SPECIFICATIONS
Output power
200 Watts RMS into 8Ω
THD
< 0.09% 20Hz-20kHz unweighted
< 0.01% 20Hz-20kHz 'A' weighted
< 0.003% 20Hz-20kHz @ 1W unweighted
Frequency response
10Hz-50kHz + 0.5dB
5Hz-80kHz + 1dB
S/N ratio
> 107 dB unweighted
> 120 dB 'A' weighted
Power consumption
400W
Power requirements
100/115/230V 50/60Hz AC
(factory preset for country)
Dimensions (mm)
170 x 175 x 430 approx. (W x H x D)
width and height include feet, depth
includes terminals
Musical Fidelity reserves the right to make improvements which may result in
specification or feature changes without notice.
INSTRUCTIONS FOR USE
Advertisement
Related Manuals for Musical Fidelity X-A200
Summary of Contents for Musical Fidelity X-A200
-
Page 1: Specifications
(factory preset for country) Dimensions (mm) 170 x 175 x 430 approx. (W x H x D) width and height include feet, depth includes terminals Musical Fidelity reserves the right to make improvements which may result in specification or feature changes without notice. - Page 2 Place all connecting cables where they are not likely to be walked on or trapped by items placed on them. The X-A200 has a "Loop Out" facility to allow for easy bi-amping of speakers with bi-wireable crossovers. In this kind of set-up typically one...
