1000 Series UPS
Operation and Reference Guide
Second Edition (October 1999)
Part Number 341253-002
Compaq Computer Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Compaq 1000 Series

  • Page 1 1000 Series UPS Operation and Reference Guide Second Edition (October 1999) Part Number 341253-002 Compaq Computer Corporation...
  • Page 2 MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE, GOOD TITLE AND AGAINST INFRINGEMENT. This publication contains information protected by copyright. No part of this publication may be photocopied or reproduced in any form without prior written consent from Compaq Computer Corporation. © 1999 Compaq Computer Corporation.
  • Page 3: Table Of Contents

    Getting Help ........................x Compaq Technical Support .................xi Compaq Website....................xi Compaq Authorized Reseller................xi Chapter 1 Overview Compaq 1000 Series UPS Models................1-2 Front Panels ......................1-3 Rear Panels ......................1-4 Standard UPS Features .................... 1-6 Communications Port ..................1-7 Power Management Software................1-7 Hardware Option Cards ..................
  • Page 4 Compaq 1000 Series UPS Operation and Reference Guide Chapter 2 Installation Installation Requirements ..................2-2 Item(s) not supplied with the UPS kit ............... 2-2 Item(s) supplied with the UPS kit ..............2-2 Before Starting the UPS................... 2-4 Rack-Mounting the UPS ................... 2-4 Connecting to the Communications Port ............
  • Page 5 About This Guide v Chapter 5 Battery Maintenance Precautions....................... 5-2 Charging Batteries ....................5-3 When to Replace Batteries..................5-3 Pre-Failure Battery Warranty................... 5-4 Obtaining New Batteries..................5-5 Replacing Batteries....................5-5 Step 1: Preparing the UPS ................5-5 Step 2: Removing the Battery Pack ..............5-6 Step 3: Installing New Batteries ..............
  • Page 6 Compaq 1000 Series UPS Operation and Reference Guide Appendix C Specifications Physical Specifications ....................C-2 Input Specifications....................C-3 Output Specifications....................C-4 Output Specifications....................C-5 Overcurrent Protection.....................C-6 Battery Specifications ....................C-7 Battery Runtime .......................C-8 Environmental Specifications ..................C-9 Index...
  • Page 7: About This Guide

    About This Guide This guide is designed to be used as step-by-step instructions for installation and as a reference for operation, troubleshooting, and future upgrades. Text Conventions This document uses the following conventions to distinguish elements of text: Keys Keys appear in boldface. A plus sign (+) between two keys indicates that they should be pressed simultaneously.
  • Page 8: Symbols In Text

    Compaq 1000 Series UPS Operation and Reference Guide Symbols in Text These symbols may be found in the text of this guide. They have the following meanings. WARNING: Text set off in this manner indicates that failure to follow directions in the warning could result in bodily harm or loss of life.
  • Page 9: Precautions

    UPS batteries. The maintenance and replacement of batteries must be carried out by qualified service personnel. WARNING: The 1000 Series UPS models weigh between 43 and 58 lb (20 and 26 kg) when fully assembled. To reduce the risk of personal injury or...
  • Page 10: Rack Stability

    Compaq 1000 Series UPS Operation and Reference Guide IMPORTANT: Please refer to the Important Safety Information (included with the UPS kit) before installing this product. Rack Stability WARNING: To reduce the risk of personal injury or damage to the equipment, take the following precautions: Rack-mountable models MUST be installed at the bottom of the rack.
  • Page 11: Compaq Technical Support

    Operating system type and revision level Detailed, specific questions Compaq Website The Compaq website has information on this product as well as the latest drivers and Flash ROM images. You can access the Compaq website at: http://www.compaq.com Compaq Authorized Reseller For the name of your nearest Compaq authorized reseller: In the United States, call 1-800-345-1518.
  • Page 12: Overview

    Chapter Overview This chapter contains information on the following topics: Compaq 1000 Series Uninterruptible Power System (UPS) models 1000 Series UPS front panels 1000 Series UPS rear panels 1000 Series UPS features Warranties...
  • Page 13: Compaq 1000 Series Ups Models

    1-2 Compaq 1000 Series UPS Operation and Reference Guide Compaq 1000 Series UPS Models The 1000 Series includes the following UPS models: Table 1-1 1000 Series UPS Models UPS Model Part Number Comments T1000 242688-001 Domestic; low voltage; Tower T1000h 242688-002 International;...
  • Page 14: Front Panels

    Overview 1-3 Front Panels The 1000 Series includes both tower and rack-mountable UPS models. Figure 1-1. Front panel configuration - tower models Front panel Control buttons LED display Air vents Figure 1-2. Front panel configuration - rack-mountable models Battery compartment...
  • Page 15: Rear Panels

    1-4 Compaq 1000 Series UPS Operation and Reference Guide Rear Panels The 1000 Series UPS models feature the following rear panel configurations: LOAD 1 LOAD 2 Figure 1-3. Rear panel of T1000, T1500, and T1500j Communications port Power cord with 5-15p plug...
  • Page 16 Overview 1-5 LOAD 1 LOAD 2 Figure 1-4. Rear panel of T1000h and T1500h Communications port Network Transient Protector 10A input circuit breaker Load segment 2 IEC-320 power inlet Load segment 1 Option slot REMOTE POWER OFF Figure 1-5. Rear panel of R1500 and R1500j REPO port Load segment 1 IEC-320 power inlet...
  • Page 17: Standard Ups Features

    1-6 Compaq 1000 Series UPS Operation and Reference Guide REMOTE POWER OFF Figure 1-6. Rear panel of R1500h REPO port Load segment 2 IEC-320 power inlet Communications port 10A input circuit breaker Option slot Load segment 1 Standard UPS Features...
  • Page 18: Communications Port

    Overview 1-7 Communications Port The 1000 Series UPS models include a communications port that allows the UPS to exchange data with the host computer. Power management software (supplied by Compaq) gives users access to status reporting and power management features.
  • Page 19: Hardware Option Cards

    UPS can provide individual server control. For example, if a network includes two servers (with one running Windows NT, and the other running Unix), a 1000 Series UPS with a Multi-Server UPS Card can establish direct communications with each server. Allocate a separate UPS load segment to supply power to each server and to the devices associated with that server.
  • Page 20 Compaq Scalable UPS Card The Scalable UPS Card makes up to three UPS units appear as a single virtual UPS to the host computer and, with Compaq Power Management Software, allows scaling up the level of power protection available to the system.
  • Page 21: Network Transient Protector

    1-10 Compaq 1000 Series UPS Operation and Reference Guide Network Transient Protector The 1000 Series tower UPS models include a Network Transient Protector that provides protection for communications equipment (such as network devices, a fax machine, or a modem) from surges.
  • Page 22: Warranties

    Warranties $25,000 Computer Load Protection Guarantee To back up the wide range of features offered with the UPS, Compaq provides a three-year limited warranty. In addition, Compaq offers a $25,000 Computer Load Protection Guarantee (provided by the original equipment manufacturer).
  • Page 23: Installation

    Chapter Installation This chapter provides information on the following topics: Installation requirements Procedures to complete before starting the UPS Starting the UPS Completing the installation...
  • Page 24: Installation Requirements

    2-2 Compaq 1000 Series UPS Operation and Reference Guide Installation Requirements This section lists items needed to install the Compaq 1000 Series UPS models. Item(s) not supplied with the UPS kit Tools A medium flat-bladed and Phillips screwdriver may be needed.
  • Page 25 The T1000h/T1500h models ship with a 6-foot UPS/computer interface cable, Compaq part number 295245-003; and two 6-foot IEC to IEC power cords, Compaq part number 142263-001, for load equipment power. The R1500/R1500j models ship with a 12-foot UPS/computer interface cable, Compaq part number 295245-004.
  • Page 26: Before Starting The Ups

    NOTE: Although these steps can be carried out after the UPS is installed, the UPS will need to be powered down to safely perform these tasks. Rack-Mounting the UPS The 1000 Series rack-mountable UPS models must be mounted on fixed rails. Refer to the appropriate installation card (supplied with the UPS kit) to obtain instructions.
  • Page 27: Connecting To The Communications Port

    Installation 2-5 Connecting to the Communications Port The 1000 Series UPS models include a communications port that allows the UPS to exchange data with the host computer. IMPORTANT: Compaq Power Management Software, LanSafe III, and FailSafe III require the communications port to be appropriately cabled to the host computer.
  • Page 28: Connecting The Network Transient Protector

    2-6 Compaq 1000 Series UPS Operation and Reference Guide Connecting the Network Transient Protector The 1000 Series tower UPS models include a Network Transient Protector to provide surge protection for connected communications devices. IMPORTANT: Use the Network Transient Protector with a standard telephone line only—...
  • Page 29: Connecting The Remote Emergency Power Off

    Installation 2-7 Connecting the Remote Emergency Power Off The 1000 Series rack-mountable UPS models include a Remote Emergency Power Off (REPO) port. When properly wired, the REPO port allows the power to the UPS output receptacles to be switched off from a remote location.
  • Page 30: Starting The Ups

    2-8 Compaq 1000 Series UPS Operation and Reference Guide 4. Replace the connector block in the REPO port. RE M OT PO W ER OF F R E M O P O W E R O F F Figure 2-4. Replacing the connector block IMPORTANT: The remote switch must be in the OFF (open) position to enable power to the output receptacles.
  • Page 31: Checking The Battery Recharge Date Label

    IMPORTANT: Do not use the UPS if the battery recharge date has expired. If the date on the Battery Recharge Date label has passed without the batteries being recharged, contact an Authorized Compaq Service Representative. THIS PRODUCT CONTAINS A NONSPILLABLE BATTERY...
  • Page 32: Connecting Devices To The Ups

    2-10 Compaq 1000 Series UPS Operation and Reference Guide Connecting Devices to the UPS Before connecting devices, verify that the UPS will not overload by making sure that the total VA rating of the devices (the load) does not exceed the VA rating of the UPS.
  • Page 33: Powering Up The Ups

    Installation 2-11 Powering up the UPS When the unit is plugged in for the first time, the UPS automatically initiates a self-test. The front panel LED display lights will go on and off during the self-test. If the self-test is completed successfully, the UPS enters Standby mode.
  • Page 34 2-12 Compaq 1000 Series UPS Operation and Reference Guide 13 12 11 Figure 2-7. The front panel LED display (rack-mountable model) The Front Panel LED Display – All Models Symbol AC Input level Power cord – Site Wiring Fault indicator...
  • Page 35: Completing The Installation

    With the UPS in Standby mode, allow the batteries to charge before putting the UPS into service. IMPORTANT: The batteries will charge to 90% of their capacity within approximately 4 hours. Compaq recommends allowing the batteries to charge for 24 hours before using them to supply backup power to devices.
  • Page 36: Placing The Ups In Operate Mode

    2-14 Compaq 1000 Series UPS Operation and Reference Guide Placing the UPS in Operate mode Press and hold the ON button ( ) until the LED 16 ( , ON LED) turns green, indicating that power is available at the UPS output receptacles. The UPS will acknowledge compliance with a short beep.
  • Page 37: Operation

    Chapter Operation This chapter contains information on the following topics: Precautions to be observed when using the UPS UPS modes of operation Front panel controls Front panel indicators Overcurrent protection Placing the UPS in Operate mode Returning to Standby mode Initiating a self-test The audio alarm...
  • Page 38: Precautions

    3-2 Compaq 1000 Series UPS Operation and Reference Guide Precautions Observe these precautions when using the Compaq 1000 Series UPS models. WARNING: To reduce the risk of electric shock from earth conductor leakage current: Do not operate a UPS that is disconnected from the utility power source.
  • Page 39: Front Panel Controls

    Power is automatically restored to the output receptacles when utility power is restored. Front Panel Controls The 1000 Series UPS front panel includes the controls required to: Place the UPS in Operate mode. Place the UPS in Standby mode. Place the UPS in Configure mode.
  • Page 40 3-4 Compaq 1000 Series UPS Operation and Reference Guide The front panel includes the following LED indicators and button controls: Figure 3-1. The front panel LED display (tower model) 13 12 11 Figure 3-2. The front panel LED display (rack-mountable model)
  • Page 41: Front Panel Indicators

    Operation 3-5 The Front Panel LED Display – All Models Symbol AC Input level Power cord – Site Wiring Fault indicator Battery Charge level Battery – Battery Service indicator Load level Load devices – Communications ON LED ON button STANDBY button TEST/ALARM RESET button Front Panel Indicators The front panel LED display colors indicate the UPS status:...
  • Page 42 3-6 Compaq 1000 Series UPS Operation and Reference Guide AC Input (LEDs 1-4) Table 3-1 AC Input LEDs Color Meaning The utility voltage is higher than the voltage range for which the UPS has been configured. The UPS is supplying battery power.
  • Page 43 Operation 3-7 Battery Charge (LEDs 6-9) Table 3-3 Battery Charge LEDs Color Meaning Green Batteries are between 67% and 100% charged. (LEDs 7 and 8 are also green) Green Batteries are approximately 66% charged. (LED 8 is also green) Green Batteries are approximately 33% charged.
  • Page 44: Overcurrent Protection

    3-8 Compaq 1000 Series UPS Operation and Reference Guide Communication (LED 15) Table 3-6 Communication LED Color Meaning Green The communication link between the UPS and the host computer is active. Flashing Data is being transferred between the UPS and the host Green computer.
  • Page 45: Placing The Ups In Operate Mode

    Operation 3-9 Placing the UPS in Operate Mode The 1000 Series UPS may be placed in Operate mode if either of the following conditions apply: The UPS is powered up and in Standby mode (LED 16 is off) The UPS is powered off; no utility power is available...
  • Page 46: Returning To Standby Mode

    3-10 Compaq 1000 Series UPS Operation and Reference Guide Returning to Standby Mode When the UPS is in Operate mode (LED 16, , is green), pressing the STANDBY button ( ) will place the UPS in Standby mode. The UPS will acknowledge compliance with a short beep.
  • Page 47: Initiating A Self-Test

    Operation 3-11 Initiating a Self-test To initiate a self-test, press the TEST/ALARM RESET button and hold for three seconds. The UPS acknowledges compliance with five beeps. Figure 3-5. The TEST/ALARM RESET button TEST/ALARM RESET button IMPORTANT: A portion of the self-test requires battery power; the self-test cannot be initiated if the batteries are less than 90% charged.
  • Page 48: Audio Alarm

    3-12 Compaq 1000 Series UPS Operation and Reference Guide Audio Alarm The UPS may sound an audio alarm to warn the user that an alarm condition exists. IMPORTANT: Certain audio alarms can be disabled. See Chapter 4, “Configuration,” for more information.
  • Page 49: Configuration

    Chapter Configuration This chapter contains information on the following topics: Placing the UPS in Configure mode Configuration parameters and their LED indicators Using the front panel LED display and controls to monitor and change configuration parameters Using the UPS configuration parameters to optimize battery life by matching utility voltage...
  • Page 50: Placing The Ups In Configure Mode

    4-2 Compaq 1000 Series UPS Operation and Reference Guide Placing the UPS in Configure Mode The Compaq 1000 Series UPS can enter the Configure mode while in the Operate or Standby mode. Figure 4-1. Configure mode controls ON LED (LED 16)
  • Page 51: Configuration Parameters And Their Led Indicators

    Configuration 4-3 Configuration Parameters and their LED indicators In the Configure mode, the front panel LEDs 1 to15 are assigned to eleven configuration parameters , detailed in the following table. (LED 16 indicates the ON or OFF status of each parameter.) Figure 4-2.
  • Page 52 4-4 Compaq 1000 Series UPS Operation and Reference Guide Table 4-1 Configuration Parameters/LED Indicators Parameter Parameter LED 16 Explanation (LED) Name Status 120/230 Nom Nominal utility voltage level is 120/230 VAC. 110/220 Nom Nominal utility voltage level is 110/220 VAC.
  • Page 53 Configuration 4-5 Table 4-1 Configuration Parameters/LED Indicators continued Parameter Parameter LED 16 Explanation (LED) Name Status AC Input Failure Enables an audio alarm when the utility (default) voltage is outside the UPS operating range. Disables the audio alarm for this event. Sleep Mode Enables Sleep mode.
  • Page 54: Changing Configuration Parameters

    4-6 Compaq 1000 Series UPS Operation and Reference Guide Changing Configuration Parameters The Configure mode may be entered from the Operate or Standby mode. IMPORTANT: If the STANDBY button is pressed while in the Configure mode, the UPS will enter Standby mode, and power to the load segments will cease.
  • Page 55 Configuration 4-7 NOTE: For nominal voltage configuration parameters 1, 2, 3, and 10—selecting an ON value for any one parameter automatically sets the other three possibilities to OFF. 5. To scroll through the configuration parameters, press the ON button ( ).
  • Page 56: Optimizing Battery Life By Matching The Utility Voltage

    4-8 Compaq 1000 Series UPS Operation and Reference Guide Optimizing Battery Life by Matching the Utility Voltage Optimize UPS battery life by using the configuration parameters to select the best nominal voltage range for the UPS installation. When utility voltage is outside the selected operating range, the UPS supplies battery power to the load segments.
  • Page 57 Configuration 4-9 Operating Range +20% Extended Nominal Range - 20% -35% Utility Voltage Time Figure 4-6. Utility voltage fluctuation indicating a possible need for extended range setting To match the utility voltage, the UPS operating range can be modified in two ways: If the utility voltage differs from the currently configured nominal voltage, but stays within a ±20 percent band (see Fig 4-5), consider...
  • Page 58 4-10 Compaq 1000 Series UPS Operation and Reference Guide Table 4-2 Operating Ranges (VAC) - North America and Japanese Models Nominal Level Normal Range Extended Range 80 to 120 Not applicable 88 to 132 72 to 132 96 to 144...
  • Page 59: Battery Maintenance

    Chapter Battery Maintenance This chapter contains information on the following topics: Precautions to be observed when maintaining or replacing batteries Charging batteries When to replace batteries Pre-Failure Battery Warranty Obtaining new batteries Replacing batteries Care and storage of batteries...
  • Page 60: Precautions

    WARNING: There is a risk of personal injury from the hazardous energy levels associated with UPS batteries. The maintenance and replacement of batteries must be carried out by qualified service personnel. Replace the batteries with the Compaq spare designated for the UPS. Spare battery kit part numbers are: 1000 models - 295460-001...
  • Page 61: Charging Batteries

    Battery Maintenance 5-3 Charging Batteries The Compaq 1000 Series UPS models automatically charge the batteries when connected to utility power. No user intervention is required while the UPS is in use. For information on charging the batteries when installing the UPS, see “Completing the Installation”...
  • Page 62: Pre-Failure Battery Warranty

    Compaq Power Management Software that the battery may fail, the battery is replaced free of charge under the warranty. Compaq maintains the highest standards in the industry, as evidenced by the Compaq Pre-Failure Battery Warranty. The Pre-Failure Battery Warranty is...
  • Page 63: Obtaining New Batteries

    Battery Maintenance 5-5 Obtaining New Batteries Compaq supplies spare battery packs for 1000 Series UPS models. Obtain spare batteries for the UPS when the Battery Service indicator (LED 10) illuminates, meaning that new batteries may be required within 30 to 60 days.
  • Page 64: Step 2: Removing The Battery Pack

    5-6 Compaq 1000 Series UPS Operation and Reference Guide To replace batteries with the UPS in Operate mode (hot-swapping) Batteries may be replaced (hot-swapped) without powering off the UPS if both of the following conditions are met: The UPS is not charging the batteries (Battery Charge LEDs 6, 7, and 8 are all green, indicating that the batteries are fully charged).
  • Page 65 Battery Maintenance 5-7 Figure 5-3. Detaching the faceplate Faceplate Recesses Upper attachment slots 2. Do not attempt to completely remove the faceplate. For battery maintenance, temporarily reattach the faceplate to the UPS chassis by inserting the lower mounting prongs in the upper attachment slots. Figure 5-4.
  • Page 66 5-8 Compaq 1000 Series UPS Operation and Reference Guide Figure 5-5. Lowering the battery compartment cover plate Screws Battery compartment cover plate 4. Use the plastic tag attached to the battery to partially slide out the battery pack. Access to the battery pack terminals is obtained.
  • Page 67 Battery Maintenance 5-9 5. Disconnect the negative (black) battery pack terminal connection. WARNING: To reduce the risk of short-circuits or arcing, disconnect the negative (black) battery lead before disconnecting the positive (red) battery lead. Figure 5-7. Disconnecting the battery pack terminal connections 6.
  • Page 68 5-10 Compaq 1000 Series UPS Operation and Reference Guide Rack-Mountable Models Follow this procedure to remove the battery pack: 1. Detach the UPS front panel from its attachment slots. Figure 5-8. Detaching the UPS front panel 2. Disconnect the battery connector.
  • Page 69 Battery Maintenance 5-11 3. Remove the two retaining screws securing the battery pack drawer. Figure 5-10. Releasing the battery pack drawer Screws Battery pack drawer CAUTION: Follow appropriate material-handling guidelines to safely remove the battery pack. 4. Slide the battery pack drawer out of the UPS completely, and remove the battery pack.
  • Page 70: Step 3: Installing New Batteries

    5-12 Compaq 1000 Series UPS Operation and Reference Guide Step 3: Installing New Batteries To install new batteries, reverse the steps in “Removing the Battery Pack,” in this chapter. WARNING: To reduce the risk of short-circuits or arcing, connect the positive (red) battery lead before connecting the negative (black) battery lead.
  • Page 71: Care And Storage Of Batteries

    Battery Maintenance 5-13 Care and Storage of Batteries To maximize the life of batteries: Minimize the amount of time the UPS uses battery power by matching UPS configuration with utility voltage. For more information, see Chapter 4, “Configuration.” Keep the area around the UPS clean and dust-free. If the environment is very dusty, clean the outside of the UPS regularly with a vacuum cleaner.
  • Page 72: Troubleshooting

    Chapter Troubleshooting This chapter provides information on the following topics: Troubleshooting problems that occur during UPS start Troubleshooting problems that occur after UPS start Repairing the UPS...
  • Page 73: Troubleshooting During Start

    6-2 Compaq 1000 Series UPS Operation and Reference Guide Troubleshooting During Start If problems occur when starting the Compaq 1000 Series UPS models, select the appropriate symptom for possible causes and actions suggested. Table 6-1 Troubleshooting Guide (UPS Start) Symptom...
  • Page 74: Troubleshooting After Start

    Troubleshooting 6-3 Troubleshooting After Start For problems that occur after the UPS has gone through the startup self-test sequence, these suggested actions address possible causes. Table 6-2 Troubleshooting Guide (After Start) Symptom Possible Cause Suggested Action Audio Alarm Alarm condition exists Identify the red LED associated with this alarm condition.
  • Page 75 6-4 Compaq 1000 Series UPS Operation and Reference Guide Table 6-2 Troubleshooting Guide (After Start) continued Symptom Possible Cause Suggested Action Utility power variations The utility voltage is frequently frequently outside the UPS operating range. switches Update the configuration. between...
  • Page 76: Repairing The Ups

    Shut down the UPS. Contact an flashing red; exists authorized service provider. audio alarm cannot be silenced Repairing the UPS Repairs to the UPS must be carried out by Compaq or a Compaq Authorized Service Provider. Other than battery replacement, there are no user-serviceable parts.
  • Page 77: Regulatory Compliance Notices

    Appendix Regulatory Compliance Notices Federal Communications Commission Notice Part 15 of the Federal Communications Commission (FCC) Rules and Regulations has established Radio Frequency (RF) emission limits to provide an interference-free radio frequency spectrum. Many electronic devices, including computers, generate RF energy incidental to their intended function and are, therefore, covered by these rules.
  • Page 78: Class A Equipment

    A-2 Compaq 1000 Series UPS Operation and Reference Guide Class A Equipment This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 79: Modifications

    Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Compaq Computer Corporation may void the user’s authority to operate the equipment. Cables Connections to this device must be made with shielded cables with metallic RFI/EMI connector hoods in order to maintain compliance with FCC Rules and Regulations.
  • Page 80: Canadian Notice (Avis Canadien

    A-4 Compaq 1000 Series UPS Operation and Reference Guide Canadian Notice (Avis Canadien) Class A Equipment This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.
  • Page 81: Japanese Notice

    Regulatory Compliance Notices A-5 Japanese Notice July 14 version Taiwanese Notice...
  • Page 82: Battery Replacement Notice

    Your UPS is provided with a Sealed Lead Acid battery pack. There is a danger of explosion and risk of personal injury if the battery is incorrectly replaced or mistreated. Replacement is to be done by a Compaq authorized service Provider using the Compaq spare designated for this product. For more information about battery replacement or proper disposal, contact your Compaq authorized reseller or your Authorized service provider.
  • Page 83: Electrostatic Discharge

    Appendix Electrostatic Discharge To prevent damaging the system, be aware of the precautions you need to follow when setting up the system or handling parts. A discharge of static electricity from a finger or other conductor may damage system boards or other static-sensitive devices.
  • Page 84: Grounding Methods

    B-2 Compaq 1000 Series UPS Operation and Reference Guide Grounding Methods There are several methods for grounding. Use one or more of the following methods when handling or installing electrostatic-sensitive parts: Use a wrist strap connected by a ground cord to a grounded workstation or computer chassis.
  • Page 85 Appendix Specifications This appendix provides specifications that apply to Compaq 1000 Series UPS models: Physical specifications Input specifications Output specifications Overcurrent protection Battery specifications Battery runtime Environmental specifications...
  • Page 86: Physical Specifications

    C-2 Compaq 1000 Series UPS Operation and Reference Guide Physical Specifications Table C-1 Physical Specifications - Models T1000 and T1000h Feature U.S. Metric Dimensions Width 7.0 in 178 mm Height 8.8 in 224 mm Depth 17.1 in 444 mm Weight...
  • Page 87: Input Specifications

    Specifications C-3 Input Specifications Table C-4 Input Specifications - Per Model UPS Model Utility Voltage Nominal Utility Power Cord Supplied Frequency (Hz) Voltage (VAC) T1000 100, 110 Non-detachable cord with 5-15p plug 100, 110 120, 127 T1000h 50/60 208, 220 None 230, 240 T1500...
  • Page 88: Output Specifications

    C-4 Compaq 1000 Series UPS Operation and Reference Guide Output Specifications Table C-5 Output Specifications - Per Model UPS Model Nominal Power Load Segment # Output Receptacles Rating (VA) T1000 1000 3 x 5-15R 3 x 5-15R T1000h 1000 3 x IEC-320...
  • Page 89 Specifications C-5 Table C-6 Output Specifications – 1000 Series UPS Models Characteristics Utility Voltage (VAC) Nominal Output Voltage (VAC) Voltage 110 to 127 220 to 240 Source of Power Regulation ±8% of nominal output voltage rating Output Utility power (normal range)
  • Page 90: Overcurrent Protection

    C-6 Compaq 1000 Series UPS Operation and Reference Guide Overcurrent Protection Table C-7 Overcurrent Protection - Per Model UPS Model Input Protection T1000 No protection for load segments T1000h Input circuit breaker T1500 No protection for load segments T1500j No protection for load segments...
  • Page 91: Battery Runtime

    Specifications C-7 Battery Runtime Table C-9 Estimated Battery Runtime (Minutes) 1000 1500 Rack-Mountable Total Load (VA) Tower Models Tower Models Models 1000 1200 1400 1500 Note: Volts x Amps = VA per device. Add all device VAs for total load. If a device lists the power in Watts, use the following conversion equation: Watts x 1.35 = VA VA/1000 = KVA...
  • Page 92: Environmental Specifications

    C-8 Compaq 1000 Series UPS Operation and Reference Guide Environmental Specifications Table C-10 Environmental Specifications - 1000 Series UPS Models Feature Specification Operating temperature to 40 C (32 to 104 UL-tested at 25 C (77 Relative humidity 0% to 95%; non-condensing...
  • Page 93 Index Numbers and Symbols 1000 Series UPS See batteries Uninterruptible Power System care and storage See care and 1000 Series storage of batteries changing See also replacing batteries procedures 5-5 AC Input Failure warning on rack stability 5-2 disabling audio alarm 4-5...
  • Page 94 2 Compaq 1000 Series UPS Operation and Reference Guide communications port recommendation against keeping caution on cable use 1-7 spares 5-5 caution on communications when to obtain 5-5 cables 2-5 connecting to the host replacing See replacing computer 2-5 batteries...
  • Page 95 Network Transient enabling 4-4 Protector 1-10 Configure mode Remote Emergency Power exiting 4-7 Off 1-10 explained 3-2 UPS 1000 Series 1-6 initiating 3-3 warranties 1-11 connecting Federal Communications devices to UPS 2-10 Commission (FCC) notice A-1 Network Transient cables A-3...
  • Page 96 4 Compaq 1000 Series UPS Operation and Reference Guide rack-mountable model, completing the illustrated 3-4 installation 2-13 tower model, illustrated 3-4 connecting the communications LED meaning port 2-5 green LEDs 3-5 connecting the communications in Configure mode 4-6 port, illustrated 2-6...
  • Page 97 Index 5 LanSafe III Network Transient Protector overview 1-7 connecting 2-6 using the UPS’s Comm features 1-10 Port 2-5 overview 1-10 LED 01 See AC Input LEDs nominal utility voltage level explained 4-4 LED 02 See AC Input LEDs related configuration LED 03 See AC Input LEDs parameters 4-4 LED 04 See AC Input LEDs...
  • Page 98 6 Compaq 1000 Series UPS Operation and Reference Guide Compaq Multi-Server UPS Card PBX, connecting to digital 1-10 example of use 1-8 physical specifications overview 1-8 T1000 and T1000h C-2 Compaq Scalable UPS Card T1500, T1500j, and example of use 1-9...
  • Page 99 See TEST/ALARM sequence 1-8 RESET button using Compaq Power meaning of LED display 3-11 Management Software 1-7...
  • Page 100 8 Compaq 1000 Series UPS Operation and Reference Guide utility voltage range See operating range technical support x telephone numbers xi TEST/ALARM RESET button exiting Configure mode 4-7 VCCI Notice for Japan A-5 initiating a self-test 3-11 voltage level initiating Configure mode 4-2,...
