare parts! Hoeing drive Specifications, figures, and dimensi- Forward ons stated in these instructions are not binding. No claims can be derived Reverse from them.

  • Page 3: Designation Of Parts

    Designation of Parts Petrol Engine Version Figure A 10 9 Figure B agria Power Hoe Farmstar premium 1600...
  • Page 4 6 Engine type number 7 Starter handle 8 Cooling-air screen 9 Exhaust with guard 10 Spark plug, spark plug connector 11 Engine oil filling plug and dip stick 12 Engine oil drain plug 13 Fuel tap agria Power Hoe Farmstar premium 1600...

  • Page 5: Table Of Contents

    Front Support Wheel ....25 Figures A and B 4. Commissioning and (Petrol Engine Version) .... 3 Operation Figures C and D Commissioning the Machine (Diesel Engine Version) ..54 (Petrol Engine Version) ....26 agria Power Hoe Farmstar premium 1600...

  • Page 6: Recommendations

    Maintenance and Repair The trained mechanics of your agria workshop carry out expert maintenance and repair. You should only carr y out major maintenance work and repairs on your...

  • Page 7: Fuel

    -26°C app. -15°C app. -20°C app. - 9°C As a last resort, you can add up to 30% of regular petrol to avoid paraffine deposits. However, this has negative effects on consumption rate and performance. agria Power Hoe Farmstar premium 1600...

  • Page 8: Unpacking And Assembly

    Take the machine out of the box or cut the box open on all 4 corners and fold down the sides to remove the machine. Fit the hoeing tools and hoeing guards. Carry out all steps for starting-up. agria Power Hoe Farmstar premium 1600...

  • Page 9: Safety Instructions

    Careful with rotating tools – keep at a hoe/multi-purpose machine render safe distance! manufacturer liability null and void. Beware of coasting tools. Before you start any maintenance or repair on them, wait until tools have come to a complete stop. agria Power Hoe Farmstar premium 1600...
  • Page 10 Above all, learn how to turn the engine and turn it off. Have the malfunction off quickly and safely in an emergency. repaired without delay. Ensure that all guards are mounted and positioned to provide protection. agria Power Hoe Farmstar premium 1600...
  • Page 11 Linkage attachments as specified and Check nuts and bolts regularly for tight only couple at specified points. fit and re-tighten, if necessary. Ensure that you re-install all guards and adjust them properly after maintenance and cleaning. agria Power Hoe Farmstar premium 1600...
  • Page 12 1. Safety Instructions Only use original agria spare parts. All Before you dispose of opened and other commercial spare parts must seemingly empty pressurised tins (e.g. correspond to quality and technical of assist-starting liquids) make sure they requirements specified by agria.

  • Page 13: Safety Instructions

    With engine running, keep at a safe distance from knife! Do not touch any moving machinery parts. Wait until they have come to a complete stop! With engine running, keep at a safe distance! agria Power Hoe Farmstar premium 1600...

  • Page 14: Specifications

    Steering handle: ..height and side adjustable without tools h ......860…1090 k ........810 Weight: (without hoeing tools) l ........1420 Petrol engine version ..... 53,5 kg A ......520…980 Diesel engine version .... 63,5 kg agria Power Hoe Farmstar premium 1600...

  • Page 15: Engine

    Starter: on handlebar: ..... a = < 2.5 m/s Soft-pull recoil starter with mechanical in accordance with EN 709 and EN 1033 at decompression facility 85% of rated engine speed with tool at work. agria Power Hoe Farmstar premium 1600...
  • Page 16 Fuel tank capacity: ..approx. 2.5 l Vibration acceleration value: on handlebar: ..... a = < 7.1 m/s in accordance with EN 709 and EN 1033 at 85% of rated engine speed with tool at work. agria Power Hoe Farmstar premium 1600...

  • Page 17: Devices And Operating Elements

    3. Devices and Operating Elements The power hoe agria-Farmstar is a Cooling System motorised unit for turning over the Cooling system is fan-cooled. Therefore ground. Therefore it is most suitable for keep screen at recoil starter and cooling normal use in landscape gardening.

  • Page 18: Safety Circuit Function

    (A/8) down. Do not tie down safety circuit lever. The safety circuit lever also serves as an emergency shut-off. In an emergency, move the lever to position “STOP”, the lever automatically goes to STOP position. agria Power Hoe Farmstar premium 1600...
  • Page 19 To do this, move the lever to the right. Fuel tap The fuel tap (B/13) is on the carburetor. Move the tap to the right to open it. Move the tap to the left to close it. agria Power Hoe Farmstar premium 1600...
  • Page 20 Activate decompression to start the engine via the recoil starter. To do this, fold down the decompression lever (C/14). As you pull the recoil starter, the decompression lever will automatically move back into its original position. agria Power Hoe Farmstar premium 1600...

  • Page 21: Clutch

    C/10 C/10; C11 Steering Handle Steering Handle Height and Side Adjustment Undo the tommy nut (5) until the teeth are exposed. Move the handlebars (4) to the proper position. Re-tighten the tommy nut (5). agria Power Hoe Farmstar premium 1600...

  • Page 22: Hoeing Tools

    (view from the front) or fences. through the hoeing tools and the hoeing shaft and tighten with two discs (2) and lok- king nut (1) (tighten with 45 Nm). agria Power Hoe Farmstar premium 1600...
  • Page 23 ..100 ..1 .. 4 ......3 .. 915 .. 108* ..1 .. 4 .. 1 ..1 ..3 .. 1045 ... 2 * = Total width with guard discs ..... = shorten out of larger anchoring bolt agria Power Hoe Farmstar premium 1600...

  • Page 24: Depth Bar

    Fold up the locking pin (5). Remove the locking pin (5). Move the bar (4) either up or down until its holes are aligned with the holes in the leg (3). Replace the locking pin and fold it down. agria Power Hoe Farmstar premium 1600...

  • Page 25: Front Support Wheel

    Fold the beam up into a mesh with notches and tighten the knurled screw. Transport Position 1 Front wheel 2 Linch pin Fold the front wheel down and tighten 3 Knurled screw (clamping screw) the knob screw. agria Power Hoe Farmstar premium 1600...

  • Page 26: Commissioning And Operation

    Before you operate the engine the first time, fill engine and oil bath air filter with oil (see page 35 and 36)! Oil level agria Power Hoe Farmstar premium 1600...

  • Page 27: Starting The Petrol Engine

    Flick the engine shut-off switch to “I”. Move the speed control lever to a central posi- tion (between idling speed and full throttle). Start engine from a position outside the hazar- dous area. CHOKE to operation position. agria Power Hoe Farmstar premium 1600...

  • Page 28: Shutting Off The Petrol Engine

    Instead, close the fuel tap and operate the engine until it comes to a stop by lack of fuel. This is to ensure the carburetor is empty and to avoid resin deposits. agria Power Hoe Farmstar premium 1600...

  • Page 29: Diesel Engine Version

    Before you operate the engine the first time, fill engine and oil bath air filter with oil (see page 40 and 41)! Oil level agria Power Hoe Farmstar premium 1600...

  • Page 30: Starting The Diesel Engine

    Push decompression lever (D/14) downwards. Start engine from a position outside the danger zone. Decompression automatically goes back into former position. Set speed control lever to centre position (half throttle) and let engine warm up for some time. agria Power Hoe Farmstar premium 1600...

  • Page 31: Shutting Off The Diesel Engine

    This ensures continued and reliable operation. 1 Min. Set safety circuit lever (C/8) to “STOP”. shutting engine never activate decompression, as this might damage the valves. Secure machine against unauthorized use. agria Power Hoe Farmstar premium 1600...

  • Page 32: Hoeing

    Only remove jammed objects with a tool, e.g. a wooden stick. To clean or exchange the hoeing tools, recline the machine only backwards onto the handlebar (before you do this, remove the depth bar). agria Power Hoe Farmstar premium 1600...
  • Page 33 Pull clutch lever and lock with pawl (A/10 or max. 20° C/10) (safety circuit switch in “start position”). (44 %) Restart the engine. agria Power Hoe Farmstar premium 1600...

  • Page 34: End Of Operation

    Pull clutch lever (A/9 or C/9) and lock pawl. Move gear shift lever to neutral (“0”). Shut off the engine – move speed control lever (A/6 or C/6) to “STOP”. If the attachment comes with guards, immediately attach these. agria Power Hoe Farmstar premium 1600...

  • Page 35: Petrol Engine

    Specifications for oil quantity and quality. Use a funnel or a similar device to fill the oil reservoir. Replace the oil filler plug (2) and tighten it. Only change oil while the engine is still warm, but not hot – danger of burns! agria Power Hoe Farmstar premium 1600...
  • Page 36 Re-attach the air-filter housing (do not forget the o-ring) and top up engine oil to level mark (refer to technical specifications for engine oil) Re-fit the filter cover and attach it with the wing nut (9Nm). agria Power Hoe Farmstar premium 1600...

  • Page 37: Fuel System

    Remove the drain plug and open the fuel tap. Fuel supply will be OK, if fuel runs through the tap. Retighten the drain plug. Fuel Hoses 3 Fuel drain plug Replace fuel hoses after every 2 years. agria Power Hoe Farmstar premium 1600...
  • Page 38 (B/8). Check each time before you take up operation! 100 h Air-Cooling System Clean internal cooling fins and surfaces at least every 100 operating hours (earlier in very dusty conditions). - Service agria Power Hoe Farmstar premium 1600...
  • Page 39 Engine speed actuating devices must be adjusted correctly to start, operate and switch off the engine at correct speed rates. For adjustment, contact your agria workshop. Carburetor Settings Small differences in fuel, temperature, altitude or load may require slight carburetor adjustment.

  • Page 40: Diesel Engine

    Fill fresh engine oil into the oil filling opening. Refer to Specifications for oil quantity and quality. Use a funnel or a similar device to fill the oil reservoir. Replace the oil filler plug (2) and tighten it. agria Power Hoe Farmstar premium 1600...
  • Page 41 Fill engine oil into the oil sump (3) (approx. 0.2 l) until it is level with the full marks on the ring inside the oil sump. Ensure the assembly is closed tight. agria Power Hoe Farmstar premium 1600...
  • Page 42 Fill diesel fuel into the fuel tank. Crank engine several times with recoil starter or electric starter and start the engine. Let engine run for approx.1 minute. Fuel Hoses Exchange after every 2 years; exchange leaking fuel hoses immediately. agria Power Hoe Farmstar premium 1600...
  • Page 43 After every 400 operating hours, clean and check injection jet. - Service Idling Speed Always ensure that idling engine speed is adjusted correctly. At low speeds, the engine is supposed to run smoothly, with speed control lever at stop in neutral. - Service agria Power Hoe Farmstar premium 1600...

  • Page 44: Machine

    (refer to specifi- cations for quality and quantity) until the oil is level with the inspection hole (see “Transmission oil level“) Replace the plug and tighten it. Attach the panel (1). agria Power Hoe Farmstar premium 1600...

  • Page 45: Adjusting The Clutch Lever

    Set the adjustment screw (1) to a play of “A”. Turn screw in to reduce play, turn screw out to increase the play. Then secure the adjustment screw with a lock nut (2). Free play of clutch: A = 5…6 mm agria Power Hoe Farmstar premium 1600...

  • Page 46: Safety Circuit Function

    Engine Clean the engine only with a cloth. Avoid cleaning it with a pressure washer, as water might leak into ignition and fuel system, causing malfunctions. agria Power Hoe Farmstar premium 1600...

  • Page 47: Storage

    Tighten the bowl until it is snug. Remove the carburetor drain plug (3) to drain the petrol into a suitable container or add fuel stabiliser (agria No. 799 09): Fill the fuel tank, then add stabiliser - observe instructions! Operate the engine for approx.

  • Page 48: Varnishes, And Wear Parts

    Air filter element set 759 99 Spark plug NGK BPR 6 ES; BOSCH WR 7 DC List of Spare Parts 172 22 172 23 997 151 Power hoe Farmstar 1600 997 145 Honda engine agria Power Hoe Farmstar premium 1600...
  • Page 49 6. Troubleshooting Observe safety instructions! Have all serious malfunctions on the machine or engine repaired by your agria workshop. They have the proper tools. Improper repairs can only add to the damage. Problem Possible Cause Remedy Page Petrol Engine: Engine...
  • Page 50 - Loose cylinder head or Tighten cylinder head, output damaged gasket exchange gasket too low - Poor compression Have engine checked - Air filter clogged Clean air filter = For this purpose contact your agria workshop - Service agria Power Hoe Farmstar premium 1600...

  • Page 51: Troubleshooting

    - Worn out clutch Exchange clutch disc Excessive - Loosened attachment bolts Tighten attachment bolts vibration = For this purpose contact your agria workshop - Service Electrical Wiring – Petrol Engine Version Safety circuit Circuit 1 Engine 2 Solenoid ignition...

  • Page 52: Inspection And Maintenance Chart

    K = Checks and service to be executed by operator W = Maintenance to be executed by professional workshop F = Maintenance should be carried out by your agria workshop * = after 2 years agria Power Hoe Farmstar premium 1600...
  • Page 53 6 Engine type number 7 Starter handle 8 Cooling-air screen 9 Exhaust with guard 11 Engine oil filling plug and dip stick 12 Engine oil drain plug 14 Decompression lever 15 Engine oil filter agria Power Hoe Farmstar premium 1600...

  • Page 54: Diesel Engine Version

    Designation of Parts Diesel Engine Version Figure C Figure D agria Power Hoe Farmstar premium 1600...

  • Page 55: Conformity Declaration

    EC Conformity Declaration agria Power Hoe Farmstar premium 1600...
