ULTRA SERIES | ULTRA98/120
Installation & Operation Instructions
The Santa Fe ULTRA98 and ULTRA120 are
ventilating dehumidifiers that integrate into the
heating and cooling system to provide the ultimate
in comfort, health and property protection through:
+ Dehumidification
+ Fresh Air Ventilation (Optional)
+ Air Filtration
* The Santa Fe Ultra98/120 was previously known as the Ultra Aire 98H/120H.
800.533.7533 | Santa-Fe-Products.com
Santa-Fe-Products.com | 800.533.7533
Serial Number
Install Date
Sold By
Patent: thermastor.com/patents
Santa Fe ULTRA98/ULTRA120 Installation & Operation Instructions
1
TS-1126 04/21 Rev A
Advertisement
Table of Contents
Related Manuals for Santa Fe ULTRA Series
Summary of Contents for Santa Fe ULTRA Series
- Page 1 + Dehumidification + Fresh Air Ventilation (Optional) + Air Filtration Patent: thermastor.com/patents * The Santa Fe Ultra98/120 was previously known as the Ultra Aire 98H/120H. 800.533.7533 | Santa-Fe-Products.com Santa Fe ULTRA98/ULTRA120 Installation & Operation Instructions Santa-Fe-Products.com | 800.533.7533 TS-1126 04/21 Rev A...
-
Page 2: Table Of Contents
Warranty ......................19 FOR REPAIR & TECH SUPPORT: 1-800-533-7533 (follow prompts) or CONTACT US AT: service@madisoniaq.com Santa Fe is committed to manufacturing quality products. To maintain our standards, product specifications may change without notice. 4201 Lien Road, Madison, WI 53704 (800) 533-7533 Thermastor.com | Santa-Fe-Products.com... -
Page 3: Safety Instructions
CAUTION! THIS SYMBOL MEANS IMPORTANT INSTRUCTIONS. FAILURE TO HEED THEM CAN RE- SULT IN INJURY OR MATERIAL PROPERTY DAMAGE. Registrations This Santa Fe dehumidifier conforms to unified standard UL 60335-2-40 and CSA standard C22.2.60335-2-40. WARNING! WARNING! 120 VOLTS MAY CAUSE SERIOUS INJURY FROM ELECTRIC SHOCK. -
Page 4: Dehumidifier Set Up
• DO NOT place the dehumidifier directly on structural building members without vibration absorbers or unwanted noise may result. Place the Santa Fe Dehumidifier on supports to raise the base of the unit. • A drain pan with a float switch MUST be placed under the dehumidifier if installed above a living area or above an area where water leakage could cause damage. -
Page 5: Attaching Duct Collars
10" Supply Air Outlet 10" Supply Air Outlet 10" Supply Air Outlet Front View Front View Rear View Rear View Front View Front View Rear View Rear View Top View Top View 800.533.7533 | Santa-Fe-Products.com Santa Fe ULTRA98/ULTRA120 Installation & Operation Instructions... -
Page 6: Electrical Requirements
Santa Fe offers a variety of control devices for use with the Santa Fe Dehumidifier. The control is to be located remotely from the dehumidifier and placed in the space to be conditioned. A low voltage (24 Volt) control MUST be used with the Santa Fe Dehumidifier and MUST be connected with low voltage (18-22 gauge) thermostat wire. -
Page 7: Drain Installation
This switch should be installed in series with the field wire that connects to the common lead from the Santa Fe Dehumidifier to the control panel. If the pump fails, this switch opens the common control circuit and stops water production before the reservoir overflows. Contact a qualified electrician to install the safety float switch to the Santa Fe Dehumidifier. -
Page 8: Ducting To Hvac Systems
The recommended installation creates a separate return for the Santa Fe Dehumidifier in a central area of the structure. Duct the supply of the unit to the air supply of the existing HVAC system. Connect an insulated duct from outside to the 6" collar of the Santa Fe Dehumidifier to provide fresh make-up air. CAUTION! CAUTION! DO NOT CONNECT WITH A STATIC PRESSURE GREATER THAN OR EQUAL TO +0.5 WG. -
Page 9: Recommended Hvac System Installation
• Install a dedicated 10" air return for the Santa Fe Dehumidifier from a central area of the structure. • Install an insulated duct from outside to the 6" collar of the Santa Fe Dehumidifier to provide fresh air ventilation (optional). -
Page 10: Fresh Air Ventilation
The time and frequency of ventilation should be based on the size and occupancy of the residence. • The fresh air ventilation duct should be connected to the 6" round collar on the front of the Santa Fe Dehumidifier. -
Page 11: Determine Ventilation Requirements
< 500 501 - 1000 1001 - 1500 1501 - 2000 2001 - 2500 2501 - 3000 3001 - 3500 Table 4.1 from ASHRAE 62.2-2016 Record the required CFM ____________ 800.533.7533 | Santa-Fe-Products.com Santa Fe ULTRA98/ULTRA120 Installation & Operation Instructions... -
Page 12: Controls
CONTROLS A control must be used with the Santa Fe Dehumidifier. Santa Fe offers the DEH 3000 proprietary control. The DEH 3000 allows homeowners to monitor and control relative humidity and proper ventilation levels in their home. This control is also available with a remote sensing option. - Page 13 The control and the Santa Fe Dehumidifier are labeled to prevent confusion. Depending on the control, some of the screw terminals on the Santa Fe Dehumidifier may not be used. Be sure to consult the electrical schematic in this manual or inside the access panel of the Santa Fe Dehumidifier before making control connections.
-
Page 14: Air Filtration
AIR FILTRATION The Santa Fe Dehumidifier is equipped with a MERV-13 (Dimensions: 1.75” x 14.00” x 17.50”) filter. The filter should be checked and replaced every three to six months. Operating the unit with a dirty filter will reduce dehumidifier capacity and efficiency. -
Page 15: Merv Rating Chart
Sanding Dust <20% 65-70% Spray Paint Dust Electrostatic - Self charging woven panel filter. Textile Fibers Window A/C Units <20% <65% Carpet Fibers Table Data Source: United States Environmental Protection Agency 800.533.7533 | Santa-Fe-Products.com Santa Fe ULTRA98/ULTRA120 Installation & Operation Instructions... -
Page 16: Service
9. If this test works, then the field control wiring 5. Dirty air filter(s) or air is ok. flow restricted. 10. If the problem persists, then the control is 6. Defective fan or relay. most likely faulty. Santa Fe ULTRA98/ULTRA120 Installation & Operation Instructions Santa-Fe-Products.com | 800.533.7533... - Page 17 7. Collecting the water removed in a 24 hour period 8. Defective compressor. will give a measurement of performance. 9. Restrictive ducting. 800.533.7533 | Santa-Fe-Products.com Santa Fe ULTRA98/ULTRA120 Installation & Operation Instructions...
- Page 18 Refrigerant Charging WARNING! WARNING! SERVICING THE SANTA FE DEHUMIDIFIER WITH ITS HIGH PRESSURE REFRIGERANT SYSTEM AND HIGH VOLTAGE CIRCUITRY PRESENTS A HEALTH HAZARD WHICH COULD RESULT IN DEATH, SERIOUS BODILY INJURY, AND/OR PROPERTY DAMAGE. SERVICE MUST BE PERFORMED BY A QUALIFIED SERVICE TECHNICIAN.
-
Page 19: Warranty
WARRANTY Limited Warranty. Therma-Stor, LLC (“Therma-Stor”) warrants as follows: (i) the Santa Fe dehumidifier dehumidifier (“Product”) will be free of material defects in workmanship or materials for a period of two (2) years (“Two-Year Warranty”) following the date of initial purchase of such Product by an original customer purchasing from Therma-Stor or an authorized reseller (“Customer”);... - Page 20 Santa-Fe-Products.com 1.800.533.7533...
