Harbor Breeze LAKE PLACIDO CPK1261 Installation Manual

Hide thumbs

Table Of Contents

Harbor Breeze

is a registered trademark

ATTACH YOUR RECEIPT HERE

Serial Number

Questions, problems, missing parts? Before returning to your retailer, call our customer

service department at 1-800-643-0067, 8 a.m. - 6 p.m., EST, Monday - Thursday,

8 a.m. - 5 p.m., EST, Friday.

EB14429

LAKE PLACIDO CEILING FAN

Purchase Date

ITEM #0451824

MODEL #CPK1261

Español p. 20

Lowes.com/harborbreeze

Table of Contents

Need help?

Do you have a question about the LAKE PLACIDO CPK1261 and is the answer not in the manual?

Questions and answers

Connie

June 23, 2025

How to get your the lightbulbs to change on a Harbor Breeze Lake Placido ceiling fan?

Summary of Contents for Harbor Breeze LAKE PLACIDO CPK1261

Page 1 ITEM #0451824 LAKE PLACIDO CEILING FAN MODEL #CPK1261 Español p. 20 Harbor Breeze ® is a registered trademark of LF, LLC. All Rights Reserved. ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-800-643-0067, 8 a.m.
Page 2: Table Of Contents
TABLE OF CONTENTS Package Contents....................... Hardware Contents......................Safety Information....................... Preparation ......................... Initial Instructions ........................ Standard/Angle-Mounting Instructions................. Flushmount Instructions ...................... Wiring Instructions ......................Final Instructions ......................... Operating Instructions ......................Care and Maintenance ....................... Troubleshooting........................Limited Lifetime Warranty....................Replacement Parts List ...................... Lowes.com/harborbreeze...
Page 3: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY Finial Mounting Bracket (preassembled on Light Kit (J)) Downrod Assembly Bulb Coupling Canopy (preassembled on Motor Housing (F)) Canopy Cover Mounting Bracket Screw (preassembled on Canopy (C)) (preassembled on Mounting Bracket (A)) Clevin Pin Coupling Cover (preassembled on Coupling (P))
Page 4: Hardware Contents
(not shown actual size) HARDWARE CONTENTS Blade Screw Wire Connector Qty. 15 + 1 extra Qty. 4 Motor Screw Qty. 2 Qty. 10 + 1 extra SAFETY INFORMATION READ AND SAVE THESE INSTRUCTIONS Please read and understand this entire manual before attempting to assemble, operate or install the product. .
Page 5: Preparation
WARNING CAUTION PREPARATION Estimated Assembly Time: Lowes.com/harborbreeze...
Page 6: Initial Instructions
INITIAL INSTRUCTIONS 1. Turn off circuit breakers and wall switch to the fan supply line leads. DANGER: Failure to disconnect power supply prior to installation may result in serious injury or death. 2a. Choose the desired mounting method: A. Standard Mounting: Standard mounting is best suited for ceilings 8 ft.
Page 7: Standard/Angle-Mounting Instructions
INITIAL INSTRUCTIONS 3. Check existing outlet box (not included) to ensure it is securely fastened to at least two points in a structural ceiling member and can support the full weight of the fan. Once verified, install mounting bracket (A) to the outlet box using the screws and washers provided with the outlet box.
Page 8 STANDARD/ANGLE-MOUNTING INSTRUCTIONS 2. Feed power wires from motor housing (F) through downrod assembly (B), then insert downrod assembly (B) into the coupling (P) on motor housing (F). Align the hole on downrod assembly (B) to hole on coupling (P), then re-install clevis pin (R). Re-attach hairpin clip (S) into clevis pin (R) until it snaps into place, then tighten the two previously loosened coupling screws (T).
Page 9: Flushmount Instructions
FLUSHMOUNT INSTRUCTIONS 1. Remove canopy cover (D) by pressing out on the inner edges of the canopy cover until it releases from the canopy (C). Note: Flushmount installation will not use canopy cover (D), downrod assembly (B), clevis pin (R), hairpin clip (S) or coupling screws (T).
Page 10: Wiring Instructions
WIRING INSTRUCTIONS WARNING: To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before hanging. WARNING: If you are not sure if the outlet box is grounded, contact a licensed electrician for advice, as it must be grounded for safe operation. WARNING: If house wires are different colors than referred to in the following steps, stop immediately.
Page 11: Final Instructions
WIRING INSTRUCTIONS Wrap electrical tape (not included) around each wire Outlet Box connector and make sure no bare wire or wire strands are visible after making connections. Then, turn wires upward and carefully push them into the outlet box; make sure the WHITE and GREEN connections are on GREEN one side and the BLACK connections are on the other side.
Page 12 FINAL INSTRUCTIONS 3. Secure one blade/blade iron assembly to the flywheel, using the motor screws (CC) through the holes located on the side of the flywheel. Repeat the procedure for the remaining blade/blade iron assemblies. Hardware Used Motor Screw x 10 Flywheel 4.
Page 13 FINAL INSTRUCTIONS 6. Remove one of the switch housing screws (W) from the switch housing (I) and loosen the other two. 7. Attach the connector from the light kit (J) to the connector from the motor housing (F). Attach the light kit (J) to the switch housing (I) by placing the keyslot holes from the light kit (J) onto the two protruding switch housing screw (W) heads.
Page 14 FINAL INSTRUCTIONS 9. Install the glass bowl (K) into light case (L), aligning the holes in glass bowl (K) and light case (L). 10. Thread the fan pull chain through the slot in the side of light assembly and the light pull chain into the center hole of light assembly.
Page 15: Operating Instructions
FINAL INSTRUCTIONS 12. Assemble fobs (DD) to appropriate pull chains. Hardware Used OPERATING INSTRUCTIONS 1. The fob (DD) marked with a fan image is for motor speed control: High, Medium, Low and Off. Pull once for each position. The fob (DD) marked with a light image controls the light either On or Off with each pull of the chain.
Page 16: Care And Maintenance
CARE AND MAINTENANCE Important: Shut off main power supply before beginning any maintenance. Do not use water or a damp cloth to clean the ceiling fan. . At least twice each year, tighten all screws and lower canopy to check mounting plate screws. .
Page 17 TROUBLESHOOTING PROBLEM PROBABLE CAUSE CORRECTIVE ACTION 6. Blade holders are loose. 6. Check to be sure the fan blade irons seat firmly and uniformly on the surface of the motor. If flanges are seated incorrectly, loosen the flange screws and retighten.
Page 18: Limited Lifetime Warranty
This warranty supersedes all prior warranties. NOTE: A small amount of “ wobble ” is normal and should not be considered a defect. Printed in China Harbor Breeze is a registered trademark of LF, LLC. All Rights Reserved. ®...
Page 19: Replacement Parts List
A188-0127348 Light Kit A187-0297348 Glass Bowl A182-0285036 Light Case A183-0091348 Finial Cover A183-0089348+B123-0022005 Finial A186-0128348 Wire Connector Blade Screw B168-0389070 Motor Screw Printed in China Harbor Breeze is a registered trademark of LF, LLC. All Rights Reserved. ® Lowes.com/harborbreeze Lowes.com/harborbreeze...
