Gravity Vent Fireplace Insert
!
WARNING
!
WARNING
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or loss of life.
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light the appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call
the fire department.
Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
4001003-12
© 2010 Miles Industries Ltd. All rights reserved
Model RF24BN/BP
Installation and Owner's Manual
WARNING
HOT GLASS WILL
HOT GLASS WILL
HOT GLASS WILL
CAUSE BURNS.
CAUSE BURNS.
CAUSE BURNS.
DO NOT TOUCH GLASS
DO NOT TOUCH GLASS
DO NOT TOUCH GLASS
UNTIL COOLED.
UNTIL COOLED.
UNTIL COOLED.
NEVER ALLOW CHILDREN
NEVER ALLOW CHILDREN
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
TO TOUCH GLASS.
TO TOUCH GLASS.
Manufactured by
MILES INDUSTRIES LTD., British Columbia, Canada
www.valorfireplaces.com
INSTALLER: Leave this manual
with the appliance.
CONSUMER: Retain this manual
for future reference.
Please read this manual BEFORE installing
and operating this appliance.
This appliance may be installed in an
after-market permanently located,
manufactured (mobile) home where not
prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
This appliance is a domestic room-heating
appliance. It must not be used for any other
purposes such as drying clothes, etc.
This appliance is suitable for installation in a
bedroom or bed sitting room.
Massachusetts: The piping and final
gas connection must be performed by a
licensed plumber or gas fitter in the State of
Massachusetts.
Patents Pending
Advertisement
Table of Contents
Related Manuals for Valor Retrofire F24BN
Summary of Contents for Valor Retrofire F24BN
- Page 1 Patents Pending Model RF24BN/BP Gravity Vent Fireplace Insert Installation and Owner’s Manual WARNING WARNING WARNING HOT GLASS WILL HOT GLASS WILL HOT GLASS WILL CAUSE BURNS. CAUSE BURNS. CAUSE BURNS. DO NOT TOUCH GLASS DO NOT TOUCH GLASS DO NOT TOUCH GLASS UNTIL COOLED.
- Page 2 Thank You ... For purchasing a Valor Retrofire. Your new radiant gas heater is a technical appliance that must be installed by a qualified dealer. Each Retrofire is fully tested during the production process for your safety and comfort. Your unit has been professionally installed by:...
-
Page 3: Table Of Contents
Table of Contents Safety and Warning Information............4 ◊ Specifications ..................5 Dimensions and Clearances ..............6 Venting ....................7 Existing Fireplace Preparation ............8 Supply Gas .................... 9 Vent Liner Rough-In ................10 Appliance Preparation ................ 10 Firebox Installation ................11 Ceramic Fuel Bed Installation ............ -
Page 4: Safety And Warning Information
Safety and Warning Information READ and UNDERSTAND all instructions carefully This unit MUST be used with a vent system as before starting the installation. FAILURE TO FOLLOW described in this installation manual. NO OTHER vent these installation instructions may result in possible fire system or components MAY BE USED. -
Page 5: Specifications
Safety and Warning Information Operating Your Fireplace for the First Time. It is also possible that these vapors could set off any smoke detection alarms in the immediate vicinity. When operating your new fireplace for the first time, These vapors are quite normal on new appliances. We some vapors may be released due to the burning of recommend opening a window to vent the room. -
Page 6: Dimensions And Clearances
Dimensions and Clearances Dimensions— for Solid-Fuel Burning Fireplace Insert Only See separate framing Dimensions for Zero Clearance applications with the Zero Clearance Kit RA24ZC. 24-1/2” 24-3/8” 17” 8” 7-5/8” 1225VFB Ventana Fret (Black) Stand-offs RA24TB Fret (Black) 25-1/2” 3” dia. 27”... -
Page 7: Venting
Venting Vent Materials Use a 3” diameter aluminium flex liner approved for gas venting when installing as an insert (existing chimneys). Use a 4” diameter type “B” vent when installing with a RA24ZC Zero Clearance Kit. See separate instructions packaged with the Zero Clearance Kit. -
Page 8: Existing Fireplace Preparation
Existing Fireplace Preparation A few points must be considered before inserting the RF24 into an existing fireplace cavity. Generally, modifications to the existing fireplace that will compromise its integrity are NOT allowed. Components that are bolted or screwed on, such as dampers or baffles, may be removed to accommodate the installation of the RF24 engine. Cutting away any sheet metal parts off the existing fireplace to accommodate the installation of the RF24 is prohibited. -
Page 9: Supply Gas
Supply Gas • It is preferable to rough-in the gas line at this point before proceeding with the firebox installation. • The gas supply inlet connection is a 3/8” NPT female connector. For detailed location of this connector, see illustration in section Dimensions. If a circulating fan or isolating valve is to be installed, adjust the routing of the gas line to suit. -
Page 10: Vent Liner Rough-In
Vent Liner Rough-In Rough-in the 3” diameter vent liner into existing chimney system being careful not to tear or damage the liner in the process. Leave plenty of liner at the bottom end if the heater will be connected while on the hearth—see diagram in Connect Liner to the Firebox section. -
Page 11: Firebox Installation
Firebox Installation Connect Liner to the Firebox Trim Liner and Connect The vent plate will ultimately locate approximately 19” Vent Plate to Liner using Gear Clamp provided above the base of the fireplace once inserted. 1. Trim the liner accordingly so it will not be too long Approx. - Page 12 Firebox Installation Reinstall the Burner Module Note: If the circulating fan is to be installed, it should be done at this point before installing the burner module. See instructions packaged with the fan for installation details. Reinstall the burner module using the 4 screws removed previously. Note: The upper baffle may be removed to gain more room for the screwdriver to install the rear screws.
-
Page 13: Ceramic Fuel Bed Installation
Ceramic Fuel Bed Installation Install the Ceramic Brick Liner Install the ceramic brick liner taking care not to damage them as the material is fragile. The top rounded edges of the side panels should face inwards and the front edge is bevelled. Place the side brick panels flat up high against the side of the firebox and slide them downward into place, behind the frame of the firebox. -
Page 14: Window Refitting
Ceramic Fuel Bed Installation Install the Ceramic Log Set L/H Log Locating Pins Place Middle Cross Log Place R/H Cross Log Across Gap in Front Log Onto Locating Pins Place L/H Cross Log Onto Locating Pins Window Refitting Hook the window over the top edge of the firebox and fasten the bottom two spring-loaded bolts by pushing in and turning 90 degrees. -
Page 15: Remote Control Installation
Remote Control Installation CAUTION DO NOT PUT BATTERIES IN THE REMOTE CONTROL RECEIVER until the wires are connected to the burner control unit as short-circuit could result in the destruction of the electrical components. CAUTION DO NOT USE a screwdriver or other metallic object to remove the batteries from the receiver or the handset! This could cause a short circuit to the receiver. -
Page 16: Vent Check
Vent Check This unit is equipped with a vent safety switch, located on the right side of the draft hood, which will shut the burner off if the vent is not functioning properly. Use a match or a source of smoke at the front of the draft channel to check direction of flow in the vent. -
Page 17: Owner's Information
Owner’s Information The window can be removed for cleaning by rotating CAUTION the two fastening studs at the bottom corners 90 Your fireplace becomes very hot when operating. degrees to release, and swinging the bottom of the Avoid placing decorating objects sensitive to heat window unit outwards to unhook the top edge—see page 10. -
Page 18: Remote Control Operation
Owner’s Information Batteries Replacement The repair parts are shown in the repair parts list. Please always quote the part number and description CAUTION when requesting spare parts. DO NOT USE a screwdriver or other metallic object Vent Safety Switch to remove the batteries from the receiver or the This appliance is equipped with a vent safety switch handset! This could cause a short circuit to the which, when activated, will turn off the burner and... - Page 19 Remote Control Operation Setting the temperature Use this setting when you come in and want to enjoy a specific temperature. 1. Push the AUTO button until a number and F flash. Let go. 2. While it is still flashing, push the ▲ and ▼ buttons to the temperature you want. Let go.
-
Page 20: Options
Options Fuel Conversion Kits RA24NK—Converts from LPG to NG RF24BN—Natural Gas Installations RA24PK—Converts from NG to LPG RF24BP—Propane Gas Installations Zero Clearance Kit Accessories (sold separately) RA24ZC Decorative Cast Iron Frets Outer Cast Plate RA24CV—Contemporary, Vintage Iron Finish 715CVI (use with RA24ZC kit only) RA24AV—Avant-Garde, Vintage Iron Finish Screened Fronts (use with RA24ZC kit only) RA24TB—Traditional, Black Finish... -
Page 21: Lighting Instructions
Lighting Instructions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot, which must be lighted by hand. When lighting the pilot, follow these instructions exactly. -
Page 22: Warranty
Warranty If you have a problem with this unit, please contact your dealer or supplier immediately. Under no circumstances should you attempt to service the unit in any way by yourself. The warranties in paragraphs 1 and 2 are provided only to the first purchaser/user of this unit, are not transferable and are subject to the conditions and limitations in paragraphs 3, 4 and 5. -
Page 23: Parts
Parts PART PART DESCRIPTION DESCRIPTION NUMBER NUMBER Firebox Assembly 4000634AH Pilot Tube 4000732 Vent Plate 4001010 Straight Connector 220K891 Convection Baffle 4001009 Maxitrol Valve GV34 4000056 LH Fret Support 4000693 Valve Cover 4000801 Wing Nuts (2) 4000741 Servo Motor 4000802 LH Leg 4000662 Minimum Rate Screw #185 NG... - Page 24 Parts...
- Page 25 Thank You ... For purchasing a Valor by Miles Industries. Your new radiant gas heater is a technical appliance that must be installed by a qualified dealer. Please circle where appropriate - ask your installer if in doubt:Information provided will be used for customer records only.
- Page 26 Fold here Postage needed Miles Industries Ltd. 190 - 2255 Dollarton Highway North Vancouver, BC V7H 3B1 Canada Online Warranty registration at www.valorfireplaces.com Were you given all documentation and manuals for your product? Thank you for choosing a Valor Product...
