SPECIFICATIONS
MM input
Sensitivity
3mV for 350mV output
Input impedance
47K
THD
< 0.01% @ 1kHz, 350mV out
Input overload margin
30dB
S/N ratio
> 75dB unweighted
> 82dB "A" weighted
MC input
Sensitivity
350uV for 350mV output
Input impedance (switchable)
100R, 50R, 25R or 10R
THD
< 0.01% @ 1kHz, 350mV out
Input overload margin
30dB
S/N ratio
> 65dB unweighted
> 74dB "A" weighted
General
RIAA accuracy
+ 0.5dB 20Hz-20kHz
Power requirement
12V AC 500mA
(via X-PSU supplied)
Dimensions (mm)
110 x 110 x 220 (W x H x D)
width and height include feet
Musical Fidelity reserves the right to make improvements which may result in
specification or feature changes without notice.
XLP 2 issue 3 November 1999
INSTRUCTIONS FOR USE
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Musical Fidelity X-LP2
Summary of Contents for Musical Fidelity X-LP2
-
Page 1: Specifications
Dimensions (mm) 110 x 110 x 220 (W x H x D) width and height include feet Musical Fidelity reserves the right to make improvements which may result in specification or feature changes without notice. XLP 2 issue 3 November 1999... -
Page 2: Installation Precautions
There are no adjustments within. on the rear of both X-LP Please refer all service work to an authorised Musical Fidelity agent. Connect two of the outputs from the X-PSU to the PSU inputs on both of the X-LP .
