Alarm Out

You can set up the DVR to activate alarm out of the device connected to the DVR's alarm out port.
1 to 16: Displays alarm out number. See Appendix 4 — Connector Pin Outs for details about the alarm out
number.
From, To: Set alarm out activation period. Alarm out is activated during the period only. If the From time is later
than the To time, the alarm out will be activated at the From time of the current date until next day's To time. If
you set To: 08:00 and From: 18:00, this means the alarm will be activated over night from 6:00 p.m. until 8:00
a.m. the following day.
Dwell time: Set the alarm out duration.
Use audible alert: The DVR sounds beep through the connected speaker during alarm output.
