SPECIFICATIONS
MM input
Sensitivity
3mV for 350mV output at 1kHz
Input impedance
47K Ohms
THD
< 0.01% at 1kHz, 350mV out
Input overload margin
30dB
S/N ratio
> 75dB unweighted
> 83dB "A" weighted
MC input
Sensitivity
350µV for 350mV output at 1kHz
Input impedance
100 Ohms
THD
< 0.01% at 1kHz, 350mV out
Input overload margin
30dB
S/N ratio
> 65dB unweighted
> 74dB "A" weighted
General
RIAA accuracy
± 0.25dB 20Hz to 20kHz
Power requirement
12 - 0 - 12Volts AC 500mA
(via mains adaptor supplied)
Dimensions
180mm
88.2mm (3.5") high including feet
208mm
Weights
Unit, net :
Adaptor, net :
Total packed : 3.1 kg
Musical Fidelity reserves the right to make improvements which may result in
specification or feature changes without notice.
(7.1") wide
(8.2") deep
2.5 kg
(5 lbs 8 oz)
0.45 kg (1 lb)
(6 lbs 13 ozs)
X-LPS v3 Issue 1 : April 2003
STEREO PHONO PRE-AMPLIFIER
Instructions for use
X-LPS v3 Issue 1 : April 2003
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Musical Fidelity X-LPS V3
Summary of Contents for Musical Fidelity X-LPS V3
-
Page 1: Specifications
0.45 kg (1 lb) Total packed : 3.1 kg (6 lbs 13 ozs) Musical Fidelity reserves the right to make improvements which may result in specification or feature changes without notice. X-LPS v3 Issue 1 : April 2003 X-LPS v3 Issue 1 : April 2003... -
Page 2: Installation Precautions
X-LPS (marked with the earth symbol). However, if a problem persists, please contact your Musical Fidelity agent. Never open the case of the X-LPS yourself, as this will invalidate the guaran- Connect the low voltage AC output lead from the accessory mains adaptor to tee.
