Card reader board

Description
Card reader board
Card reader board cable
Before removing the card reader board, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see
5. Remove the battery (see
6. Remove the hard drive (see
7. Remove the speakers (see
Remove the card reader board:
1. Remove the two broadhead Phillips PM2.0×3.0 screws (1) that secure the card reader board to the
computer.
2. Remove the card reader board (2).
Reverse this procedure to install the card reader board.
Bottom cover on page
Battery on page 54).
Hard drive on page 55).
Speakers (front) on page
35).
57).
Component replacement procedures
Spare part number
812694-001
812680-001
63
