Musical Fidelity X-Pre V3 Instructions For Use

V 3
X-Pre SPECIFICATIONS
Output : Voltage RMS, maximum
Impedance
Frequency response
Line inputs :
Total harmonic distortion + noise, :
20Hz to 20kHz
Signal / noise ratio reference :
Input sensitivity for 1 Volt RMS out :
Input impedance :
Gain at maximum volume :
Overload margin :
Channel separation :
Phono input : (moving magnet type)
Frequency response reference
IEC RIAA - see graph . . . .
Signal / noise ref. 1 Volt RMS output
Input sensitivity for 1 V RMS output
Input impedance
Overload margin
Input facilities :
Output facilities :
Power requirement :
Dimensions :
Weight :
Standard accessories :
Musical Fidelity reserves the right to make improvements which
may result in specification or feature changes without notice.
Page 8 of 8 X-Pre
> 31.8 Volts
< 47 Ohms
10Hz to 40kHz ±0.5dB
< 0.005% (1 Volt output, half volume)
> 93dB 'A'-weighted
1 Volt RMS output
208mV
47k Ohms
13.6dB (4.8 times)
35dB
> 88dB typical at 1kHz, half volume
20.0
15.0
10.0
PHONO RESPONSE
5.0
dB 0.0
RIAA
-5.0
PHONO
-10.0
RIAA/IEC
-15.0
-20.0
20.0 31.5 50.0 80.0 125 200 315 500 1000 1600 2500 4000 6300 10000 16000
Frequency (Hz)
> 70dB ("A"-weighted, at half volume)
2mV
47k Ohms
24dB
3 pairs RCA line level connectors
1 pair RCA phono input connectors (moving magnet)
1 pair RCA audio outputs controlled by the volume,
1 pair RCA tape record fixed line level output.
100 / 115 / 230Volts AC 50 / 60Hz, 5 Watts
218mm, 8.6 inches wide
98 mm, 3.9 inches high (including feet)
374mm, 14.7 inches deep (including knob and
rear earth terminal)
5.8 kg, 12.8 lbs unit only, unboxed
7.2 kg, 15.9 lbs in carton
IEC type mains lead (10-Amp type),
Remote control handset (universal type),
2 batteries size LR03 or AAA, manganese alkaline type
V 3
Issue 1 : July 2004
.
PRE AMPLIFIER
INSTRUCTIONS FOR USE
Thank you for purchasing the Musical Fidelity
V 3
X-Pre pre-amplifier.
Used properly and carefully, it should give you many years of
outstanding musical reproduction.
V 3
Aesthetically, the X-Pre is a perfect match for the
X-RAY V 3 CD player and X-P200 amplifier.
Together, they form one of the finest hi-fi systems available.
Dust regularly with a soft cloth or soft brush, but be careful when
using cleaning or polishing agents - they may harm the surface
finish.
If you have any questions about your audio system,
please consult your dealer who is there to help and advise.
V 3
X-Pre Page 1 of 8
.
