INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
WARNING:
If the information in these
instructions is not followed exactly a fire or
explosion may result causing property
damage, personal injury or death.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapours and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical Switch.
• Do not use any phone in your building.
• Immediately call your gas supplier
from a neighbour's phone. Follow the
gas supplier's instructions.
• If you cannot reach your gas supplier
call the fire department.
Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
This appliance may be installed in an
aftermarket permanently located,
manufactured home (USA only) or mobile
home, where not prohibited by local codes.
This appliance is only for use with the type of
gas indicated on the rating plate. This
appliance is not convertible for use with
other gases unless a certified kit is used.
This appliance is suitable for installation in a
bedroom or bed sitting room.
020215-36
BROADWAY & BRENTWOOD
INSTALLATION AND
OPERATING INSTRUCTIONS
MODEL: BROADWAY /
BRENTWOOD
SERIES: A
DIRECT VENT GAS INSERT
5055.66-E
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pacific energy BROADWAY
Summary of Contents for Pacific energy BROADWAY
-
Page 1: Operating Instructions
• Do not try to light any appliance. • Do not touch any electrical Switch. • Do not use any phone in your building. BROADWAY & BRENTWOOD • Immediately call your gas supplier INSTALLATION AND from a neighbour’s phone. Follow the OPERATING INSTRUCTIONS gas supplier’s instructions. -
Page 2: Important Note For The Commonwealth Of Massachusetts
Important Note for the Commonwealth of Massachusetts: From Massachusetts Rules and Regulations 248 CMR 5.08: For all side wall horizontally vented gas fuelled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied. -
Page 3: Table Of Contents
Log Set Installation/Removal ......27 Rustic Log Set Installation/Removal ....28 Glass Burner Kit Installation/Removal ....29 Replacement Parts / Kits List ......31 Wiring Diagram ..........32 Broadway Rating Label ........33 Brentwood Rating Label ........34 5055.66-E 020215-36... -
Page 4: Caution
Caution FOR YOUR SAFETY - Do not install or operate your Pacific Energy appliance without first reading and understanding this manual. Any installation or operational deviation from the following instructions voids the Pacific Energy Warranty and may prove hazardous. This appliance and its individual shut off valve must be disconnected from gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psig (3.5 kPa). -
Page 5: Safety
Safety • Due to high temperatures, this gas appliance should be located out of traffic and away from furniture and draperies. • Children and adults should be alerted to the hazards of high surface temperatures and should stay away to avoid burns or clothing ignition. •... -
Page 6: Owners Information
OWNER’S INFORMATION Congratulations on your purchase of a Pacific Energy Gas Appliance. Your fireplace has been professionally installed by: Dealer name: ___________________ Phone Number:_________________ If you discover any problems with your gas appliance contact your dealer immediately to have the unit repaired. -
Page 7: Remote Control
OWNER’S Remote Control Operation INFORMATION System Description The Proflame Remote Control System consists of two elements: 1. Proflame Transmitter. 2. Proflame Integrated Fireplace Control (IFC) board and a wiring harness to connect the IFC to the gas valve and stepper motor. Transmitter (Remote Control with LCD Display) The Proflame Transmitter uses a streamline design with a simple button layout and informative LCD display (Fig. -
Page 8: Operating Procedure
OWNER’S INFORMATION IFC Module The Proflame 2 Integrated Fireplace Control (IFC) board (Fig. 3) is a device located at the rear side of the fireplace or stove, that allows the automatic ignition and pilot flame supervision, and to command the functions of a hearth appliance. It is configured to control the ON/OFF main burner operation via a hand-held transmitter unit (Fig. - Page 9 OWNER’S INFORMATION Temperature indication Display With the system in the “OFF” position, press the Thermostat Key and the Mode Key at the same time. Look at the LCD screen on the transmitter to verify that a C or F is visible to the right of the Room Temperature display. (Fig.
- Page 10 OWNER’S INFORMATION Remote Flame Control The Proflame has six (6) flame levels. With the system on, and the flame level at the maximum in the appliance, pressing the down arrow key once will reduce the flame height by one step until the flame is turned off.
- Page 11 OWNER’S INFORMATION Comfort Fan Speed Control If the appliance is equipped with a hot air circulating fan, the speed of the fan can be controlled by the Proflame system. The fan speed can be adjusted through six (6) speeds. To activate this function use the Mode Key (fig.1) to locate the fan control icon (Fig. 13). Use the Up/Down Arrow Keys (Fig.1) to turn on, off or adjust the fan speed (fig.
- Page 12 OWNER’S INFORMATION Low Battery Power Detection Transmitter The life span of the remote control batteries depends on various factors: the quality of the batteries used, the number of ignitions the fireplace or stove has made, the number of changes to the room thermostat set point, etc.
-
Page 13: Maintenance
Do not strike or otherwise impact the glass in any way that may cause it to break. If the glass becomes cracked or broken it must be replaced before using the fireplace. Replacement door can be obtained from your nearest Pacific Energy dealer. Do not substitute with any other type. -
Page 14: Lighting Instructions
OWNER’S Lighting Instructions INFORMATION 020215-36 5055.66-E... -
Page 15: Installer Information
INSTALLER Fireplace Dimensions INFORMATION Broadway: 14 3/4” Figure 16: Broadway Dimensions Brentwood: Figure 17: Brentwood Dimensions 5055.66-E 020215-36... -
Page 16: Existing Fireplace Preparation
INSTALLER Existing Fireplace Preparation INFORMATION The Broadway and Brentwood Gas inserts are certified to be installed into pre-existing approved fire place cavities. The minimum cavity requirements are listed in Figure 18 below. Dimension Broadway Brentwood 13” 15” 21” 23” 26”... -
Page 17: Clearances To Combustibles
INSTALLER Clearances to Combustibles INFORMATION *MANTEL CLEARANCE Broadway Brentwood 20 1/2” 32” 16” 32” 11” 32” ** MANTEL DEPTH 12” 9” 6” 16” Minimum hearth depth As measured from glass Figure 19: Mantel Clearances 8” Figure 20: Sidewall Clearances 5055.66-E... -
Page 18: Surround Installation
3. Install the surround front by positioning it so as to clear the notches and secure by applying a downward pressure in order to engage the locking tabs. Figure 21: Contemporary Surround Broadway Brentwood GBWY.STBKA GBNT.STBKA GBWY.STSSA GBNT.STSSA GBNT.STBKOSA GBWY.STBKOSA... -
Page 19: Venting
Venting INFORMATION Note: The following Simpson Duravent kits are MAX. Vent Height 35’ (10.7m) recommended for use with this appliance. High-Wind (Broadway 46DVA-CL33) 26’-35’ (Brentwood 46DVA-CL34) Full Closed Prairie Co-Linear Kit (Broadway 46DVA-CL33P) (Brentwood 46DVA-CL34P) Only certified venting systems or components may 16’-26’... -
Page 20: Plumbing And Electrical
INSTALLER Plumbing and Electrical INFORMATION Figure 26: Gas and Electrical Connections Note: Installation requires that an electrical outlet be installed into existing fireplace cavity before insert is installed. To make the required electrical and gas connections start by positioning the gas insert within the existing fireplace. -
Page 21: Gas Supply
WARNING: The gas tray including gasket must be reinstalled after conversion/installation or servicing has been completed. Gas Pressure Check / Output / Efficiency Please refer to following page for gas pressure testing procedure. Broadway Gas pressure requirements Orifice Output AFUE 1.98mm... -
Page 22: Gas Pressure Testing Procedure
INSTALLER Gas Pressure Testing Procedure INFORMATION Note: To test the gas pressure, turn off the gas supply to the appliance before loosening test point screws. Verify gas pressures with the fireplace lit and at the highest setting. 1. Remove door (Fig. 31) and locate the valve as seen in Figure 27. 2. -
Page 23: Propane Conversion
INSTALLER Propane Conversion INFORMATION Before starting the conversion make sure to shut off the gas supply to the unit and allow fireplace to cool to room temperature. To convert the gas fireplace insert from natural gas to propane the (GASC.LPKIT) kit is required. This kit comes with new pilot and burner orifices as well as a new pressure modulator for the valve. -
Page 24: Door Installation/Removal
INSTALLER Door Installation/Removal INFORMATION Installation 1. Position the door so that the doors upper bracket is positioned overtop of the lip on top of the firebox. 2. Lower the bottom edge of the door and secure it with 1/4” bolts to the relief arms as shown in figure 28. -
Page 25: Panel Installation/Removal
INSTALLER Panel Installation / Removal INFORMATION Installation NOTE: Air Deflector from burner kit needs to be installed before panels. See Burner Kit Installation. 1. Insert back panel so that it is sitting on ledge at the back of the firebox as shown in Figure 34. -
Page 26: Log Burner Kit Installation/Removal
INSTALLER Log Burner Kit Installation / Removal INFORMATION Air Deflector Installation / Removal Installation Position the air deflector in the fireplace as seen in figure 37 and secure with two screws using a screwdriver. Removal Remove the two screws seen in figure 37 using a screwdriver, and remove the air deflector from fireplace. -
Page 27: Log Set Installation/Removal
INSTALLER Log Set Installation / Removal INFORMATION Installation 1. Position rear log against the back firebox as seen in Figure 39. 2. Position front log just behind the front burner tube as seen in Figure 42. 3. Position log 3 with the thin end of the log resting on top of the right end of the front log as seen in Figure 44. -
Page 28: Rustic Log Set Installation/Removal
INSTALLER Rustic Log Set Installation / Removal INFORMATION Installation 1. Position rear logs #1 and #2 against the back firebox as seen in Figure 48. 2. Position front logs #3 and #4 between the front burner tubes as seen in Figure 49. 3. -
Page 29: Glass Burner Kit Installation/Removal
INSTALLER Glass Burner Installation / Removal INFORMATION Air Deflector Installation / Removal Installation Position the air deflector in the fireplace as seen in figure 53 and secure with two screws using a screwdriver. Removal Remove the two screws seen in figure 53 using a screwdriver, and remove the air deflector from fireplace. - Page 30 INSTALLER INFORMATION The Broadway and Brentwood fireplaces both come with an adjustable damper that can limit the flow of intake air. This damper is located behind the air deflector at the rear of the inner firebox. Sometimes on installations that involve vertical venting configurations over 10 feet in height, the intake air tends to accelerate down the vent causing hectic flame action.
-
Page 31: Replacement Parts / Kits List
INSTALLER INFORMATION Replacement Parts Description Order Number 1. Broadway Regular Screen..........GBWY.SCRNA 2. Brentwood Regular Screen..........GBNT.SCRNA 3. Complete Replacement Gas Tray........GASC.BRNTRAYA Broadway (18,000 BTU) Aesthetic Components Brentwood (30,000 BTU) Aesthetic Components Door Kit (required) Door Kit (required) SCREEN PRINTED DOOR ....BRET.DSPA SCREEN PRINTED DOOR ....BDEM.DSPA... -
Page 32: Wiring Diagram
INSTALLER INFORMATION Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. 020215-36 5055.66-E... -
Page 33: Broadway Rating Label
INSTALLER INFORMATION 5055.66-E 020215-36... -
Page 34: Brentwood Rating Label
INSTALLER INFORMATION 020215-36 5055.66-E... - Page 35 INSTALLER INFORMATION 5055.66-E 020215-36...
- Page 36 © 2014 Copyright Pacific Energy Fireplace Products LTD. INSTALLER Reproduction, adaptation, or translation without prior written permission is prohibited INFORMATION except as allowed under the copyright laws. For technical support, please contact your retailer. Web site: www. pacificenergy.net 2975 Allenby Rd., Duncan, BC V9l 6V8 020215-36 5055.66-E...
