Valor regency 328 Installation & Servicing Instructions Manual

Radiant / convector
Hide thumbs
Table of Contents

Advertisement

Quick Links

Valor Folium Format U/down 12/4
INSTALLATION & SERVICING INSTRUCTIONS
RADIANT / CONVECTOR
THIS APPLIANCE IS FOR USE WITH NATURAL GAS (G20) AT A
SUPPLY PRESSURE OF 20mbar (8 in w.g.)
THIS APPLIANCE IS FOR USE IN THE UNITED KINGDOM (GB) AND
We trust that these instructions give sufficient details to enable this appliance to be installed and maintained satisfactorily. However if
further information is required, our Valor advice line will be pleased to help.
INSTALLER: Please leave these instructions with the owner
5/22/00
9:33 AM
Page 1
GAS FIRES
Favourite
MODEL 322
Firelite
MODEL 328
&
Regency
MODEL 328
THE REPUBLIC OF IRELAND (IE) ONLY
Ring 0345 626 341 (local call rates apply).
600B520/02
April 2000
