Top Menu SYSTEM INFO

Firmware and hardware versions and the serial num-
ber of the unit is listed in the SYSTEM INFO screen.
Resetting to Factory
Defaults
Navigate to SYSTEM INFO in the Top Menu and press
the encoder to enter the screen.
Highlight SYSTEM DEFAULT and press the encoder.
Highlight OK in the next pop-up screen and press the
encoder to restore the factory default settings.
The default settings are as follows:
Level
Phase
TxBatt
SmartNR
Compat
Tuning
DivMode
LockSet
RxCh
Rio Rancho, NM, USA
+00 dBu
NORMAL
AA ALK
NORMAL
Dig. Hybrid
NORMAL MODE
Switched
NOT LOCKED
8, 0
Digital Hybrid Wireless

IR Transmitter Setup

The IR (infrared) port simplifies transmitter setup by
sending the settings saved in the receiver to an IR en-
abled transmitter. The IR port is located on the receiver
front panel next to the power switch.
Hold the transmitter with its IR port facing the receiver
front panel within two feet or so and start the transfer
with the receiver. Navigate to the SETTINGS item
in the TX MENU and press the encoder to open the
setup screen.
Select the desired transmitter channel. Highlight SEND
SET and press the encoder. The settings displayed on
the receiver LCD will the sent to the transmitter.
Modular Receiver System
®
15
