SANTA FE COMPACT2 INSTALLER'S AND OWNER'S MANUAL
Thank you for purchasing the Santa Fe Compact. For questions regarding this product
or to order parts/accessories, contact your dealer or call TOLL-FREE 1-800-533-7533.

Table of Contents

Precautions .........................................................2
1. Intended Application(s) .........................................2
2. Registrations .......................................................3
3. Specifications ......................................................3
4. Unit Assembly .....................................................3
4.1 Installing Feet ......................................................3
4.2 Drain Hose ..........................................................3
5. Installation ..........................................................3
5.1 Safety Precautions ..............................................3
5.2 Location ...............................................................3
5.3 Electrical Requirements .......................................3
5.4 Condensate (Water) Removal ...............................3
6. Operation ............................................................4
6.1 Humidity Control Adjustment ...............................4
6.2 Defrost Cycle .......................................................4
6.3 Fan Operation ......................................................4
7. Maintenance .......................................................4
7.1 Air Filters .............................................................4
7.2 Cleaning Pre-filter ...............................................5
7.3 Pleated Filter .......................................................5
7.4 Removing Filters .................................................5
7.5 Installing Filters ...................................................5
8. Service ................................................................5
8.1 Technical Description ..........................................5
8.2 Troubleshooting ...................................................5
8.3 Refrigerant Charging ............................................6
8.4 Compressor/Capacitor Replacement ....................6
9. Replacement Parts/Accessories ..........................6
10. Wiring Diagram ...................................................6
Warranty .............................................................7

Precautions

• Never operate a unit with a damaged power cord. If
the power cord is damaged, it must be replaced by the
manufacturer, its service agent, or a similarly qualified
person in order to avoid a hazard.
• Do not unplug the unit by pulling on the cord. Grasp the
plug firmly and pull it out of the wall socket or power
receptacle.
• When plugging in the unit, use a Ground Fault Interrupter
outlet.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience or knowledge, unless
they have been given supervision or instruction concerning
the use of the appliance by a person responsible for their
safety. Children should be supervised to ensure that they
do not play with the appliance.
• Never operate electrical equipment near or in standing
water.
• Do not stick your fingers or other objects through the
safety grill.
• The unit must be used in the upright position.
• When changing filters, do not stick fingers or other objects
in the unit.
• Do not restrict airflow in to or out of the unit. This may
cause the unit to overheat.
• The unit should never be serviced or cleaned while it is
plugged in.
• Do not sit or stand on the unit, or use as a shelf or table.
• Before leaving the unit unattended, ensure children do not
have access to the equipment. Do not allow children to play
with or near the unit or in its air flow.
• The unit is designed to be installed indoors only.
• No user serviceable components. Contact installer or call
1-800-533-7533 for all repair or warranty needs.
Read the installation, operation and maintenance instructions
carefully before installing and using this unit. Proper
adherence to these instructions is essential to obtain
maximum benefit from your Santa Fe dehumidifier.
Read and Save These Instructions
WARNING!
instructions. Failure to heed them can result in serious
injury or death.
CAUTION!
instructions. Failure to heed them can result in injury or
material property damage.

1. Intended Application(s)

The Santa Fe Compact2 is intended for use in crawlspaces
or basements: however, the unit can be placed in almost
any residential setting where dehumidification is desired.
Use in non-residential applications and pool areas may void
warranty.
The Santa Fe Compact2 is designed to operate in
temperatures between 49° and 95°F. This unit works most
effectively between 56° and 95°.
In order to efficiently control humidity levels, the area in
which the dehumidifier is to be operated must be free of
water intrusion or excessive fresh (outside) air infiltration.
Before installing the Santa Fe Compact2, water intrusion and
air infiltration problems should be addressed.
2
- This symbol means important
- This symbol means important
Santa Fe Compact2 Installer's & Owner's Manual
