Valor Retrofire RF24IDN Installation And Owner's Manual

Direct vent fireplace insert
Hide thumbs Also See for Retrofire RF24IDN:

Advertisement

WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury or loss of life.
Do not store or use gasoline or other
fl ammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light the appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call
the fi re department.
Installation and service must be performed
by a qualifi ed installer, service agency or the
gas supplier.
4002315-06
© 2011 Miles Industries Ltd. All rights reserved.
Model RF24IDN/IDP
Direct Vent Fireplace Insert
Installation and Owner's Manual
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
Manufactured by
MILES INDUSTRIES LTD., British Columbia, Canada
www.valorfi replaces.com
INSTALLER: Leave this manual
with the appliance.
CONSUMER: Retain this manual
for future reference.
Please read this manual BEFORE installing
and operating this appliance.
This appliance may be installed in an
after-market permanently located,
manufactured (mobile) home where not
prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certifi ed kit is used.
This appliance is a domestic room-heating
appliance. It must not be used for any other
purposes such as drying clothes, etc.
This appliance is suitable for installation in a
bedroom or bed sitting room.
Massachusetts: The piping and fi nal
gas connection must be performed by a
licensed plumber or gas fi tter in the State of
Massachusetts.
Patents Pending

Advertisement

Table of Contents
loading

Summary of Contents for Valor Retrofire RF24IDN

  • Page 1 fi tter in the State of by a qualifi ed installer, service agency or the Massachusetts. gas supplier. Manufactured by MILES INDUSTRIES LTD., British Columbia, Canada www.valorfi replaces.com 4002315-06 © 2011 Miles Industries Ltd. All rights reserved.
  • Page 2 Thank You ... For purchasing a Valor Retrofi re. Your new radiant gas heater is a technical appliance that must be installed by a qualifi ed dealer. Each Retrofi re is fully tested during the production process for your safety and comfort.
  • Page 3: Table Of Contents

    Table of Contents Safety and Warning Information..............4 Specifi cations ....................5 ◊ Dimensions ....................6 Vent Confi gurations ..................7 Vent Termination ....................8 Existing Fireplace Preparation ..............10 Supply Gas Installation ................11 Vent Liner Rough-in ..................12 Appliance Preparation .................12 Firebox Installation ..................13 Ceramic Fuel Bed Installation ..............16 Window Refi...
  • Page 4: Safety And Warning Information

    Safety and Warning Information READ and UNDERSTAND all instructions carefully This unit MUST be used with a vent system as before starting the installation. FAILURE TO FOLLOW described in this installation manual. NO OTHER vent these installation instructions may result in possible fi re system or components MAY BE USED.
  • Page 5: Specifi Cations

    Safety and Warning Information It is also possible that these vapors could set off any Operating Your Fireplace for the First Time smoke detection alarms in the immediate vicinity. When operating your new fi replace for the fi rst time, These vapors are quite normal on new appliances.
  • Page 6: Dimensions

    Dimensions 17-1/4” 24-1/2” 24-3/8” 8” 7-5/8” 3” dia. 3” dia. Inlet 1225VFB Ventana Fret (Black) RA24TB Fret (Black) 25-1/2” 27” Gas Inlet 3/8” NPT Female 11” 10” RA24CV Fret (Vintage Iron) RA24AV Fret (Vintage Iron) Control Valve Location Optional Frets Front Face of 1”...
  • Page 7: Vent Confi Gurations

    Vent Confi gurations Where possible, avoid joints in fl ex pipe. If joints Allowable Vent Confi gurations are required, use only connectors approved by the The RF24 is certifi ed for use with approved 3” diameter manufacturer of the fl ex pipe. Field fabricated joints are fl...
  • Page 8: Vent Termination

    Vent Termination The RF24 is approved for Vertical Co-Linear Termination Only. Two 10” dia. 3” diameter liners are required from top to bottom. The vent liners must be connected to the proper collars (intake and exhaust) or the unit will not operate properly.
  • Page 9 Vent Termination Vent Terminal Location The venting system for this appliance is considered to be a Special Venting System. The rule in the Installation Code CAN/CGA–B149 requiring a minimum vent height of 2 feet above any portion of a building within 10 feet does not, therefore, apply.
  • Page 10: Existing Fireplace Preparation

    Existing Fireplace Preparation A few points must be considered before inserting the Gas Line Routing RF24 into an existing fi replace cavity. Generally, no Plan the routing of the gas line before proceeding. modifi cations are allowed to the existing fi replace that Utilize the existing hole for the gas line.
  • Page 11: Supply Gas Installation

    Supply Gas Installation • It’s preferable to rough-in the gas line at this point • When testing for leaks: before proceeding with the fi rebox installation. • Make sure that the appliance is turned off. • The gas supply inlet connection is a 3/8” NPT •...
  • Page 12: Vent Liner Rough-In

    Vent Liner Rough-in Rough-in the two 3” diameter vent liners into existing When connecting the liner in this manner it is best to chimney system being careful not to tear or damage leave the top termination until later so the slack liner the liners in the process.
  • Page 13: Firebox Installation

    Firebox Installation Connection of liners to fi rebox Trim liners if necessary and connect to the fi rebox either while the fi rebox is on the hearth (Option 1) or with the fi rebox in the cavity (Option 2). Use gear clamps provided to connect the liners to the fi...
  • Page 14 Firebox Installation Leveling the fi rebox in the hearth The backside of each support leg has a leveling bolt. If necessary, adjust the level of the fi rebox in the hearth. Fret bracket Leveling Front Back Leveling bolt bolt Leveling bolt Side View Front View Burner Module Reinstallation...
  • Page 15 Firebox Installation Top Convection Baffl e Installation Position the fi rebox as far back as possible within the existing fi replace to allow ample space at front for the fret and to allow convection air to fl ow under the smoke curtain of the existing fi...
  • Page 16: Ceramic Fuel Bed Installation

    Ceramic Fuel Bed Installation Ceramic Log Set Installation Carefully remove the ceramic logs from the packaging Please note that the Rear Log will have a different taking care not to damage them. Install the logs as position depending of the gas type. described below.
  • Page 17: Window Refi Tting And Checking

    Window Refi tting and Checking Hook the window over the top edge of the fi rebox, and Check that Window fasten the bottom two spring loaded bolts by pushing Moves Freely After in and turning 90 degrees. Check that the window Reinstallation moves freely against the spring by pulling out at the bottom.
  • Page 18: Operation Check And Aeration Adjustment

    Operation Check and Aeration Adjustment Turn the fi replace up and down using the remote control to confi rm that the full range of inputs is achieved. Air Shutter Light the fi re and allow to warm up for 10–15 minutes to evaluate the fl...
  • Page 19: Optional Bottom Cover Installation

    Optional Bottom Cover Installation Important: When the bottom cover is used instead of a fret, An area of 3/4 inch (19 mm) in front of the a space is required in front of the window to allow the window window MUST be kept clear at all times! to move and relieve during a hard start.
  • Page 20 Owner’s Information Dust, etc. can be brushed from the ceramic fuel effects To replace the batteries in the remote control and fi rebox walls after removing the front unit and receiver: opening the window. Dust etc. can also be removed 1.
  • Page 21: Remote Control Operation

    Remote Control Operation NOTE: Before using the remote control system for the fi rst time, the receiver and the handset must be synchronized. See the section Remote Control Initial Set-up on page 17 in this manual. Your fi replace remote control helps you get the comfort, convenience and aesthetics you want from your gas fi replace. The remote controls your fi...
  • Page 22 Remote Control Operation Operation Modes STANDBY MODE—Ignited pilot only. MAN MODE —Manual Mode. You can use this mode to adjust the flame height up or down. ☼ TEMP MODE —Daytime Temperature Mode (appliance must be in Standby mode; pilot ignited): The room TEMP temperature is measured and compared to the set temperature.
  • Page 23 Remote Control Operation Temperature Use this setting when you come in and want to enjoy a set temperature. MODE or the ☽ 1. Select either the ☼ MODE by briefly pressing the SET button. TEMP TEMP 2. Hold the SET button until the TEMP display flashes. 3.
  • Page 24: Options

    Remote Control Operation Low Battery Indication CAUTION Remote handset: BATT will appear on the display when DO NOT USE a screwdriver or other metallic object the battery needs to be replaced. to remove the batteries from the battery box or the Replace with one 9 V alkaline battery.
  • Page 25: Lighting Instructions

    Lighting Instructions FOR YOUR SAFETY, READ BEFORE LIGHTING WARNING : If you do not follow these instructions exactly a re or ex losion ay result causin ro erty da a e ersonal in ury or loss of life A. This appliance has a pilot which must be lighted by hand or by remote control. Follow these instructions exactly. To save gas, turn the pilot off when not using the appliance for a prolonged period of time.
  • Page 26: Wiring Diagram

    Wiring Diagram Optional Wall Switch Kit 1265WSK Connector Yellow GV60 Wiring Diagram...
  • Page 27: Approved Venting Components

    Approved Venting Components APPROVED DIRECT VENT SUPPLIERS FOR VALOR MODELS 739, 780, 785 & RF24DV Venting Parts Code / availability by Manufacturer Venting Parts Description Standard Co-axial 46DVA-VC 4DT-VC TM-4VT — HSDV4658-1313 — High Wind Co-axial 46DVA-VCH — — SV4CGV —...
  • Page 28: Warranty

    Warranty If you have a problem with this unit, please contact your dealer or supplier immediately. Under no circumstances should you attempt to service the unit in any way by yourself. The warranties in paragraphs 1 and 2 are provided only to the fi...
  • Page 29: Parts

    Parts PART PART DESCRIPTION DESCRIPTION NUMBER NUMBER Firebox Assembly 400634AH 2-Flame Pilot Hood 4000730 Restrictor (2) 400767 Electrode 720A543 Convection Baffl e 4000744 Pilot Tube 4000732 Fret Support LH 4002837BY Thermocurrent Interruptor 4001037 Wing Nut (2) 4000741 GV60 Valve 4000873 Leg LH 4000662 Servo Motor...
  • Page 30 Parts 50a, 50b 51a, 51b 8a, 8b 14a, 12a, 12b 34a, 29a, 29b...
  • Page 31 Thank You ... For purchasing a Valor by Miles Industries. Your new radiant gas heater is a technical appliance that must be installed by a qualifi ed dealer. Please circle where appropriate - ask your installer if in doubt:Information provided will be used for customer records only.
  • Page 32: Miles Industries Ltd

    Fold here Postage needed Miles Industries Ltd. 190 - 2255 Dollarton Highway North Vancouver, BC V7H 3B1 Canada Online Warranty registration at www.valorfi replaces.com Were you given all documentation and manuals for your product? Thank you for choosing a Valor Product...
