SPECIFICATIONS
Inputs
4 Line level
THD
< 0.007% 20Hz-20kHz unweighted
< 0.005% 20Hz-20kHz 'A' weighted
Frequency response
+ 0.3dB 20Hz-20kHz
Crosstalk
> 63dB separation
S/N ratio
> 78dB unweighted
> 88dB 'A' weighted
Valve type
2 x ECC88
Power requirement
12V AC 500mA (via mains
adaptor supplied)
Dimensions (mm)
110 x 110 x 220 (W x H x D)
Width and height include feet
Musical Fidelity reserves the right to make improvements which may result in
specification or feature changes without notice.
INSTRUCTIONS FOR USE
Advertisement
Related Manuals for Musical Fidelity X-PRE
Summary of Contents for Musical Fidelity X-PRE
-
Page 1: Specifications
12V AC 500mA (via mains adaptor supplied) Dimensions (mm) 110 x 110 x 220 (W x H x D) Width and height include feet Musical Fidelity reserves the right to make improvements which may result in specification or feature changes without notice. - Page 2 Do not use the X-PRE near water. Each of your line level sources should be connected to an input on the back of the X-PRE and then the X-PRE's output connected to Keep the X-PRE away from heat sources such as the input of your amplifier system.
