25mm
250mm
Fig. 4
450mm
for Servicing
purposes
50mm
In operation
Fig. 5
© Baxi Heating UK Ltd 2013
25mm
4.0 Clearances
4.1
For your Safety
This appliance must have been installed in
accordance with the manufacturer's instructions
and the regulations in force.
Any modification that may interfere with the
normal operation of the appliance without
express written permission from the manufacturer
or his agent could invalidate the appliance
warranty. In GB this could also infringe the Gas
Safety (Installation and Use) Regulations.
GB - Heating Industry definition meaning England,
Scotland, Wales, Northern Ireland, Isle of Man and
the Channel Isles
Your boiler must not be operated without the
casing correctly fitted and forming an adequate
seal.
Do not interfere with any sealed components on
this boiler.
Take note of any warning labels on your boiler.
Your boiler should have the following minimum
clearances for Safety and Maintenance
(Fig. 4 & 5):-
Top
Left side
Right Side
Front
If your boiler is installed in a compartment, do not
use it for storage purposes. Do not obstruct any
purpose provided ventilation openings.
Flammable materials must not be stored in close
proximity to your boiler.
Avoid skin contact when your boiler is in
operation, as some surfaces may get hot i.e.
pipework, flue.
Ensure that the flue terminal, outside the house,
does not become damaged or obstructed,
particularly by foliage.
It is important that the condensate drain system
is not blocked, modified or damaged in any way
as this would affect the operation of your boiler.
Your installer should have insulated any exposed
pipework.
- 250mm
- 25mm
- 25mm
- 50mm (In Operation)
- 450mm (For Servicing)
7
